DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` a
INSTRUCTION MANUAL

DVD Player

Please Read This Manual.

We recommend that you read this manual carefully before connecting your DVD
video player and operating it for the first time.
Keep this manual in a safe place for future reference.
1AD6P1P2011--A
(CA)
DVD-DX405
English

Advertisement

Table of Contents
loading

Related Manuals for Sanyo DVD-DX405

Summary of Contents for Sanyo DVD-DX405

  • Page 1: Dvd Player

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` a INSTRUCTION MANUAL DVD Player Please Read This Manual. We recommend that you read this manual carefully before connecting your DVD video player and operating it for the first time. Keep this manual in a safe place for future reference.

  • Page 2: Table Of Contents

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 1 TABLE OF CONTENTS IMPORTANT SAFETY PRECAUTIONS ... 2 FEATURES ... 5 ABOUT DISCS ... 6 BEFORE OPERATION... 8 PREPARATIONS BEFORE OPERATION. 10 Front Panel ... 10 Rear Panel ... 11 VFD... 12 Names and Layout of Remote Controls ...

  • Page 3: Important Safety Precautions

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 2 IMPORTANT SAFETY PRECAUTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER- SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
  • Page 4 DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 3 This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following procedures for installation, use and servicing.
  • Page 5 DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 4 IMPORTANT SAFETY PRECAUTIONS This will prevent damage to the unit due to lightning and power line surges. 14 DISC TRAY Keep your fingers well clear of the disc as it is closing. It may cause serious personal injury.

  • Page 6: Features

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 5 FEATURES Thank you for choosing SANYO. Please read this manual carefully to obtain maximum benefits from your product. OUTSTANDING SOUND QUALITY Dolby Digital developed by DTS Inc., features high quality surround sound which can be played in DVD or CD disc at home, to reproduce high quality sound effects.

  • Page 7: About Discs

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 6 ABOUT DISCS PLAYABLE DISCS DVD-video DVD-R/+R DVD-RW/+RW DVD-ROM CD-G CD-DA CD-R/ CD-RW CD-DA/JPEG/MP3 CD-ROM NONE PLAYABLE DISCS DVD-video DVD-ROM CD-ROM CD-MP3 DVD-RAM STRUCTURE OF DVD DISC TITLE CHAPTER TITLE The images or music of a DVD are divided into some units, among which title is the biggest one.
  • Page 8 DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 7 CHAPTER It is smaller than title among the units of a DVD. A title is made up of several chapters , and each chapter has a number for search. But some discs may not have numbered chapters.

  • Page 9: Before Operation

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 8 BEFORE OPERATION SECURITY • Before operation, check if the voltage of the unit is in line with the local voltage. • Hold the plug to disconnect it from the mains outlet. Do not pull the power cord.
  • Page 10 DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 9 CHECK ACCESSORIES Check if you have all the accessories after the carton is opened. Remote control AAA batteries USE REMOTE CONTROL 1 Open the battery compartment. 2 Insert two AAA batteries, make sure to match "+" and "-" of the batteries to the marks in the battery compartment.

  • Page 11: Preparations Before Operation

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 10 PREPARATIONS BEFORE OPERATION FRONT PANEL ! STANDBY/ON button To switch the unit On or Off when connected to AC power outlet @ OPEN/CLOSE button To open or close the disc tray. # PLAY button To play the loaded disc.

  • Page 12: Rear Panel

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 11 REAR PANEL ! AUDIO OUT (L/R TRACK) Two phono sockets for analogue 2 Channel audio in order to a TV or stereo amplifier. @ VIDEO OUT Connects composite video signal to input AV or PHONO sockets of TV or monitor to achieve high fidelity colour reproduction.

  • Page 13: Vfd

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 12 PREPARATIONS BEFORE OPERATION MP3 PBC ! Recognized DISC TYPE indicator : DVD @ PLAY indicator # PAUSE indicator $ DVD/CD/MP3 indicator Indicates the title, chapter or track number. % DVD/CD/MP3 indicator Indicates the hour.

  • Page 14: Names And Layout Of Remote Controls

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 13 NAMES AND LAYOUT OF REMOTE CONTROLS * After setting the mode by using SETUP menu (for example, NTSC select in NTSC/PAL/AUTO setup), the setting is kept though you switch the unit off and turn it on.

  • Page 15: Connections

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 14 CONNECTIONS Turn off all equipment before operation. The unit has many kinds of output modes like A/V output, S-VIDEO output and digital signal output (COAXIAL, OPTICAL). You may select as you need.

  • Page 16: Basic Operations

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 15 BASIC OPERATIONS PLAY DISCS Press "POWER" button on the TV and audio system, Press "TV/VIDEO" button on the TV, select VIDEO mode (TV). Select S-Video mode if using an S-VIDEO connection. N ote: Select the correct audio input on the amplifier.

  • Page 17: System Setting

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 16 BASIC OPERATIONS SYSTEM SETTING According to the system of the TV to be connected, set the system of the unit to make it match the TV. Press SYSTEM button on the remote control, then choose TV TYPE.

  • Page 18: Fast Play

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 17 FAST PLAY When playing disc, you may play it forward fast or reverse it fast to find what you need. N ote: Press Press PLAY to play time you press the button, the speed of normally when picture changes like the right sides.

  • Page 19: Select Audio Language

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 18 BASIC OPERATIONS SELECT AUDIO LANGUAGE You can choose the language according to your choice when playing mulit- language DVD. Press “AUDIO” button, select different languages. AUDIO *Attention: Please select the AUDIO language in SETUP menu to keep the setting!!! SELECT CHANNELS (VCD) You may select the right channel or left channel or stereo from a multi-channel.

