1
NSG 435 ESD SIMULATOR
USER MANUAL
Instructional Video & More At
601-131H

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NSG 435 and is the answer not in the manual?

Questions and answers

Related Manuals for Teseq NSG 435

Summary of Contents for Teseq NSG 435

  • Page 1 NSG 435 ESD SIMULATOR USER MANUAL Instructional Video & More At 601-131H...
  • Page 2 NSG 435 ESD SIMULATOR USER MANUAL NSG 435 ESD simulator...

  • Page 3: Table Of Contents

    CONTENTS General Explanation of the symbols used in this manual Safety Introduction Electrostatic discharge (ESD) Simulation Effects on the EUT NSG 435 System descritpion The simulator 3.2.1 Function modules 3.2.2 Block diagram 3.2.3 Operating elements System components 3.3.1 Basic set 3.3.2...
  • Page 4 Air/Contact-discharge Voltage Polarity Repetition frequency Counter Preselect counter 5.10 Automatic polarity switching 5.11 Continuous operation 5.12 Storing voltage settings Test procedures Standard-conforms procedures Other conditions Verification of the pulse data Maintenance Servicing Calibration Exchanging the R/C network 8.3.1 Derating of pulse repetition at increased capacitance Repairs Disposal Declaration of Conformity CE...

  • Page 5: General

    1 GENERAL 1.1 Explanation of the symbols used in this manual Please take note of the following explanations of the symbols used in order to achieve the optimum benefit from this manual and to ensure safety during operation of the equipment. The following symbol draws your attention to a circumstance where non- observation of the warning could lead to inconvenience or impairment in the performance.

  • Page 6: Safety

    The NSG 435 simulator is not a toy! It is a professional tool and belongs only in the hands of specialists and appropriately trained personnel. When powered by its own batteries the simulator can be active even without any power cable being connected.
  • Page 7 Return a damaged simulator to a Teseq service centre immediately for repair. Teseq AG Luterbach, Switzerland and the associated sales organizations accept no responsibility for personal or material damage nor for any consequential...

  • Page 8: Introduction

    The high equalizing current that flows, and the associated large electromagnetic field that hence results, can cause electronic devices (computers, terminals, process controllers, vehicle electronics, solid state devices, credit or memory cards, etc.) to malfunction or even be destroyed. NSG 435 ESD simulator...

  • Page 9: Simulation

    2.2 Simulation A systematic investigation of electronic equipment and installations to deter- mine their electromagnetic compatibility (EMC) is, today, a necessity if one is not prepared to suffer the economic disadvantages that could otherwise ensue. As a logical consequence, appropriate testing is now a legal requirement for the sale of electronic products within the EC.
  • Page 10 The ESD simulator NSG 435 fulfils the requirements of various applications in an ideal manner: Ergonomic shape For nontiring use Operation Operating elements and display always in view of the user. Constant check on the test values. Battery-powered Independence from a mains power feed.

  • Page 11: Effects On The Eut

    MOS or other components ESD testing usually shows up all the weak spots in the HF-range of a piece of equipment simultaneously. The uses to which the NSG 435 simulator can be put hence go way beyond those called for in standard-conform applications.

  • Page 12: Nsg 435

    Thanks to its battery pack, the NSG 435 offers optimal freedom of movement around the workplace and is an ideal test instrument not just for the deve- lopment engineer but also for quality control purposes, system tests and for investigations in the field.

  • Page 13: The Simulator

    3.2 The simulator 3.2.1 Function modules The NSG 435 simulator is modularly constructed from a number of function units that are all housed in a multi-part, molded shell. Control section µ-processor, HV-generator keypad, display and remote discharge network trigger connection (exchangeable) measuring electronics...

  • Page 14: Block Diagram

    The battery charge state is continuously monitored. A tendency towards low voltage is shown on the display. The instrument’s functions are inhibited once the battery voltage is insufficient to guarantee the pulse parameters. NSG 435 ESD simulator...

