You are not allowed to reuse or distribute any part of this manual without prior permission. • For Open Source License information, refer to the “OpenSourceInfo.pdf” in the provided CD-ROM. PlanetFirst represents Samsung Electronics' commitment to the sustainable development and social responsibility through eco-driven business and management activities.
Page 3
Using the flash too close to your subject’s eyes can cause temporary or permanent damage. Handle and dispose of batteries and chargers with care • Use only Samsung-approved batteries and chargers. Incompatible batteries and chargers can cause serious injuries or damage to your camera. •...
Page 4
Health and safety information • Avoid using or storing your camera in dusty, dirty, humid, or poorly- ventilated areas to prevent damage to moving parts and internal components. • Remove the batteries from your camera when storing it for an extended period of time.
Page 5
Health and safety information Use only Samsung-approved accessories Using incompatible accessories may damage your camera, cause injury, or void your warranty. Protect your camera’s lens • Do not expose the lens to direct sunlight, as this may discolor the image sensor or cause it to malfunction.
Page 6
Indications used in this manual Icons used in this manual Icon Function Additional information Safety warnings and precautions Camera buttons. For example, [Shutter] represents the shutter button. Page number of related information The order of options or menus you must select to ►...
Contents Tips Concepts in Photography Shooting postures ... 10 Holding the camera ... 10 Standing photography ... 10 Crouching photography ... 11 Aperture ... 11 Aperture value and the depth of field ... 12 Shutter speed ... 13 ISO sensitivity ... 14 How the aperture setting, shutter speed, and ISO sensitivity control exposure ...
Page 8
Contents Shooting modes ... 39 t Smart Auto mode ... 39 P Program mode ... 40 Program Shift ... 40 A Aperture Priority mode ... 41 S Shutter Priority mode ... 41 M Manual mode ... 42 Framing Mode ... 42 Use a bulb ...
Page 9
Contents Metering ... 71 Spot ... 71 Link AE to AF Point ... 71 Center-weighted ... 72 Multi ... 72 Smart Range ... 73 OIS ... 74 OIS options ... 74 Exposure Compensation ... 75 Exposure/Focus Lock ... 76 Video functions... 77 Movie AE Mode ...
Page 10
Transfer files using Intelli-studio ... 109 Use Samsung RAW Converter ... 110 System Requirements for Windows ... 110 System Requirements for Mac ... 110 Use the Samsung RAW Converter Interface ... 111 Edit RAW format files ... 111 Chapter 6 Appendix Error messages ...
Concepts in Photography Shooting postures A correct posture for stabilizing the camera is necessary for taking a good photo. Even if you hold a camera correctly, the wrong posture can cause the camera to shake. Stand up straight and remain still to maintain a steady base for your camera.
Concepts in Photography Crouching photography Compose your shot, crouch with one knee touching the ground, and keep a straight posture. Aperture The aperture, a hole that controls the amount of light that enters the camera, is one of the three factors that determine the exposure. The aperture housing contains thin, metal plates that open and close to let light through the aperture and into the camera.
Concepts in Photography The size of the aperture is represented by a value known as an “F-number.” The f-number represents the focal length divided by the diameter of the lens. For example, if a lens with a 50 mm focal length has an f-number of F2, the diameter of the aperture is 25 mm.
Concepts in Photography Shutter speed Shutter speed refers to the amount of time it takes to open and close the shutter, and it is an important factor in the brightness of a photo, as it controls the amount of light which passes through the aperture before it reaches the image sensor.
Concepts in Photography ISO sensitivity The exposure of an image is determined by the sensitivity of the camera. This sensitivity is based on international film standards, known as ISO standards. On digital cameras, this sensitivity rating is used to represent the sensitivity of the digital mechanism that captures the image.
Concepts in Photography How the aperture setting, shutter speed, and ISO sensitivity control exposure The aperture setting, shutter speed, and ISO sensitivity are closely interconnected in photography. The aperture setting controls the opening that regulates the light that enters the camera, while the shutter speed determines the length of time that light is allowed to enter.
Concepts in Photography Correlation between focal length, angle, and perspective Focal length, which is measured in millimeters, is the distance between the middle of the lens to its focal point. It affects the angle and perspective of captured images. A short focal length translates into a wide angle, which allows you to capture a wide shot.
