Aiphone GT-1C7-L Installation Manual
Residential/tenant station
Hide thumbs
Also See for GT-1C7-L:
- Operation manual (13 pages) ,
- Operation manual (58 pages) ,
- Quick start installation manual (8 pages)
Table of Contents
Advertisement
FK2330 A P1216 SZ 58483
GT-1C7-L/GT-1C7
SERVICE MANUAL
GT-1M3-L/GT-1M3
Residential/Tenant Station
INSTALLATION MANUAL
GT-1C7-L/GT-1C7
GT-1M3-L/GT-1M3
Thank you for selecting Aiphone for your communication needs. Please read this manual carefully before installation, and keep
this in a safe place for future reference.
Please note that images and illustrations depicted in this manual may differ from the actual product.
Advertisement
Table of Contents
Related Manuals for Aiphone GT-1C7-L
Summary of Contents for Aiphone GT-1C7-L
- Page 1 GT-1C7-L/GT-1C7 GT-1M3-L/GT-1M3 Thank you for selecting Aiphone for your communication needs. Please read this manual carefully before installation, and keep this in a safe place for future reference. Please note that images and illustrations depicted in this manual may differ from the actual product.
- Page 2 * If liquid crystal is ingested, immediately gargle with water and seek • This manual was created by Aiphone Co., Ltd., all rights reserved. Copying a medical attention. part of or this entire manual without prior permission from Aiphone Co., Ltd. is * If contact with the eyes or skin occurs, clean with pure water and seek strictly forbidden.
-
Page 3: Table Of Contents
5 cm 5 cm (2") (2") 5 cm (2") 5 cm (2") GT-1C7-L/GT-1C7 only The station has a speaker on the back. Make sure to leave the specified spaces on all the sides to ensure sound clarity. - 3 -... -
Page 4: Mounting
(5/16") Notes ( GT-1C7-L/GT-1C7 only • The station has a speaker on the back. When using a gang box for routing the wires, use a single gang box and attach the mounting bracket to the wall directly in the way as shown above. If a 2- or 3-gang box is used, audio quality may be altered. -
Page 5: Wiring
* Refer to the GT SYSTEM Installation manual (page 27) when connecting the stations by using the 4-way video junction unit (GT-4Z). To prevent shorts, unused cables should be insulated. Terminal setting: For terminating a residential/tenant GT-1C7-L/GT-1C7 station, turn SW1 to the [A] side. B1 B2 R1 R2 (*1) -
Page 6: Option Connector
Option connector To prevent shorts, be sure to cut unused lead wires at the bottom and insulate the ends. GT-1C7-L/GT-1C7 Option connector (Yellow) Doctor call (automatic entry) (Orange) (Blue) Call notification (White) GT-1M3-L/GT-1M3 (Gray) Option contact output (Black) Doctor call (automatic entry) This makes it possible to use the doctor call (automatic entry) function at residential/tenant stations. -
Page 7: Settings
Please read the chapter [5 SETTINGS (COMMON AREA)] of the GT SYSTEM Installation manual for the settings. However, also read the following for the sections 5-6 and 5-7 only. Those include operations on the GT-1C7-L/GT-1C7 or GT-1M3-L/GT-1M3. Manual setting of residence ID * Read this section in place of [5-6 Manual setting of residence ID] of the GT SYSTEM Installation manual. -
Page 8: Regulations
WARRANTY Aiphone warrants its products to be free from defects of material and workmanship under normal use and service for a period of 2 years after delivery to the ultimate user and will repair free of charge or replace at no charge, should it become defective upon which examination shall disclose to be defective and under warranty.
