syncing two bases (optional)
A Sync Cord is included with Twing Long and Split Cal King size bases.
The Sync Cord connects the two control boxes to a single remote for the synchronization of two bases.
STEP 1
Unplug the base(s) from power source.
STEP 2
Disconnect the battery backup box cable from each control
box or splitter cable (make note where the cable was
plugged in).
STEP 3
Connect the male end of each sync cord to control box
or splitter cable. Insert it into the same port that you
disconnected the battery backup box from in Step 2.
STEP 4
Connect each battery backup box male connection to the
sync cord female connection (Refer to illustration at right).
STEP 5
Plug bases back into the power source.
STEP 6
Check to ensure all cords are securely attached. Both
remotes will now operate both bases simultaneously.
The system is now linked. Pressed buttons on either remote
will control the two bases simultaneously.
Sync Cord
Control Box 1
Battery Backup
Box 1
PERFORMANCE NOTES
If bases become mismatched, return both bases to the
flat position to re-sync the bases.
Control Box 2
Battery Backup
Box 2
15