Concepts in Photography Depth of field Portraits or still-life photos mostly acclaimed by people are the ones on which the background is out of focus so the subject looks pronounced. Depending on the focused areas, a photo can be blurred or sharpened. This is called ‘a low DOF’...
Page 19
Concepts in Photography DOF depends on focal length The longer the focal length is, the lower the DOF gets. A telescope lens with a longer focal length than a telescope lens with a short focal length is better to take a photo of a low DOF. A photo taken with a 18 mm telescope A photo taken with a 100 mm telescope lens...
Concepts in Photography DOF preview You can use the Depth preview button to get an idea of what your shot will look like before shooting. When you press the button, the camera adjusts the aperture to the predefined settings and shows the results on the screen.
Concepts in Photography Using the rule of thirds will create photos with stable and compelling compositions. Below are a few examples. Photos with two subjects If your subject is in one corner of the photo, it creates an unbalanced composition. You can stabilize the photo by capturing a second subject in the opposite corner to balance the weight of the photo.
Concepts in Photography Flash Light is one of the most important components in photography. It’s not easy, however, to have an enough amount of light anytime and anywhere. Making use of a flash allows you to optimize light settings and create a variety of effects. Flash, also known as strobe or speed light, helps to create adequate exposure in low-light conditions.
Concepts in Photography Bounce Photography Bounce photography refers to the method of photography which redirects the light from the subject to the ceiling or walls so that the light spreads evenly. Normally, photos taken with flash may appear unnatural and cast shadows. Subjects in photos taken with bounce photography cast no shadows and look smooth due to evenly spread light.
My Camera Get started Unpack Check your product box for the following items. Camera USB cable Rechargeable battery Battery cradle/AC power cable (including the body cap, accessory shoe cover, and smart shoe cover) Software CD-ROM User manual Basic Operation Strap (User manual included) The illustrations may differ from your actual items.
My Camera Camera layout 1 2 3 4 Name Speaker Shutter button Jog dial • In Shooting mode: change the setting values of menus, adjust shutter speed in some shooting modes, and change the size of a focus area. • In Playback mode: enlarge or reduce a photo.
Page 27
Camera layout My Camera > Name Power switch E button (p. 92) • In Shooting mode: Lock the adjusted exposure value or focus. • In Playback mode: Protect the displayed file. Name Status lamp • Blinking: When saving a photo, shooting a video, sending data to a computer or printer.
Page 28
Camera layout My Camera > Name Smart shoe Connect an optional electronic viewfinder. Battery chamber cover Insert a memory card and battery. Tripod mount Display HDMI port Power adapter port Shutter release port Use a shutter release cable with a tripod to minimize camera movement.
My Camera Display icons In Shooting mode Capture photos 1. Shooting options (left) Icon Description Photo size Photo quality Focus area option Face detection Flash option* Flash intensity* Color space Smart range (p. 73) Optical Image Stabilization (OIS) (p. 74) * These icons appear when you attach an optional flash.
Display icons My Camera > In Playback mode View photos Mode Metering Flash Focal Length Information White Balance Picture Wizard Photo Size Date Icon Description Location information Volume RAW file Print information added to file (p. 103) Sound Picture file (p. 45) Protected file Folder number - File number 100-0001...
You can purchase optional lenses made exclusively for your NX series camera. Learn about the functions of each lens and select one that suits your needs and preferences. Lens layout SAMSUNG 20-50 mm F3.5-5.6 ED lens (example) Description Lens mount index Zoom lock switch...
Lenses My Camera > Lock or unlock the lens To lock the lens, pull and hold the zoom lock switch away from the camera body and rotate the zoom ring clockwise. To unlock the lens, rotate the zoom ring counter-clockwise until you hear the click.
Page 34
Lenses My Camera > SAMSUNG 18-55 mm F3.5-5.6 OIS lens (example) Description Lens mount index Zoom ring Focus ring (p. 64) Lens hood mount index Lens OIS switch (p. 74) AF/MF switch (p. 58) Lens contacts SAMSUNG 20 mm F2.8 lens (example) Description iFn button (p.
Lenses My Camera > Lens markings Find out what the numbers on the lens signify. SAMSUNG 50-200 mm F4-5.6 ED OIS lens (example) 3 4 5 Description Aperture value A range of supported aperture values. For example, F 1:4-5.6 means the maximum aperture value range from 4 to 5.6.
