- Page 1 5.5″ 4K HDMI Monitor CM-55C QUICK GUIDE...
- Page 2 INTERFACES AND BUTTONS Power Switch Battery Input Battery output HDMI Input DC Power Input Micro USB Remote Control SD Card Slot Headphone Switch to “ ” position to power on; Power Switch and switch to “ ” position to power off DC IN DC power input, 5～17VDC，...
- Page 3 POWER ON ❶ Install the battery or connect the power cord. ❷ Switch the power switch to “一” position, the monitor will be powered on. It will display the boot screen after power on for 3~4 seconds. The BATT OUT interface directly outputs battery power when battery is mounted.
- Page 4 BUTTONS OPERATION JOYSTICK Joystick Joystick provides five operation directions, Up Down, Left, Right, and Straight Down. Use the joystick as a navigation tool to scroll between scenes pages and set features. : scroll it leftmost to enter into the monitor settings menu : scroll it right to enter into a scene or create a scene mode : scroll it up to enter into ZOOM mode : cancel the settings, return to the previous menu or quit...
- Page 5 SCENE MODE Enter a Scene It will display a scene as default after powered on. Scroll the joystick right or left to switch among scenes. Scroll the joystick down to return a scene when in ZOOM mode. Scroll the joystick right to return a scene when in monitor settings menu.
- Page 6 Enable/Disable a Tool In a scene, press straight down the joystick to display the scene tool, and then scroll the joystick left to close the scene tool in current scene. IMAGE ZOOM Scroll up the joystick to enter into image zoom mode, double(2X) or quadruple(4X) the image, and move the starting position of the enlarged image.
- Page 7 ❷ Adjusting Mode Press straight down the joystick to move the starting position of the enlarged image. Then, the icon is changed, there will be four arrows at each direction surrounding the center rectangle. Press straight down the joystick to confirm the adjustment. * In 2X or 4X zoom mode, press straight down the joystick, it will recover and display the original image.
- Page 8 SWIT Electronics Co., Ltd. Add: 10 Hengtong Road, Xin'gang, Nanjing Economic and Technological Development Zone, Nanjing 210038, P.R.China Tel: +86-25-85805753 Email: contact@swit.cc SWIT Electronics Europe GmbH Add: Hochstr. 17, 47228 Duisburg, Germany Tel: +49(0)20659799339 Email: info@swit-europe.com SWIT Electronics America, Inc Add: 3350 Scott Boulevard 61-02, Santa Clara, CA 95054, USA Tel: (408)260-8258, 1-866-986-SWIT(7948) Email: info@swit.us...
