Topcon rl-h3c Instruction Manual

RL-H3C package
Instrument
Level Sensor LS-70C
Bracket, Holder-6
Dry batteries (C-cell)
Carrying case
Instruction Manual
Optional accessories
• Standard rechargeable batteries and charger can be used
as power option for the RL-H3C
• Grade plate adapter
• Elevating tripod, wall mount etc
SPECIFICATIONS
RL-H3C
1 pc.
Accuracy
1 pc.
Working range (Ø)
4 pc.
Rotation speed
1 pc.
Laser source
1 vol.
Operating time
Water-/dustproof
Operating temperature
Weight
SPECIFICATIONS
Beam detection
High precision
Normal precision
Detection indication
Power supply
Auto shut-off delay
Operating temperature
Weight
Your Topcon dealer
TOPCON EUROPE B.V.
http: //www.topconeurope.com
Item number: 5410231
Language: English
Printed: 09-2002
RL-H3C Laser
± 15"
± 300 m
600 (rpm)
Visible LD
± 60 hrs
IP 56
-20ºC~+50ºC
1,9 kg
LS-70C Handreceiver
50 mm
± 1 mm
± 2 mm
Liquid crystal andBuzzer
DC 9V, ± 80 hrs
± 30 min.
-20ºC~+50ºC
0,25 kg
Certificatie No. 03682548
TOPCON EUROPE B.V.
Capelle a/d IJssel, The Netherlands
RL-H3C GENERAL
CONSTRUCTION
LASER
2002