My Camera Optional accessories You can purchase additional accessories including flash, GPS module, and an electronic viewfinder that can help you take better and more convenient shots. For more information, refer to the manual for each accessory. The illustrations below may differ from the actual items. Flash layout Description READY lamp/Test button...
Optional accessories My Camera > Connect the flash by sliding it into the accessory shoe. Lock the flash into place by turning the accessory shoe fastening dial clockwise towards LOCK. Press the power button on the flash. GPS module layout Description Status lamp Power button...
Optional accessories My Camera > Attach the GPS module Remove the accessory shoe cover from the camera. Mount the GPS module by sliding in into the accessory shoe. Lock the GPS module into place by turning the accessory shoe fastening dial clockwise towards LOCK. Press the power button of the GPS module.
Optional accessories My Camera > Attach the electronic viewfinder Remove the accessory shoe cover and the smart shoe cover on the camera. Mount the electronic viewfinder on the accessory shoe (1) and smart shoe (2) of the camera. • Take caution not to damage the connector (3). Press [Power] (1) on the viewfinder and rotate the [Diopter adjustment dial] (2) to adjust the diopter to fit your eye- sight.
My Camera Shooting modes Two simple shooting modes—Smart Auto and Scene mode—help you take photos with numerous automatic settings. Additional modes allow for greater customization of settings. Icon Description Smart Auto mode (p. 39) Program mode (p. 40) Aperture Priority mode (p. 41) Shutter Priority mode (p.
Shooting modes My Camera > P Program mode The camera automatically adjusts shutter speed and aperture value so that an optimal exposure value can be achieved. This mode is useful when you want to take shots of constant exposure while being able to adjust other settings. Program Shift Program Shift function lets you adjust the shutter speed and aperture value while the camera maintains the same exposure.
Shooting modes My Camera > A Aperture Priority mode In Aperture Priority mode, the camera automatically calculates shutter speed according to the aperture value you choose. You can adjust the depth of field (DOF) by changing the aperture value. This mode is useful for taking portraits and landscape shots.
Shooting modes My Camera > M Manual mode Manual mode lets you adjust the shutter speed and aperture value manually. In this mode, you can fully control the exposure of your photos. This mode is useful in controlled shooting environments, such as a studio, or when it is necessary to fine-tune camera settings.
Shooting modes My Camera > Adjust the focus ring to select a scene. • You can also rotate the navigation button to select a scene. Scene Half-press [Shutter] or press [o] to save. Fully press [Shutter] to take the photo. Available scene modes (for 20-50 lens) : Beauty Shot, Portrait, Children, Backlight, Landscape, Sunset, Dawn, Beach &...
Shooting modes My Camera > Adjust the focus ring to select an option. • You can also rotate the navigation button to select an option. Half-press [Shutter] or press [o] to save. Fully press [Shutter] to take a photo. Available options Shooting mode Shutter speed Aperture value...
Shooting modes My Camera > s Scene mode In Scene mode, the camera selects the best settings for each type of scene. You can select a desired scene by pressing [f] in Shooting mode. Option Description Sound picture: Add voice memos before and after taking photos.
Page 47
Shooting modes My Camera > Option Description Text: Clearly capture text from printed or electronic documents Landscape: Capture still-life scenes and landscapes Sunset: Capture scenes at sunset, with natural-looking reds and yellows Dawn: Capture scenes at sunrise Beach & Snow: Reduce underexposed photos due to sunlight reflected from sand or snow Option...
Shooting modes My Camera > v Movie mode In Movie mode, you can shoot videos in High Definition (1280x720) and capture sound via the camera’s microphone. In order to adjust the exposure level, you can select Program in the Movie AE Mode options menu so that the aperture value can be automatically set or select Aperture Priority to manually set the aperture value.
Shooting modes My Camera > Available functions by shooting mode For details about shooting functions, see Chapter 2. Function Available in P/A/S/M/i/s/ Size (p. 50) v*/t P/A/S/M/i/s*/v Quality (p. 51) P/A/S/M ISO (p. 52) P/A/S/M/v White Balance (p. 53) P/A/S/M/v Picture Wizard (p.
Chapter Shooting Functions Learn about the functions you can set in Shooting mode. You can enjoy more customized photos and videos by using the shooting functions.
