- Page 1 INSTALLATION, USE AND MAINTENANCE MANUAL Brio ESPRESSO INSTANT English DOC. NO. H 075U 03 EDITION 2 01 01...
- Page 3 DICHIARAZIONE DI CONFORMITA’ DECLARATION OF CONFORMITY DÉCLARATION DE CONFORMITÉ KONFORMITÄTSERKLÄRUNG DECLARACIÓN DE CONFORMIDAD DECLARAÇÃO DE CONFORMIDADE VERKLARING VAN OVEREENSTEMMING INTYG OM ÖVERENSSTÄMMELSE OVERENSSTEMMELSESERKLÆRING Valbrembo, 04/09/2000 Dichiara che la macchina descritta nella targhetta di identificazione, è conforme alle disposizioni legislative delle direttive: 89/392, 89/336, 73/23 CEE e successive modifiche ed integrazioni.
-
Page 5: Table Of Contents
ADJUSTING THE SETTING OF THE COFFEE UNIT PISTON STROKE PAG. 12 WATER TEMPERATURE CONTROL PAG. 12 ADJUSTING THE GRADE OF GRINDING PAG. 12 ADJUSTING THE COFFEE DOSE PAG. 13 CUP SENSOR PAG. 13 © by NECTA VENDING SOLUTIONS SpA 0101 Brio C-I... - Page 6 Product code Serial number Model Frequency Type Operating voltage Current Absorbed power Water mains characteristics Boiler data © by NECTA VENDING SOLUTIONS SpA 0101 Brio C-I...
-
Page 7: Technical Specifications
Frequency sonnel at least once a year. Installed power - Espresso - Instant © by NECTA VENDING SOLUTIONS SpA 0101 Brio C-I... - Page 8 - Overflow solenoid valve (only with water supply from from a point of view of both electrical safety and health the mains) regulations. - Liquid waste container float - Instant boiler anti-boiling thermostat (instant models) © by NECTA VENDING SOLUTIONS SpA 0101 Brio C-I...
- Page 9 Some parts of the machine can be damaged by strong detergents. © by NECTA VENDING SOLUTIONS SpA 0101Brio C-I...
- Page 10 In order to speed up the sanitising operations, the machine is supplied with spares to replace the parts to be cleaned. 0101Brio C-I © by NECTA VENDING SOLUTIONS SpA...
- Page 11 - After disinfection thoroughly rinse all components to ensure that all residue of the solution is removed. © by NECTA VENDING SOLUTIONS SpA 0101Brio C-I...
- Page 12 1 - Sugar dispensing spout coffee until the empty condition is indicated. 2 - Pin 3 - Flexible lever - completely empty the water system using the special 4 - Return spring clamps. 0101Brio C-I © by NECTA VENDING SOLUTIONS SpA...
- Page 13 - open the tap and switch the machine on. INSERTING THE LABELS The menu and instruction labels are supplied with the machine and must be inserted at the time of installation (see "selection dose" table). © by NECTA VENDING SOLUTIONS SpA 0101 Brio C-I...
- Page 14 All operations requiring the machine to be energized with the door open should be carried out with the door switch key inserted, and therefore by qualified per- sonnel informed about the specific risks of such situation. 0101 Brio C-I © by NECTA VENDING SOLUTIONS SpA...
-
Page 15: Standard Settings
- coffee temperature (at the spout) approx. 85÷89° C; - instant product temperature (at the spout) approx. 75° C; The machine standard settings assign the same price, expressed in number of basic units, to all selections © by NECTA VENDING SOLUTIONS SpA 0101 Brio C-I... - Page 16 4 - Dose adjusting lever 5 - Reference notches - tightening will increase the temperature; - loosening will decrease the temperature; - the temperature varies by approx. 1° C every 2 turns. 0101 Brio C-I © by NECTA VENDING SOLUTIONS SpA...
-
Page 17: Cup Sensor
To refit the coffee unit, pay special attention to the 1 - Green LED piston position. Reference notches on the external 2 - Red LED disk and on the unit case should match (see Fig. 18). 3 - Adjustment trimmer © by NECTA VENDING SOLUTIONS SpA 0101 Brio C-I... -
Page 18: Operating Modes
"Cup" Cup present "Take the drink" Drink ready When pressing a pre-selection button for sugar, the messages "Sugar" or "Extra sugar" are displayed for a few seconds. 0101 Brio C-I © by NECTA VENDING SOLUTIONS SpA... -
Page 19: Programming
The following functions are also available: - failure reset; - machine installation; - statistics display; - statistics printout - statistics reset. © by NECTA VENDING SOLUTIONS SpA 0101 Brio C-I... -
Page 20: Displaying The Present Failures
The machine will lock if the boiler fails to reach the operating temperature after 10 minutes (Espresso mod- els) or 20 minutes (Instant models) of heating from the machine start, or from the last selection. 0101 Brio C-I © by NECTA VENDING SOLUTIONS SpA... -
Page 21: Setting The Water
Press the confirm button " " from the "programming" The machine default configuration is with menu to access the price list, which can be scrolled with water supply from the mains. the “ ” and “ ” buttons. © by NECTA VENDING SOLUTIONS SpA 0101 Brio C-I... -
Page 22: Setting The Machine Code
N.B.: The counters are set to zero by default; Press the confirm button " ", the message "Working" is displayed for a few seconds and the statistics are reset. With the counters set to zero, this function is disabled. 0101 Brio C-I © by NECTA VENDING SOLUTIONS SpA... -
Page 23: Programmer
CONFIGURATION CONFIG. END Exit from the configuration menu 1 - Connector The software starts again from address 0000 2 - Programmer holder (as when the machine is started) 3 - Programmer © by NECTA VENDING SOLUTIONS SpA 0101 Brio C-I... -
Page 24: Maintenance
Check that the handle pin of the ratiomotor is correctly stainless steel and varnished surfaces should be kept engaged in its seat. clean by using mild detergents (solvents must not be used). Never use water jets to clean the machine. 0101 Brio C-I © by NECTA VENDING SOLUTIONS SpA... -
Page 25: Annual Sanitising
2 - Boiler connecting hose 3 - Unit securing knob 4 - Upper piston snap ring 5 - Lower piston snap ring 6 - Reference notches 7 - Ratiomotor handle pin © by NECTA VENDING SOLUTIONS SpA 0101 Brio C-I... -
Page 26: Printed Board Functions And Indicator Lights
512 Kb and 1 Mb EPROMs by setting jumpers JS3 and JS4. To correctly configure a board in case of replacement or to change the machine performance, refer to the following tables and to the selection dose table. 0101 Brio C-I © by NECTA VENDING SOLUTIONS SpA... - Page 27 Minidips which are not mentioned are to be set to OFF. CONFIGURING THE MODEL According to the model, minidip 5 and the jumper (see Fig. 21) shall be set as follows: © by NECTA VENDING SOLUTIONS SpA 0101 Brio C-I...