  • Page 15: Operating Elements

    Apart from the trigger button itself (pulse triggering) all the operating elements are on the surface of the instrument that faces the operator. The NSG 435 is switched on/off with the main switch. The significance of the elements in the display field can be seen in the following picture.
  • Page 16 Single discharge Repetitive discharge at 0.5, 1, 5, 10, 20, 25 Hz for air-discharge Repetitive discharge at 0.5, 1, 5, 10 Hz for contact-discharge Automatic polarity switching Storage of programmed test levels Resets the counter Return from second function NSG 435 ESD simulator...

  • Page 17: System Components

    The basic set is packed in a practical carrying case and comprises: Carrying case 42 x 32 x 13.5 cm (16.5 x 12.5 x 5.5 ” approx.) ESD simulator NSG 435 with battery-pack and 150 pF/330 Ω discharge network conforming to IEC/EN 61000-4-2, Ed. 1.2:2001...

  • Page 18: Charging Unit/Battery-Pack

    Charging of the battery takes about 1 hour. For further details please refer to separate manual. The battery has to be removed from the NSG 435 for charging via the jack con- nector. One charge is sufficient for several days of normal test operation.

  • Page 19: Options

    It is not per- missible to operate the NSG 435 with a power supply unit from another system. The power supply unit can be used on all common AC mains supplies without...

  • Page 20: Discharge Networks

    The protective earth connection does not replace the earth cable for the opera- tion of the NSG 435. To ensure safe and valid test operation the earth cable must be correctly connected as the pulse return path in every case.

  • Page 21: Remote Triggering

    The normal remote trigger unit consists of a «triggerbox» and 5 m (197 “) of optical cable. The remote trigger works in parallel with the «trigger-button» on the NSG 435. Pulse triggering, or the on/off switching in the case of repetitive discharges, can be effected by a push-button or an electrical signal applied to the triggerbox.

  • Page 22: Measurement Adapters

    (see section 7). MD 103 MD 103 («Pommerenke» target) is a more advanced coaxial measuring target with flat response characteristics up to the multi-GHz range. It may be used instead of MD 101. NSG 435 ESD simulator...

  • Page 23: Commissioning

    Take the necessary safety precautions Charge the battery (see section 3.3.2) Connect the earth cable correctly (The NSG 435 must never be switched on without an earth cable being connected) Allow the instrument to dry out if any condensation has occurred 4.2 Function check...
  • Page 24 By bringing the test finger close to the earthing point an discharge occurs which is acknowledged acoustically and the display shows the effective discharge voltage in a frame. (This applies under the following conditions: air-discharge, single-pulse, preselect counter off). The instrument is now ready to use. NSG 435 ESD simulator...

  • Page 25: Operation

    5 OPERATION 5.1 General This section provides a guide through the numerous setting possibilities of the NSG 435. The operation, which is strictly logical and hierarchically arranged, is easy to remember. The display shows unmistakable information about the parameters that have been set and the operating status of the simulator.
  • Page 26 In the case of a contact-discharge this measurement is not carried out since only a discharge current can occur. The instrument switches itself off automatically after a period of 30 minutes of non-use although the parameters that have been set will remain stored in memory. NSG 435 ESD simulator...

  • Page 27: Battery Monitor

    5.3 Battery monitor The battery charge state is monitored continuously. An insufficiently charged or empty battery is indicated on the display. «LOW BAT» blinks: Change or charge the battery soon. The in- struments functions and the pulse data are still assured. «LOW BAT» steady: Battery empty.

  • Page 28: Air/Contact-Discharge

    When working with fixed voltage levels, the relevant value is automatically loaded upon toggling between the air/contact-discharge mode. The corresponding test finger must, of course, be attached to suit the particular discharge mode: Air-discharge = rounded test finger Contact-discharge = pointed test finger NSG 435 ESD simulator...

  • Page 29: Voltage

    5.5 Voltage Press F2 to branch into the submenu for voltage setting. Some of the other buttons take on different functions as shown on the display: Free setting Call stored values level 1-4 (4 values each for air-discharge and contact discharge) Pressing F1 or F2 raises or lowers Press F3 to select the four stored the voltage respectively in steps of...