Shooting Functions Size As you increase the resolution, your photo or video will include more pixels, so it can be printed on larger paper or displayed on a larger screen. When you use a high resolution, the file size will also increase. Select a low resolution for photos that will be displayed in a digital picture frame or uploaded to the web.
RAW files have the file extension “SRW”. To adjust and calibrate exposures, white balances, tones, contrasts, and colors of the RAW files, or to convert them into JPEG or TIFF format, use the Samsung RAW Converter program found on the supplied CD-ROM. Ensure you have enough available memory to save photos in the RAW format.
Shooting Functions ISO sensitivity The ISO sensitivity value represents the sensitivity of camera to light. The larger the ISO value, the more sensitive the camera is to light. Consequently, by selecting a higher ISO sensitivity value, you can take photos in dim or dark places at faster shutter speeds. However, this may increase electronic noise and result in a grainy photo.
Shooting Functions White Balance (light source) The color of a photo depends on the type and quality of the light source. If you want the color of your photo to be realistic, select an appropriate lighting condition to calibrate the white balance, such as Auto WB, Daylight, Cloudy, or Tungsten, or adjust color temperature manually.
White Balance (light source) Shooting Functions > Option Description Color Temp.: Manually adjust the color temperature of the light source. Color temperature is a measurement in degrees Kelvin that indicates the specific type of light source. As the color temperature increases, the color distribution becomes cooler. Alternatively, as the color temperature decreases, the color distribution becomes warmer.
Page 56
White Balance (light source) Shooting Functions > Examples Auto WB Daylight Fluorescent Daylight Tungsten...
Shooting Functions Picture Wizard (photo styles) Picture Wizard lets you apply different photo styles to your photo to create various looks and emotional moods. You can also create and save your own photo styles by adjusting color, saturation, sharpness, and contrast for each style. There is no rule for which style is suitable in which conditions.
Shooting Functions Color Space Digital imaging devices such as digital cameras, monitors, and printers have their own methods for representing colors, which are called color spaces. Your camera lets you select two color spaces: sRGB or Adobe RGB. sRGB is widely used for creating colors on PC monitors and is also the standard color space for Exif.
Shooting Functions AF Mode Learn how to adjust the camera’s focus according to the subjects. You can select a focusing mode appropriate to the subject among Single Auto Focus, Continuous Auto Focus, and Manual Focus. The AF function is activated when you press [Shutter] halfway. In the MF mode, you have to rotate the focus ring on the lens to focus manually.
AF Mode Shooting Functions > Continuous AF While you are pressing [Shutter] halfway, the camera continues to automatic focusing. Once the focus area is fixed on the subject, the subject is always in focus even when moving. This mode is recommended for shooting a person on a bicycle, a running dog, or a car racing scene.
Shooting Functions AF Area The AF area function changes the positions of the focus area. Generally, cameras focus on the nearest subject. When there are a lot of subjects, however, unwanted subjects can be in focus. In order to prevent unwanted subjects from being in focus, change the focus area so that a desired subject is in focus.
AF Area Shooting Functions > Multi AF The camera displays a green rectangle in places where focus is set correctly. The photo is divided into two or more areas, and the camera obtains focus points of each area. It is recommended for scenery photos.
AF Area Shooting Functions > Self-Portrait AF It can be difficult to check whether your face is in focus when you are taking a self-portrait. When this function is on, the focus distance is set to close-up and the beep from the camera gets faster when in focus.
Shooting Functions AF Priority The camera takes a shot only if the focus is set correctly when you press [Shutter]. Turn on this function to always get a properly focused photo. Turn it off to take a photo regardless of focus. To set the focus In Shooting mode, press [m] priority,...
Shooting Functions MF Assist In the manual focus (MF) mode, you have to rotate the focus ring on the lens to focus manually. When you set the MF Assist function, you can achieve a clearer focus. This function is only available on a lens that supports manual focus.
Shooting Functions Drive (shooting method) You can set the shooting method such as Continuous, Burst, Timer and so on. Select Single to capture one photo at a time. Select Continuous or Burst to shoot fast moving subjects. Select AE BKT, WB BKT or P Wiz BKT to adjust exposure, white balance, or apply Picture Wizard effects.
