Model No.
INDOOR UNIT
High Static Pressure Ducted
(E2 type)
S-200PE2E5
S-250PE2E5
● Connectable outdoor unit lineup
This booklet is the operating
instructions for indoor unit. Regarding
the outdoor unit, see the operating
instructions supplied with the outdoor
unit.
OUTDOOR UNIT
U-200PE1E8
U-250PE1E8
U-200PE2E8A
U-250PE2E8A
85464609291022
AMP Air Conditioning
ENGLISH
Before operating the unit, read these operating instructions thoroughly and
keep them for future reference.
FRANÇAIS
Avant d'utiliser l'appareil, lisez ce mode d'emploi dans son intégralité et
conservez-le pour toute référence ultérieure.
ESPAÑOL
Antes de operar la unidad, lea atentamente estas instrucciones de
funcionamiento y guárdelas para futuras consultas.
DEUTSCH
Bevor Sie das Gerät in Betrieb nehmen, lesen Sie bitte diese
Bedienungsanleitung aufmerksam durch und bewahren Sie sie für die
künftige Verwendung auf.
ITALIANO
Prima di utilizzare l'unità, leggere a fondo queste istruzioni per l'uso e
conservarle come riferimento futuro.
NEDERLANDS
Lees deze gebruiksinstructies goed door voor u het apparaat gebruikt en
bewaar ze voor toekomstig gebruik.
PORTUGUÊS
Antes de utilizar o aparelho, leia completamente este manual de instruções
e guarde-o para futuras referências.
EΛΛΗΝΙΚΆ
Πριν θέσετε τη μονάδα σε λειτουργία, διαβάστε πολύ καλά αυτές τις οδηγίες
χρήσης και διατηρήστε τις για μελλοντική αναφορά.
БЪЛГАРСКИ
Преди да започнете експлоатация на този уред, прочетете внимателно
тези инструкции и ги запазете, за да можете да правите справки с тях и
в бъдеще.
TÜRKÇE
Üniteyi çalıştırmadan önce bu çalıştırma talimatlarını iyice okuyun ve
gelecekte başvurmak için saklayın.
РУССКИЙ
Перед использованием этого устройства внимательно прочитайте
настоящую инструкцию по эксплуатации и сохраните ее для
дальнейших справок.
УКРАЇНСЬКА
Уважно прочитайте цю інструкцію з експлуатації перед тим, як
увімкнути пристрій, та збережіть її на майбутнє.
Panasonic Corporation
1006 Kadoma, Kadoma City, Osaka, Japan
Operating Instructions
Air Conditioner
www.ampair.co.uk | sales@ampair.co.uk
2 ~ 7
E
NGLISH
8 ~ 13
F
RANÇAIS
14 ~ 19
E
SPAÑOL
20 ~ 25
D
EUTSCH
26 ~ 31
I
TALIANO
32 ~ 37
N
EDERLANDS
38 ~ 43
P
ORTUGUÊS
44 ~ 49
E
ΛΛΗΝΙΚΆ
50 ~ 55
Б
ЪЛГАРСКИ
56 ~ 61
T
ÜRKÇE
62 ~ 67
Р
УССКИЙ
68 ~ 73
У
КРАЇНСЬКА
CV6233315270
Advertisement
Related Manuals for Panasonic S-200PE2E5
Summary of Contents for Panasonic S-200PE2E5
- Page 1 RANÇAIS conservez-le pour toute référence ultérieure. Model No. INDOOR UNIT ESPAÑOL 14 ~ 19 Antes de operar la unidad, lea atentamente estas instrucciones de High Static Pressure Ducted SPAÑOL funcionamiento y guárdelas para futuras consultas. (E2 type) DEUTSCH 20 ~ 25 S-200PE2E5 Bevor Sie das Gerät in Betrieb nehmen, lesen Sie bitte diese S-250PE2E5 Bedienungsanleitung aufmerksam durch und bewahren Sie sie für die EUTSCH künftige Verwendung auf. ● Connectable outdoor unit lineup ITALIANO 26 ~ 31 This booklet is the operating instructions for indoor unit. Regarding Prima di utilizzare l’unità, leggere a fondo queste istruzioni per l’uso e TALIANO conservarle come riferimento futuro.