- Page 28 2 - Air-break 7 - Coffee unit 3 - Mechanical filter or softener cartridge (optional) 8 - Boiler 4 - Volumetric counter 9 - Liquid waste container float 5 - Vibration pump 0101 Brio C-I © by NECTA VENDING SOLUTIONS SpA...
- Page 29 1 - Water inlet solenoid valve 2 - Boiler 3 - Float 4 - Instant product solenoid valve 5 - Safety thermostat (manual reset) 6 - Anti-boiling thermostat (manual reset) 7 - Liquid waste container float © by NECTA VENDING SOLUTIONS SpA 0101 Brio C-I...
- Page 30 5 - To the machine 1 - Water tank 6 - Coffee grounds bag 2 - Water softener (optional) 7 - Liquid waste container 3 - Water supply pump 4 - Mechanical filter 0101 Brio C-I © by NECTA VENDING SOLUTIONS SpA...
-
Page 31: Programming Menu
Price N.1 XXXX - 1 Price N. 8 PREVIOUS FUNCTION/ DECREASE DATA UNIT (-1) Set Prices/Sel. NEXT FUNCTION/ INCREASE DATA UNIT (+1) DELETE DATA/ EXIT FUNCTION CONFIRM DATA/ CONFIRM FUNCTION CHANGE DATA 0101 Brio C-I © by NECTA VENDING SOLUTIONS SpA... - Page 32 Line F XXXX PREVIOUS FUNCTION/ Initialising Confirm ? Working DECREASE DATA UNIT (-1) NEXT FUNCTION/ INCREASE DATA UNIT (+1) DELETE DATA/ EXIT FUNCTION Machine code CONFIRM DATA/ CONFIRM FUNCTION CHANGE DATA © by NECTA VENDING SOLUTIONS SpA 0101 Brio C-I...
- Page 33 NEXT FUNCTION/ INCREASE DATA UNIT (+1) blinking. DELETE DATA/ The password is equal to EXIT FUNCTION the sequence "4", "2", "3" CONFIRM DATA/ and "1". CONFIRM FUNCTION CHANGE DATA 0101 Brio C-I © by NECTA VENDING SOLUTIONS SpA...
- Page 34 Price 1 XXXX Statistic N. 2 Price 8 XXXX PREVIOUS FUNCTION/ DECREASE DATA UNIT (-1) NEXT FUNCTION/ INCREASE DATA UNIT (+1) DELETE DATA/ EXIT FUNCTION CONFIRM DATA/ CONFIRM FUNCTION CHANGE DATA DISPLAY STATISTICS © by NECTA VENDING SOLUTIONS SpA 0101 Brio C-I...
- Page 35 N. 11 - Coffee release In Service PREVIOUS FUNCTION/ DECREASE DATA UNIT (-1) NEXT FUNCTION/ INCREASE DATA UNIT (+1) DELETE DATA/ EXIT FUNCTION CONFIRM DATA/ CONFIRM FUNCTION CHANGE DATA DISPLAY STATISTICS 0101 Brio C-I © by NECTA VENDING SOLUTIONS SpA...
- Page 36 WIRING DIAGRAM LEGEND CODE DESCRIPTION CODE DESCRIPTION BDV COIN MECH CONNECTORS DOSING DEVICE MOTOR - SUGAR LIQUID WASTE TRAY SWITCH MF1-.. WHIPPER MOTOR GENERAL COUNTER FRESH-BREW MOTOR CM1-2 MICROSWITCH FOR BREW UNIT MOTOR PRESH BREW PISTON MOTOR CUP TRAY MICROSWITCH CUP RELEASE MOTOR CMCB CUP CONTAINER MOTOR MICROSW.
- Page 39 The Manufacturer reserves the right to modify, without prior notice, the characteristics of the equipment described in this publication; and further declines to accept any responsibility for any inaccuracies contained in this publication which can be ascribed to printing and/or transcription errors. All instructions, drawings, tables and information contained in this publication are confidential and can neither be reproduced completely or in part, nor be transmitted to third parties without the written permit of the Manufacturer, who has the sole ownership.
