10.4 NSG 438 system error messages

Nr. Text
006 INTERLOCK OPEN
115 EUT FAILURE
125 HV SUPPLY
TIMEOUT
126 HV HOLD
TIMEOUT
127 HV FAULT
129 A FIELD IS
SELECTED
201 HV INTERNAL
DISCHARGE
Explanation
The "Interlock-circuit"
is open.
The connected EUT has
signaled a fault.
The HV capacitor in the
pulse network cannot
be loaded in the speci-
fied time.
Unit stops after 30 s
without discharge.
An internal fault on the
processor board has
been detected.
The "Run" or the "HV-on"
key has been pressed
although an operator
field is still selected.
During test, an internal
discharge has been
detected.
Action
Press "Interlock Reset" button, or
close the interlock circuit at the
back of the base unit.
EUT input has been activated. Re-
set EUT first and then press return
on screen.
HV voltage module has detected
some losses. Switch off the base
station wait for 10 s, switch on
again.
Press return on screen. Restart
the test.
Switch off the base station wait for
10 s, switch on again and continue
testing. If error persists, contact
your nearest Teseq service centre.
Finish the input in the operator field
and then start with "Run".
Press return on screen and trigger
again. If error persists, contact
your nearest Teseq service centre.