-
Page 2: Table Of Contents
Thank you for purchasing this Panasonic product. WARNING This product is a commercial air conditioner indoor unit. Installation Instructions attached. Contents Confirm to authorized dealer or specialist on usage of specified refrigerant type. Using of refrigerant other than the Safety Precautions ............2 specified type may cause product Precautions for Use ............4 Names of Parts ..............5 damage, burst and injury etc. - Page 3 CAUTION This appliance is intended to be used Provide a power outlet to be used by expert or trained users in shops, exclusively for each unit, and a in light industry and on farms, or for power supply disconnect, Earth commercial use by lay persons. Leakage Circuit Breaker (ELCB) or Residual Current Device (RCD) This appliance can be used by for overcurrent protection should children aged from 8 years and be provided in the exclusive line. above and persons with reduced physical, sensory or mental Provide a power outlet capabilities or lack of experience and exclusively for each unit, and full knowledge if they have been given disconnection means having a supervision or instruction concerning contact separation in all poles NGLISH use of the appliance in a safe must be incorporated in the fixed way and understand the hazards wiring in accordance with the involved. wiring rules. Keep the fire alarm and the air outlet To prevent possible hazards at least 1.5m away from the unit. from insulation failure, the unit must be grounded. Do not cool or heat the room too much if babies or invalids are Do not use modified present. cord, joint cord, extension cord or Do not turn the air conditioner on unspecified cord to prevent...
-
Page 4: Precautions For Use
Precautions for Use Installation Operation Condition This air conditioner must be installed properly by qualified Use this air conditioner under the following temperature range. installation technicians in accordance with the Installation „ Indoor temperature range: Instructions provided with the unit. Cooling mode 18°C ~ 32°C (*DBT) Before installation, check that the voltage of the electric Heating mode 16°C ~ 30°C (*DBT) supply in your home or office is the same as the voltage *DBT: Dry bulb temperature shown on the nameplate. WARNING Information for Users on Collection and Disposal of Old Equipment and Used Batteries Avoid the following locations for installation. Locations where smoke or combustible gas exists. -
Page 5: Names Of Parts
Names of Parts INDOOR UNIT Air intake side duct flange (rear) Water drain Electrical Air outlet side component box duct flange (2 locations) NGLISH Optional Wireless Remote Controller Timer Remote Controller High-spec Wired Remote Controller Model No. Model No. Model No. CZ-RWSK2 CZ-RWSC3 CZ-RTC4 Model No. CZ-RTC5A Read the operating instructions included with the Remote Controller. Operation For details, refer to the Operating Instructions attached to the optional Remote NOTE Controller. -
Page 6: Maintenance
Maintenance Do not attempt to clean inside the unit by yourself. Refer to the section “Care and Cleaning” in the Installation Instructions. WARNING CAUTION For safety, be sure to turn the air conditioner off and Never use solvents or harsh chemicals. Also, do not wipe disconnect the power before cleaning. plastic parts using very hot water. (Otherwise, electric shock or injury may result because (This may cause deformation or change in colour.) the fan is rotating at high speed.) Some metal edges and fins are sharp. Be careful when Do not pour water on the indoor unit. you clean those parts. (This may damage the internal components and cause (Injury may result.) an electric shock hazard.) Use a firm stool or ladder when cleaning an indoor unit installed in high locations. Before Requesting Services Symptom Cause Action The air Power failure or after power failure Press the power ON/OFF button on the remote controller. conditioner does • If the breaker is turned off, turn the power on. not operate The operation (power) button is turned off. • If the breaker has been tripped, consult your dealer although the without turning it on. power is turned Fuse blow out. -
Page 7: Troubleshooting
Troubleshooting Check before consulting or requesting services. Symptom Cause / Action Sound like streaming water is heard • Sound of refrigerant liquid flowing inside unit during operation or after operation. • Sound of drainage water through drain pipe Noise Cracking noise is heard during operation Sound due to temperature changes of parts or when operation stops. NGLISH • Indoor odor components, cigarette odor and cosmetic odor accumulated in the air conditioner and its air is discharged. Discharged air smells during operation. • The unit inside is dirty. (Contact your dealer.) Dewdrops accumulate near the air outlet • Internal moisture is cooled by cool wind and accumulates as during cooling operation. dewdrops. • If the air conditioner has been installed at places such as restaurants where large amounts of oil mist exist, cleaning is Fog occurs during cooling operation. necessary because the unit inside (heat exchanger) is dirty.