Drive (shooting method) Shooting Functions > Burst Consecutively capture up to 10 shots per second (3 seconds), 15 shots per second (2 seconds), or 30 shots per second (1 second) when you press [Shutter] once. Recommended for shooting the rapid motion of fast moving subjects such as racing cars.
Drive (shooting method) Shooting Functions > AE BKT When you press [Shutter], the camera takes 3 consecutive shots: the original, one a step darker, and one a step lighter. Use a tripod to prevent blurry photos as the camera takes three shots continuously. You can adjust the settings in BKT Set menu.
Drive (shooting method) Shooting Functions > P Wiz BKT When you press [Shutter], the camera takes three consecutive shots, each with a different Picture Wizard setting. The camera takes a shot and applies the three Picture Wizard options you have set to the image taken.
flash fires a second time. • You can use the flash and adjust the amount of light only when you use the NX exclusive external flash. Use only Samsung-approved flashes. Using incompatible flashes may damage your camera. Ball moving direction Ball moving direction...
Flash Shooting Functions > Correct the red-eye effect If the flash fires when you take a photo of a person in the dark, a red glow may appear in the eyes. To prevent this, select Fill-in Red. Without red-eye correction Adjust the flash intensity Adjust the flash intensity to avoid overexposure or underexposure.
Shooting Functions Metering The metering mode refers to the way in which a camera measures the quantity of light. The camera measures the amount of light in a scene, and in many of its modes, uses the measurement to adjust various settings. For example, if a subject looks darker than its actual color, the camera takes an overexposed photo of it.
Metering Shooting Functions > Center-weighted The Center-weighted mode calculates a broader area than the Spot mode does. It sums up the amount of light in the center portion of the shot (60 ~ 80%) and that of the rest of the shot (20 ~ 40%). It is recommended for situations where there is a slight difference in brightness between a subject and a background or an area of the subject is large compared to the overall composition of the photo.
Shooting Functions Smart Range This function automatically corrects the loss of bright detail that can occur due to shading differences in the photo. Without Smart Range effect To set Smart In Shooting mode, press [f] Range options, an option. With Smart Range effect ►...
Shooting Functions Use the Optical Image Stabilization (OIS) function to minimize camera shake. OIS may not be available with some lenses. Came shake tends to occur in dark places or when shooting indoors. In such cases, the camera uses slower shutter speeds in order to increase the amount of light taken in, which can result in a blurry photo.
Shooting Functions Exposure Compensation The camera automatically sets the exposure by measuring the levels of light from the photo’s composition and the position of a subject. If the exposure set by the camera is higher or lower than you expected, you can adjust the exposure value manually.
Shooting Functions Exposure/Focus Lock When you cannot achieve an appropriate exposure because of a strong color contrast or you want to take a photo on which the subject is out of the auto focus area, lock the focus or exposure and then take a photo. To lock the exposure or focus, adjust the photo’s composition on which you want to focus or calculate the exposure, and then press [E].
Shooting Functions Video functions The functions available for video are explained below. Movie AE Mode Set the aperture value for shooting a movie. To set movie In Shooting mode, press [f] aperture options, an option. Option Description Program: The aperture value is adjusted automatically. Aperture Priority: Set the aperture value manually before recording a video.
Video functions Shooting Functions > Wind Cut When you record videos in noisy environments, unintended sounds can be recorded in videos. In particular, severe wind noise recorded in videos distracts you from enjoying your videos. Use the Wind Cut function to remove some surrounding noise in addition to wind noise. To set Wind Cut In Shooting mode, press [m] ►...
Playback/Editing Search and manage files Learn how to search photos and videos quickly through the thumbnail view and to protect and delete files. View photos Press [y]. • The most recent file you captured will be displayed. Rotate the navigation button or press [C/w] to scroll through files.
Search and manage files Playback/Editing > View files by category in Smart Album In the thumbnail view, press [m]. Select a category and press [o]. Option Description View files by the file type such as photo, video, or Type photo with a voice memo. Date View files by the date they were saved.
Search and manage files Playback/Editing > Delete multiple files You can select multiple files and delete them. ► In Playback mode, press [ Multiple Delete. • Alternatively, in Playback mode, press [m] ► Select. Rotate the navigation button or press [C/w], select files you want to delete and press [o].
