quick start guide
1.
Product features
Premium Café Look
Design
The illuminating blue lighting
of the dispenser matches the
espresso machine, so your
kitchen maintains its classy
style.
Clear View Icemaker
The Icemaker is located in
the freezer door, ensuring full
utilization of the freezer shelf
space. Ice cubes are quickly
produced and the clear ice
bucket lets you easily see
the amount of ice cubes
produced.
Beverage Station
Easy access to your favorite
drinks while keeping the fridge
closed to maintain internal
temperature.
(Optional: RSG5K*, RSG5F*)
Spill-proof Shelves
Thanks to the all-around trim, spills and food stay contained without spilling over onto other
shelves.
RSG5D**
RSG5F**
RSG5K**
LED Tower Lighting
This space-saving fixture
illuminates every corner of
the refrigerator, so things are
easier to find.
Tall Dispenser
This tall dispenser serves
chilled, filtered water, with a
choice of cubed or crushed
ice.
Tilt Can carry
This flexible can holder can be
folded up to provide more
storage space for taller
bottles.
Advertisement
Table of Contents
Related Manuals for Samsung RSG5F series
Summary of Contents for Samsung RSG5F series
-
Page 1: Product Features
RSG5D** RSG5F** RSG5K** LED Tower Lighting This space-saving fixture illuminates every corner of the refrigerator, so things are easier to find. Tall Dispenser This tall dispenser serves chilled, filtered water, with a choice of cubed or crushed ice. Tilt Can carry... - Page 2 With TWIN Cooling Plus™, the refrigerator and freezer compartments are monitored separately so cooling air can be adjusted according to where it is needed the most. It also optimizes the distribution of cooling refrigerant and levels of humidity in the refrigerator, keeping foods fresh for a longer period of time...
-
Page 3: Safety Information
Safety Information Before using your new Samsung Side-By-Side Refrigerator, please read this manual thoroughly to ensure that you know how to safely and efficiently operate the features and functions that your new appliance offers. Because the following instruction covers various models, the characteristics of your Refrigerator may differ slightly from the Refrigerator described in this manual. -
Page 4: Severe Warning Signs
- Deteriorated insulation of electrical parts may cause an electric shock or fire. WARNING • Do not place this refrigerator in direct sunlight or expose to the heat from stoves, room heaters or other appliance. • Allow sufficient space to install the refrigerator on a flat surface. -
Page 5: Caution Signs
Do not dissemble or repair the refrigerator by yourself. - You run risk of causing a fire, malfunction and/or personal injury. • If you smell pharmaceutical or smoke, pull out power plug immediately and contact your Samsung electronics service center. •... - Page 6 R600a or R134a is used as a refrigerant. Check the compressor label on the rear of the appliance or the rating label inside the fridge to see which refrigerant is used for your refrigerator. When this product contains flammable gas(Refrigerant R600a) contact your local authority in regard to safe disposal of this product.
- Page 7 Names and basic functions Name of each component RSG5K* Button & Display Dispenser Freezer Door ➊ ➋ ➌ ➍ ➎ Door Handle Home Bar Fridge Door Front Leg Cover 1. Lamp Cover ➏ 2. Ice Maker Bucket ➐ 3. Shelves ➑...
- Page 8 Name of each component RSG5F* Button & Display Dispenser Freezer Door ➊ ➋ ➌ ➍ ➎ Door Handle Home Bar Fridge Door Front Leg Cover 1. Lamp Cover ➏ 2. Ice Maker Bucket ➐ 3. Shelves ➑ 4. Door Bins ➒...
- Page 9 Name of each component RSG5D* Button & Display Dispenser Freezer Door ➊ ➋ ➌ ➍ ➎ Door Handle Fridge Door Front Leg Cover 1. Lamp Cover ➏ 2. Ice Maker Bucket ➐ 3. Shelves ➑ 4. Door Bins ➒ 5. Drawers ➓...
- Page 10 If you are going on vacation or business trip or you do not need to use the refrigerator, press and hold this button for 3 seconds. The temperature in the fridge will be around 15°C and the freezer will work normally.
- Page 11 This icon will light up when you activate the “Vacation” feature. If you are going on vacation or business trip or you do not need to use the refrigerator, press and hold the Child Lock button for 3 seconds. The temperature in the fridge will be around 15ºC and the freezer will...
-
Page 12: Storage Of Food
This helps keep odor and mold from developing. • If the refrigerator is not to be used for a long period of time, pull out the power plug. - Deterioration in the power cord insulation may cause fire. -
Page 13: Controlling The Temperature
Child Lock button for 3 seconds and then use this function. • Power Freeze fucntion will be off in 72 hours automatically, the refrigerator operate set temperature last time. • When you use this function the energy consumption of the refrigerator will increase. - Page 14 (Once the Freezer and Fridge return to their normal set temperatures the blinking will stop. If the blinking continues, you may need to “reset” the refrigerator or call to Service Center.) CoolSelect zone™ drawer (optional) Press the “Fridge”...
- Page 15 Chill • When “Chill” is selected, the temperature of the CoolSelect Zone™ Drawer is kept at -1° C, regardless of the overall temperature setting of the refrigerator. This feature also helps keep meat or fish fresh for longer. Thaw •...
- Page 16 When “Cool” is selected, the temperature in the CoolSelect Zone™ Drawer will be the same as the overall temperature setting of the refrigerator. The drawer digital panel shows the same temperature as that of the refrigerator display panel. Since the “Cool” function...
-
Page 17: Troubleshooting
Is the refrigerator in direct sunlight or located too near a heat source? • Is the back of the refrigerator too close to the wall and therefore keeping air from circulating? • Is the temperature control on the display panel set to the correct temperature? Try setting it to a warmer temperature.
