ENGLISH
66085 / 01
Required tools
Ruler
Phillips screwdriver
Additional tools
(depending on application)
Hammer
Wood block
USA: 1-800-677-5625 • Canada : 1-800-501-9471
www.weiserlock.com
Parts in the box
Latch with
Drive-in latch
rectangular faceplate
A
B
Mounting plate
Interior assembly
G
H
Latch screws
Strike screws
Q
N
P
W
03809
Strike
assembly
C
D
Battery pack
Interior cover
J
K
Mounting plate screws
R
S
SL03031011
48654
1 / 11
Installation and
Adapter ring
Keys
E
Batteries
SmartKey tool
L
M
Interior assembly
Interior cover
screws
screws
U
49191
Note: Part numbers are printed on screw bags.
© 2017 Spectrum Brands, Inc.
User Guide
F
V
64109
Advertisement
Table of Contents
Related Manuals for Weiser PREMIS
Summary of Contents for Weiser PREMIS
- Page 1 Installation and ENGLISH User Guide 66085 / 01 Required tools Parts in the box Ruler Latch with Drive-in latch Strike Exterior Adapter ring Keys rectangular faceplate assembly Phillips screwdriver Additional tools Mounting plate Interior assembly Battery pack Interior cover Batteries SmartKey tool (depending on application) Hammer...
- Page 2 Prepare the door and check dimensions If drilling a new door, use the supplied template and the complete door drilling instructions available at www.weiserlock.com/doorprep. Measure to confirm that the hole in the door Measure to confirm that the backset is is either 2-1/8"...
- Page 3 Install the latch and strike Is the door edge chiseled? Hold the latch in front of the door hole, with the latch Which latch are you installing? face flush against the door edge. Latch “A” Latch “B” chiseled chiseled Use latch “A”. If the Use latch “B”.
- Page 4 Install the exterior assembly What is the diameter of the hole in the door? Install exterior assembly and mounting plate. Diameter is 2-1/8" (54 mm) Diameter is 1-1/2" (38 mm) Cable goes Support exterior underneath assembly during latch. mounting plate installation.
- Page 5 Install the interior assembly Remove battery cover and battery pack from interior assembly. Make sure Remove Remove turnpiece is in the interior cover. battery pack. vertical position. vertical Do not install batteries yet. Connect cables and install interior assembly. Secure with Push turnpiece shaft screws.
- Page 6 If the touchscreen indicates a failure, peform the manual door handing procedure on page 10. If the door handing process is still unsuccessful, consult the online User Guide at www.weiserlock.com/support/guides/premis-user. USA: 1-800-677-5625 • Canada : 1-800-501-9471 www.weiserlock.com 6 / 11...
- Page 7 If desired, the lock may be re-keyed to work with your existing key. See the supplied SmartKey Re-key instructions for more information. Download the Premis app and pair your lock to your phone Download the Premis app from the App Store.
- Page 8 When you are within Bluetooth range of your lock, you can use Siri commands to lock and unlock your door. Make sure your phone is unlocked, and refer to your lock by the name you assigned to it inside the Premis app.
- Page 9 The Status LED blinks every 6 seconds on lock interior to communicate whether the door is locked or unlocked, or if the batteries are low. The Status LED may be turned off inside the Premis app. Note: During the pairing process, the Status LED will flash red and green, followed by a short beep (if the lock's sound is not muted).
- Page 10 • Remove all user codes that were programmed directly at the lock. • Disable Auto-Lock. • Turn on the Status LED if it was turned off inside the Premis app. • Re-enable SecureScreen if it was disabled inside the Premis app.
- Page 11 Troubleshooting A complete troubleshooting guide is located in the online Premis User Guide at www.weiserlock.com/support/guides/premis-user. Important Safeguards • Protect your user codes and mastercode. • Familiarize yourself with all warning and caution statements. • Remind all family members of safety precautions.