  • Page 30: Polarity

    Press F5 to return to the starting menu level. (This return will also be made automatically after about 10 s). 5.6 Polarity F3 toggles between positive and negative polarity. The sign shown in the display alters correspondingly. NSG 435 ESD simulator...

  • Page 31: Repetition Frequency

    5.7 Repetition frequency Use F4 to scroll from SINGLE (single discharges) through all the possible frequen- cies for repetitive discharges: 0.5/1/5/10/20/25 Hz for air-discharge 0.5/1/5/10 Hz for contact-discharge In the SINGLE mode a discharge is released each time the trigger button is pressed.

  • Page 32: Preselect Counter

    A specified number of discharges (0...9999) can be pre-programmed with this function. These can then be triggered single by hand or automatically. F5 first resets the counter then, when pressed a second time, branches into the preselect counter menu. NSG 435 ESD simulator...
  • Page 33 F3 switches the preselect counter operation on and off (PRESELECT ON/OFF). Use F1 and F2 to raise or lower the preset value. Keeping either button pressed causes the change to occur with increasing rapidity.

  • Page 34: Automatic Polarity Switching

    5.10 Automatic polarity switching The IEC standards call for equal quantities of positive and then negative dis- charges to be applied to a test point. The NSG 435 can execute this function automatically. The automatic polarity switch operates in conjunction with the preselect counter.
  • Page 35 F5 branches into the preselect counter menu. F4 switches the function «Automatic polarity change» on and off (Precondition: PRESELECT ON). The active state is shown by the polarity sign in front of the voltage alternating on the display.
  • Page 36 This automatic function works in both the single pulse mode as well as with repetitive discharges. Reinitialize the operation in single pulse mode after each cycle. Reset the counter and select the counter menu again (press F5 three times). NSG 435 ESD simulator...

  • Page 37: Continuous Operation

    5.11 Continuous operation A continuous operating mode can be selected for repetitive discharges. Pressing the trigger button starts the continuous operation; pressing it a second time stops the operation. Continuous operation should only be utilized in cases of real necessity since every ESD radiates electromagnetic disturbance the effect of which on the environment must be taken into consideration.
  • Page 38 Use F5 to return to the original menu level. Switching off continuous operation: By F5 branch into the preselect counter menu. Press F1 or F2. The counter shows 0000 or 9999 respectively. Continuous operation is switched off. NSG 435 ESD simulator...

  • Page 39: Storing Voltage Settings

    Use F5 to return to the original menu level. 5.12 Storing voltage settings Pre-programmed discharge voltage values can be stored in four memory loca- tions for both air and contact-discharges. As delivered, the instrument has the test levels set according to IEC/EN 61000-4-2, Ed. 1.2:2001. Level Test voltage Test voltage...
  • Page 40 Press F4 and a memory location (1 ... 4) appears over F3. Use F3 to specify the required memory location. Press F4 again and the value is stored. Use F5 to return to the original menu level. NSG 435 ESD simulator...

  • Page 41: Test Procedures

    The ESD simulator system NSG 435 is constructed and calibrated in accordance with the requirements of the standards. The test engineer cannot be relieved of the duty to study the applicable test pre- scriptions closely and to adapt the conditions to the test object in question.
  • Page 42 Earth wire Insulation Example of a simplified test rig for a table-top instrument. Cabinet earthed via protective earth Mains connection Earth connection Insulation pallet Earth wire Ground reference plane Example of a test rig for a system. NSG 435 ESD simulator...

  • Page 43: Verification Of The Pulse Data

    RF filter for at its AC power midpoint) Teseq uses the following instruments for calibration purposes: Oscilloscope with >1 GHz bandwidth Coaxial measurement adapter MD 101 (Pellegrini target as per IEC/EN 61000-4-2) or MD 103 20 dB attenuator DC-12.4 GHz - SUCOFLEX-HF-coaxial cable DC-High voltage voltmeter (Ri >...

