Battery Installation Of Remote Control - Onn ONB18SB001 Product Manual

1
2
AUX
OPTICAL
LINE
3
IN
4
MUSIC TALK
5
Sound Mode
STANDARD

BATTERY INSTALLATION OF REMOTE CONTROL

First time use
Remove and discard the insulation film as Fig.1.
Replacing battery for Remote Control
1. Pull out the battery holder as Fig.2.
2. Replace the old button cell with a new CR2025 button cell
with the polarity markings facing upward as Fig.3.
3. Push back the battery holder as Fig.4.
Fig.2
REMOTE CONTROL
6
7
8
9
10
11
MOVIE
VOL
12
3V CR2025
Fig.3
8
1. (Power On/Off) Button
2. AUX Button
3. LINE IN Button
4. (Previous) Button
5. Sound Mode (MUSIC,
TALK, MOVIE, STANDARD)
6. (Mute) Button
7. (Bluetooth)Button
8. OPTICAL Button
9. (Mode Switch) Button
10. (Next) Button
11. Play/Pause Button
12. (Volume Up/Down)Button
Fig.4
Fig.1