Playback/Editing View photos Enlarge a photo You can enlarge photos when viewing them in Playback mode. You can also use the Trim function to extract the portion of the image displayed on the screen and save it as a new file. Magnified area Magnification (the maximum magnification may differ by...
View photos Playback/Editing > Highlight This function identifies the parts of a photo that are excessively bright. When you view a photo with highlight on, the excessively bright areas of the photo blink in blue. Original To set highlight In Playback mode, press [m] options, an option.
Playback/Editing Play a video You can play a video, capture an image from a video, or crop a video. Movie Size Date Pause Stop Video viewing controls Do this Press [C]. Rewind Scan backward in 2X, 4X, and 8X increments each time you press [C].
Play a video Playback/Editing > Capture an image during playback Press [o] at the point where you want to save a still image. Press [I]. • The resolution of the captured image is the same as the video resolution. • The captured file is saved as a separate file under a new name.
Playback/Editing Edit a photo Perform photo editing tasks, such as resizing, rotating, eliminating red- eye effects, and adjusting brightness, contrast, or saturation. Edited photos are saved as new files under different file names. To set Image Edit In Playback mode, press [m] options, an option.
Page 89
Edit a photo Playback/Editing > * Default Option Description Face Retouch: Hide facial imperfections. (Off*, Level 1, Level 2, Level 3) Smart Filter: Apply various filter effects to photos and create unique images. Off* Vignetting Miniature Fish-Eye Sketch Defog Halftone Dots Soft Focus The new file may be smaller than the original.
Chapter Camera settings menu Learn about the user settings and general settings menu. You can adjust the settings to better suit your needs and preferences.
Camera settings menu User settings You can set the user environment with these settings. To set user In Shooting mode, press [m] options, ISO Step You can set the size of the exposure adjustment in fractions of steps. 1/3 step is more subtle than 1 step. Auto ISO Range You can set the maximum ISO value under which each EV step is chosen when you set the ISO Auto.
User settings Camera settings menu > User Display You can add or remove shooting information from the display. Description Icons Set the shooting options icons on the display on or off. Grid Line Set the grid on the display on or off. (Off*, 2 X 2, 3 X 3, +, X) Histogram Set the histogram on the display on or off.
User settings Camera settings menu > Key Mapping You can change the function assigned to the AEL and Preview buttons. Button Function You can set the AEL button’s function. The AEL and AFL functions save the exposure value or focus area respectively when a photo is taken.
Camera settings menu Setting 1 Learn about the menu items of the Setting 1. To set Setting 1 In Shooting mode, press [m] options, Item Description Format the memory card. Formatting prepares a memory card for use in the camera and deletes all existing files including protected files.
Camera settings menu Setting 2 Learn about the menu items of the Setting 2. To set Setting 2 In Shooting mode, press [m] options, Item Description Set the Quick View time length – the amount of time the Quickview camera displays a photo immediately after you take it. (Off, 1 sec*, 3 sec, 5 sec, Hold) Adjust the display brightness, auto brightness setting, or display color.
Camera settings menu Setting 3 Learn about the menu items of the Setting 3. To set Setting 3 In Shooting mode, press [m] options, Item Description • Sensor Cleaning: Remove dust from the sensor. • Start-Up Action: When on, the camera performs sensor cleaning each time you turn it on.
• Body Firmware: Update the firmware of the camera body. • Lens Firmware: Update the firmware of the lens. • You can download firmware upgrades from www.samsungimaging.com or www.samsung.com. Firmware • You cannot run a firmware upgrade without a fully Update charged the battery.
Camera settings menu Setting 4 Learn about the menu items of the Setting 4. You should purchase an optional GPS accessory in order to use the GPS function. To set Setting 4 In Shooting mode, press [m] options, Item Description Set to take photos with location information using the Global Positioning System (GPS).
Page 99
Camera settings menu Setting 5 Learn about the menu items of the Setting 5. To set Setting 5 In Shooting mode, press [m] options, Item Description Correct lens distortion that might occur from lenses. Distortion This feature may not be available with some lenses. Correct (Off*, On) Set the functions to be displayed when you press...
Connect to external devices View files on a TV or HDTV Play back photos or videos by connecting your camera to a TV using the A/V cable. View files on a TV In Shooting mode or Playback mode, press [m] ►...