  • Page 44: Maintenance

    The instrument contains no fuses that are accessible to the user. 8.2 Calibration Trimming procedures in the NSG 435 are carried out digitally and automatically. The instrument contains no elements that are foreseen for adjustment by the user. A component defect must be suspected if the calibration measurements differ from the published technical data and the instrument is to be returned to an authorized Teseq service centre.
  • Page 45 Voltage settings: 2, 4, 6 and 8 kV Compare the results obtained against the reference figures quoted in IEC/EN 61000-4-2, Ed. 1.2:2001 Remark Teseq offers an accredited service for this kind of work. 100% I at 30 ns I at 60 ns...
  • Page 46 IEC/EN 61000-4-2, Ed. 1.2:2001. Charge switch Discharge tip Rc 50-100 MΩ Rd 330 Ω Discharge switch Cs + Cd 150 pF HV generator Discharge return connection Teseq offers calibration services to carry out such work. NSG 435 ESD simulator...

  • Page 47: Exchanging The R/C Network

    8.3 Exchanging the R/C network Exchanging the discharge networks is to be undertaken by knowledgeable personnel. A clean and well-lit working area is necessary. A yellow B black C yellow/green...
  • Page 48 18 Check the operation of the generator by observing the spark-gap (the high voltage generator adjusts itself automatically to the new network) 19 If in doubt, a voltage check can be carried out as given in section 8.2 20 A calibration measurement is not normally necessary NSG 435 ESD simulator...

  • Page 49: Derating Of Pulse Repetition At Increased Capacitance

    This is the only consequence however of using high C networks. No firmware modification of the NSG 435 is needed. The figure shows the derating values for various capacitances versus the voltage.

  • Page 50: Repairs

    Teseq service centre. 8.5 Disposal The following list shows the principal materials that are used in the construction of the NSG 435. The relevant national regulations are to be observed when disposing of the instrument. Item...

  • Page 51: Declaration Of Conformity Ce

    9 DECLARATION OF CONFORMITY CE...

  • Page 52: Technical Specifications

    Charge resistor Rch 50 MΩ Triggering Trigger button in handgrip or by remote trigger unit with 5 m (197’’) optical cable Power supply Battery in handgrip, exchangeable, charging time: approx. 3 hours Mains power unit as an accessory NSG 435 ESD simulator...
  • Page 53 – Air- / contact-discharge – Counter / preselect counter content – Soft-key functions – Battery monitor Weight NSG 435 with battery: 1.2 kg (2.6 lbs) approx. Ambient conditions Operating +5º to +40ºC 20 to 80% r.h. (non-condensing) 68 to 106 kPa...

  • Page 54: Esd Standards

    Many product or product family standards refer back to these documents. Special discharge networks and test fingers are called for by: ANSI C63.16 Guide for ESD ISO 10605:2008 Road Vehicles ESD SAE J1113, Part 5 Vehicle Component ESD and others NSG 435 ESD simulator...

  • Page 55: Warranty

    The decision regarding the method of reinstating the func- tional capability is at the sole discretion of Teseq. Excluded from the warranty is damage or consequential damage caused by negligent operation or use as well as the replacement of parts subject to deg- radation.

  • Page 56: Odering Information

    ORDERING INFORMATIONS NSG 435 basic kit consisting of: Order no. Qty. NSG 435 ESD simulator complete with: NSG 435 …… Carrying case Network for IEC/EN 61000-4-2, Ed. 1.2:2001 with 150 pF/330 Ω Test fingers, ball and point Battery-pack / earth cable / operating instructions charging unit 100/230 V, 50/60 Hz, with interna-...

  • Page 57: Addresses

    NOTES...
  • Page 58 T + 44 845 074 0660 F + 886 2 2917 2626 F + 44 845 074 0656 taiwansales @ teseq.com uksales @ teseq.com © June 2012 Teseq ® Teseq Inc. Specifications subject to change T + 1 732 417 0501 without notice.
