High Static Pressure Ducted
(Type E2)
Model No.
INDOOR UNIT
High Static Pressure Ducted
S-180PE2R5B
S-200PE2R5B
S-224PE2R5B
Before operating the unit, read these operating instructions thoroughly and keep them for future reference.
85464609359020
OUTDOOR UNIT
Single Split
(Type E2)
U-180PE2R8A
U-200PE2R8A
U-224PE2R8A
Panasonic Corporation
1006 Kadoma, Kadoma City, Osaka, Japan
Operating Instructions
Air Conditioner
(Type PE2)
CV6233332949
Advertisement
Table of Contents
Related Manuals for Panasonic S-180PE2R5B
Summary of Contents for Panasonic S-180PE2R5B
- Page 1 Model No. INDOOR UNIT OUTDOOR UNIT High Static Pressure Ducted Single Split (Type E2) (Type PE2) U-180PE2R8A S-180PE2R5B U-200PE2R8A S-200PE2R5B U-224PE2R8A S-224PE2R5B Before operating the unit, read these operating instructions thoroughly and keep them for future reference. Panasonic Corporation 85464609359020...
-
Page 2: Table Of Contents
Thank you for purchasing this Panasonic product. WARNING This product is a commercial air conditioner indoor unit. Installation Instructions attached. Contents Confirm to authorized dealer or specialist on usage of specified refrigerant type. Using of refrigerant other than the Safety Precautions ............2 specified type may cause product Precautions for Use ............ - Page 3 CAUTION This appliance is intended to be used Provide a power outlet to be used by expert or trained users in shops, exclusively for each unit, and a in light industry and on farms, or for power supply disconnect, Earth commercial use by lay persons.
-
Page 4: Precautions For Use
Precautions for Use Installation Operation Condition This air conditioner must be installed properly by qualified Use this air conditioner under the following temperature range. installation technicians in accordance with the Installation „ Indoor temperature range: Instructions provided with the unit. Cooling mode 18°C ~ 32°C (*DBT) Before installation, check that the voltage of the electric Heating mode 16°C ~ 30°C (*DBT) -
Page 5: Names Of Parts
Names of Parts INDOOR UNIT OUTDOOR UNIT Air intake Air intake side duct (rear, left side) flange (rear) Air outlet Water drain Air outlet side duct flange Electrical (2 locations) component box Drain port (bottom) Anchor hole Optional Wireless Remote Controller Timer Remote Controller High-spec Wired Remote Controller... -
Page 6: Maintenance
Maintenance Do not attempt to clean inside the unit by yourself. Refer to the section “Care and Cleaning” in the Installation Instructions. WARNING CAUTION For safety, be sure to turn the air conditioner off and Never use solvents or harsh chemicals. Also, do not wipe disconnect the power before cleaning. -
Page 7: Troubleshooting
Troubleshooting Check before consulting or requesting services. Symptom Cause / Action Sound like streaming water is heard • Sound of refrigerant liquid flowing inside unit during operation or after operation. • Sound of drainage water through drain pipe Noise Cracking noise is heard during operation Sound due to temperature changes of parts or when operation stops. -
Page 8: Specifications
Specifications Indoor unit High Static Pressure Ducted (Type E2) Model Name S-180PE2R5B S-200PE2R5B S-224PE2R5B 230 / 240 V ～ 50Hz Power Source 18.0 20.0 22.4 Cooling capacity BTU/h 61,400 68,200 76,400 20.0 22.4 25.0 Heating capacity BTU/h 68,200 76,400 85,300... -
Page 9: Outdoor Unit
Outdoor unit Single Split (Type PE2) Model Name U-180PE2R8A U-200PE2R8A U-224PE2R8A Power source 400 / 415 V 3N ～ 50 Hz 18.0 20.0 22.4 Cooling capacity BTU/h 61,400 68,200 76,400 20.0 22.4 25.0 Heating capacity BTU/h 68,200 76,400 85,300 Sound pressure level (C/H) dB(A) 59 / 61 60 / 62... - Page 10 MEMO...
- Page 11 MEMO...
- Page 12 Panasonic Corporation Website: http://www.panasonic.com © Panasonic Corporation 2016 85464609359020 Printed in China DC0716-0...