  • Page 20: Playing A Desired Scene

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 19 PLAYING A DESIRED SCENE TO SKIP SCENES IN A DISC Press √ √ to move to the next chapter (or track). The current chapter (or track) moves to the next chapter (or track).

  • Page 21: Playing A Disc Containing Mp3 Files

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 20 PLAYING A DESIRED SCENE PLAYING A DISC CONTAINING MP3 FILES When a MP3 disc is loaded, MP3 menu screen is displayed automatically depending on MP3 disc’s folder structure. Use the direction button to select the folder you want to play and press the [PLAY] button.

  • Page 22: Repeating A Defined Period From A To B (Dvd)

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 21 REPEATING A DEFINED PERIOD FROM A TO B You may press A-B to enjoy some parts repeatedly when playing a disc. 1. Press “A-B” to set a starting point A. 2. Press “A-B” twice to an end point B.

  • Page 23: Searching

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 22 PLAYING A DESIRED SCENE SEARCHING SEARCHING D SEARCHING D You may directly enter a title or chapter number to search fast on a disc. The unit plays from the point. 1 If you want to search with a chapter or a title number, press [SEARCH] button.

  • Page 24: Play Discs In Various Ways

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 23 PLAY DISCS IN VARIOUS WAYS SELECT ANGLE Some discs have images with different screen angles, you may select among N ote: them. For example, when you watch a running train, you may select to watch it from the front, the left window or the right window without stopping it.

  • Page 25: Book Mark

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 24 PLAY DISCS IN VARIOUS WAYS BOOK MARK Press MARK button , the screen will show the following frame: Moving direction button to select the saving position on the screen. Press PLAY button to save the time tag.

  • Page 26: Program Play (Dvd)

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 25 PROGRAM PLAY (DVD) You may program the title and chapter on a disc and play them in the programmed order. N ote: Press "PROGRAM" button, the screen shows: • First one is title, second one is chapter.

  • Page 27: Program Play (Vcd)

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 26 PLAY DISCS IN VARIOUS WAYS PROGRAM PLAY (VCD) You may program the track on a disc and play them in the programmed order. Press "PROGRAM" button, the screen shows: Input the sequence number you want to program playing.

  • Page 28: Digest Play (Dvd)

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 27 DIGEST PLAY (DVD) Push "INTRO" button when the unit is playing disc, the screen shows : Push direction button to select the digest type. And push “PLAY” button. N ote: • TITLE DIGEST The player will play 5 seconds of each title.

  • Page 29: Digest Play (Vcd)

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 28 PLAY DISCS IN VARIOUS WAYS DIGEST PLAY (VCD) Push "INTRO" button when the unit is playing disc, the screen shows : Push direction button to select the digest type. And push “PLAY” button.

  • Page 30: Play Mp3, Jpeg Or Picture Cd

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 29 PLAY MP3, JPEG OR PICTURE CD SELECT TRACKS The screen will display right after the disc is loaded You can select the file you want using the direction buttons. Press the PLAY button after selecting the file you want.

  • Page 31: Function Setting

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 30 FUNCTION SETTING MENU SETTING According to the recorded information and external equipment, set the following functions for DVD to obtain the best playing status. Press "SETUP" button to set the main menu.
  • Page 32 DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 31 BASIC NAVIGATION To navigation through the setting on the screen, use the direction buttons to scroll through the list of settings and use “PLAY” button to select the high lighted function. SETUP MENU Press the SETUP button to enter the On Screen Display and to exit at any time.

  • Page 33: Language

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 32 FUNCTION SETTING LANGUAGE OSD LANG. N ote: “OSD” means When select a language, the screen show this language. “On Screen For example, if you select ENGLISH, the OSD is in English. Display”.

  • Page 34: Video

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 33 VIDEO TV DISPLAY NORMAL/PS This is selected when the unit is connected with a normal TV. Wide-screen images are shown on the screen, but with some parts cut automatically. NORMAL/LB This is selected when the unit is connected with a normal TV.

  • Page 35: Audio

    DTS DVD or MPEG DVD is played, select this, the coaxial or optical port will output in the corresponding digital format (source code). • LPCM Select this when the DVD player is connected with a TV or a power amplifier through audio cord. Down Mix...
  • Page 36 DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 35 DUAL MONO This is the output mode of the L and R signals of the set audio output. If it is set to "MIX MONO", the function only works when the DVD being played is 2.0-channel.

  • Page 37: Preference

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 36 FUNCTION SETTING PREFERENCE PASSWORD Select "PASSWORD" in PREFERENCE SETUP menu to setup password, input a password. Enter a password according to the screen. N ote: • The password is 3308 when the unit is turned on initially or you forget the password.

  • Page 38: Others

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 37 OTHERS TROUBLESHOOTING If you experience the following problems while using the unit, this troubleshooting guide can help you. • NO SOUND - Check if the unit is connected securely. - Make sure you operate the TV or amplifier correctly.

  • Page 39: Technical Specifications

    DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 38 OTHERS TECHNICAL SPECIFICATIONS Laser Video Frequency response Signal/noise ratio Channel separation Dynamic range Analog Output Audio Digital Composite Output Video S-video Component Power Body (W x H x D) Dimensions Packing Weight (Gross/ Net) Notes : Design and specifications in this instruction manual are subjected to change without prior notice to improve quality and function.
  • Page 40 DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 39...
  • Page 41 DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘ ` 40 P/N:97P95600D0- (1E 06/06) SANYO Electric Co., Ltd. Printed in China...
