VECTRIX VX-2 SERVICE MANUAL
SECTION C-3:
BRAKE SWITCH
Preparations:
Remove Front Fairing
Remove Front Console Cover
Remove Vertical Panel Cover-Lower (for ICM access)
Remove Vertical Panel Cover-Upper
Remove all cable strips (1)
Remove connector from the Interface Control Module
(ICM)
Disconnect both wires at the brake switch connector and
twist out (by hand) the brake switch at the brass coupling
Assemble all parts in the
Test functions of Brake Switch assembly
other directions
see Section B-1
see Section B-2
see Section B-4
see Section B-5
1
Version 1.0/May 2011
VECTRIX, LLC
