VIEWING GAUGES

If you would like to view Parameter IDs (PIDs) specific to your vehicle, following these
instructions to learn how to view them using your Flashpaq device.
WARNING
Do not exceed legal speed limits on public roadways.
STEP 1 - Enter the STEP 2 - Select
Scan Menu. Gauges/Datalog.
STEP 5 - Select a PID Group, then select
a total of 4 PIDs. Use the / arrows to
switch between screens. OK to select.
PID Groups 1/1 Engine Misc 1/1
Engine Misc Calc Eng Load
Fuel Trim/Press Engine Coolant Temp
Time/Distance Manifold Abs Pressure
Oxygen Sensors Engine RPM
Misc Non-Engine Spark Advance
Egr/Evap Intake Air Temperature
Catalyst Temp Mass Air Flow
Throttle Detail Abs Throttle Position
STEP 3 - If asked, STEP 4 - Follow
turn ignition on, the on-screen
but do not start. instructions.
Select 4 PIDs within the
following menu
Press OK to continue...
STEP 6 - Follow the on-screen
instructions. Note the RED highlights.
See DataLogging for more information.
While viewing gauges,
press OK to start
Datalogging
Press OK again to stop
Datalogging
Press OK to continue
Data logging allows you to record specific vehicle information while driving. Follow these
instructions to find out how to datalog, and how it may be helpful to your particular needs.
WARNING
Do not exceed legal speed limits on public roadways.
STEP 1 - Refer to STEP 2 - Press the OK button to begin
the previous section recording the PID data. Press the OK
and follow the steps. button again, to stop the recording.
The information will be stored on the device and may be retrieved using a
computer. For more information continue to the next section.

DATA LOGGING

STEP 3 - Press the
left arrow to return
to the menu.
The separator lines
will change from
Red to Green,
which indicates
that the device is
actively recording
(datalogging).