View files on a TV or HDTV Connect to external devices > View files on an HDTV In Shooting or Playback mode, press [m] ► HDMI Size an option. Connect the HDTV and the camera using the HDMI cable. If both A/V and HDMI cables are connected at the same time, the HDMI cable has the priority.
Connect to external devices Print photos Print photos on your camera by connecting to printers directly or saving Digital Print Order Format (DPOF) information on a memory card. Print photos with a photo printer (PictBridge) You can print photos with a PictBridge-compatible printer by connecting your camera directly to the printer.
Print photos Connect to external devices > Configure print settings Images One Photo Size Auto Layout Auto Type Auto Quality Auto Date Auto Print Exit Option Description Select whether to print the current photo or all Images photos. Size Specify the size of the print. Layout Create thumbnail prints.
Print photos Connect to external devices > DPOF options Option Description You can select photos to print and the number of copies for photos. • Select: Select the number of copies for photos you select. (Select photos you want to print number of copies by scrolling the jog dial left or right Standard and then pressing [f])
Connect to external devices Transfer files to your computer Transfer files on a memory card to your computer by connecting the camera to the PC. Transfer files to your computer (for Windows) Transfer files by connecting the camera as a removable disk You can connect the camera to your computer as a removable disk.
Transfer files to your computer Connect to external devices > Disconnect the camera (Windows XP) The way to disconnect the USB cable for Windows Vista and 7 is similar. Ensure that no data is being transferred between the camera and the PC. •...
Use the included software to transfer files from the camera to your PC. You can also edit photos and upload them on web. Insert the CD-ROM into your PC. When the setting wizard appears, click Samsung Digital Camera Installer. Select a program you want to install and click Install.
Edit photos on a PC Connect to external devices > System Requirements Item Requirements Windows XP SP2/Vista/7 Intel ® Pentium ® 4, 3.2GHz or higher/AMD Athlon™ FX, 2.6GHz or higher Minimum 512MB RAM (1GB and above recommended) Hard disk capacity 250MB or more (1GB or more recommended) •...
Edit photos on a PC Connect to external devices > Description View files of the selected folder on your computer. Show or hide files of the connected camera. View files of the selected folder on the camera. View files as thumbnails, in Smart Album, or on a map. Browse folders in the connected device.
RAW files are not transformed to JPEG formats and are stored in the memory without any changes. With Samsung RAW Converter, you can calibrate exposures, white balances, tones, contrasts, and colors of photos.
Open/Close the fine adjustment window for the editing tools. Edit RAW format files If you edit the RAW format files with the Samsung RAW Converter, you can maintain high image quality. You can also edit JPEG and TIFF format files.
Page 113
Edit photos on a PC Connect to external devices > Adjust the exposure with the scroll bar. Original image P Mode, Aperture: f=8, Shutter Speed: 1/15 sec, ISO=100 Original image To adjust the contrast of an image Select File From the editing tools, select Adjust the tone with the scroll bar.
Page 114
Edit photos on a PC Connect to external devices > To save RAW files in JPEG or TIFF formats ► Select File Open file and open a file. ► Select File Development. Select a file format (JPEG or TIFF) and select Save.
Appendix Error messages When the following error messages appear, try these remedies. Error messages Suggested remedies The lens is locked. Rotate the lens counter- Lens is locked clockwise until you hear a click. (p. 32) • Turn off your camera and then turn it on again. •...
Appendix Maintain the camera Clean the camera Camera lens and display Use a brush to remove dust and wipe the lens gently with a soft cloth. If any dust remains, apply lens cleaning liquid to a piece of cleaning paper and wipe gently.
Maintain the camera Appendix > About memory card Supported memory card You can use SD or SDHC memory cards. Terminal Write-protect switch Label (front) You can prevent files from being deleted by using the write-protect switch on an SD or SDHC card. Slide the switch down to lock or slide it up to unlock.
Approx. 210 min/Approx. 420 photos Videos Approx. 130 min • The figures above are based on Samsung’s test standards. Your results may differ depending on your actual usage. • Available shooting time differs depending on background, shooting interval, and use conditions.
About the battery Appendix > Notes about charging the battery • If the indicator light is off, make sure that the battery is inserted correctly. • When the battery is completely discharged, charge it at least 10 minutes before using it with your camera. •...
