5.2 Maintenance

This panel is used for saving and displaying the data.
To display the [Maintenance] panel, select the mode selector key switch to "AUTO", and
then tap the [Maintenance] tab.
Select either of the following from the [Function] list.

Backup

Restore
Controller Maintenance
Robot Maintenance
The password is required if it is set in the EPSON RC+. Enter the password.
5.2.1 Backup
This panel is used for saving the Controller information to the USB memory.
To save the current status:
Tapping the <Backup> button saves the current state to the USB memory. The status
such as controller setting, task status, I/O status, and robot status are saved. This is
useful when reporting the Robot system status to the distributers or our technical support.
The data is saved in the folder named "B_serial number_date_time", which is
automatically created under the EPSON folder in the USB memory.
To remove the USB memory:
Tapping the <Unmount> button displays the removal instruction. Remove the USB
memory by following the instruction.
For details of cautions for using the USB memory, refer to Operation 8. USB Port.