Page 122
About the battery Appendix > • Use only authentic, manufacturer-recommended, Lithium-ion replacement batteries. • Do not disassemble the battery or puncture the battery with any sharp object. • Avoid exposing the battery to high pressure or crushing forces. • Avoid exposing the battery to major impacts, such as dropping it from high places.
Appendix Before contacting a service center If you are having trouble with your device, try these troubleshooting solutions before contacting a service professional. Give other accessories, such as memory card and battery when requesting a warranty service. Situation Suggested remedies •...
Page 124
Before contacting a service center Appendix > Situation Suggested remedies If you change the name of a file, your camera may not play the file (the name of the file should Cannot display files meet the DCF standard). If you encounter this situation, display files on your computer.
Page 125
Before contacting a service center Appendix > Situation Suggested remedies • Subject is not in focus. When the subject is outside the AF area, shoot by moving the subject inside the AF area and half pressing the shutter. Auto Focus does not •...
Effective pixels Approx. 14.6 mega-pixels Total pixels Approx. 15.1 mega-pixels Color filter RGB primary color filter Lens Mount Type Samsung NX Mount Available lens Samsung lenses Image Stabilization Type Lens shift (depends on lens) Mode OIS mode1 / mode2 Distortion Correct...
Page 127
White Balance Bracket, Picture Wizard Bracket Self-timer 2 ~ 30 s (1 second interval) Shutter release SR9NX01 (optional) Flash Optional Samsung external flashes: External flash SEF15A, SEF20A, SEF42A Syncro Accessory shoe (Hot shoe) White Balance Auto WB, Daylight, Cloudy, Fluorescent White, Fluorescent NW,...
Page 128
Camera specifications Appendix > JPEG only Sound picture Recordable time (before and after shooting, 5 or 10 seconds respectively) • JPEG (3:2): 14M (4592x3056), 10M (3872x2592), 6M (3008x2000), 2M (1920x1280), 1.4M (1472x976, Burst mode only) • JPEG (16:9): 12M (4592x2584), 8M (3872x2176), 5M (3008x1688), Size 2M (1920x1080)
Page 129
282 g (without battery and memory card) Operating Temperature 0 ~ 40 °C Operating Humidity 5 ~ 85 % Software Intelli-studio, Samsung RAW Converter * This specifications can change without notice to upgrade a performance. * Other brands and products names are trademarks of respective owners.
Appendix Lens specifications Lens Name SAMSUNG 20-50 mm F3.5-5.6 ED Focus Length 20 ~ 50 mm (equivalent to 30.8 ~ 77 mm in 35 mm format) 9 elements in 8 groups Elements in Group (1 aspheric lens, 1 low dispersive lens included) Angle of View 70.2°...
Page 131
Lens specifications Appendix > Lens Name SAMSUNG 30 mm F2 30 mm (equivalent to 46.2 mm in Focus Length 35 mm format) 5 elements in 5 groups Elements in Group (1 aspheric lens included) Angle of View 50.2° F2 (minumum: F22),...
You can purchase additional battery packs. • These illustrations may differ from your actual items. Refer to the user manuals of these optional accessories for details. • Use only Samsung-approved accessories. Samsung is not responsible for damage caused by using another manufacturer’s accessories.
Appendix Index Aperture 11, 15 Depth of Field (DOF) 12, 17 Auto focus 58 Digital Print Order Format (DPOF) 103 Drive (see Shooting method) 65 Battery life 119 specifications 119 Exposure Value (EV) 12, 75 Bracketing 65, 67 Fader 77 Camera Files connecting as removable disk 105...
Page 134
Index Appendix > Red-eye effect 70 Timer 66 Rule of thirds 19 Videos options 77 Samsung RAW Converter 110 viewing 85 Shooting method 65 Shooting modes Aperture Priority 41 Auto focus (AF) 58 Lens Priority 42 Manual 42 Movie 47...
Page 135
Appendix Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life.
Declaration of Conformity Trade Name : Samsung Electronics America, Inc. Model No. : Samsung NX100 Responsible Party : Samsung Electronics America, Inc. Address : 85 Challenger Road, Ridgefield Park, NJ 07660 Telephone No. : 1-800-SAMSUNG (726-7864) This device complies with Part 15 of the FCC Rules.
Page 137
Please refer to the warranty that came with your product or visit our website http://www.samsungimaging.com/ or http://www.samsung.com/ for after-sales service or inquiries.
