SERVICE MANUAL
AH-S22DP2
AH-S25DP2
AH-S32DP2
MODELS
In the interests of user-safety (Required by safety regulations in some
countries) the set should be restored to its original condition and only parts
identical to those specified should be used.
TABLE OF CONTENTS
SHARP CORPORATION
SPLIT TYPE
ROOM AIR CONDITIONERS
INDOOR UNIT
1
AH-S22DP2
AH-S25DP2
AH-S32DP2
S3313AHS32DP2
OUTDOOR UNIT
AU-S22DP2
AU-S25DP2
AU-S32DP2
Page
Advertisement
Table of Contents
Related Manuals for Sharp AH-S22DP2
Summary of Contents for Sharp AH-S22DP2
-
Page 1: Table Of Contents
AH-S22DP2 AH-S25DP2 AH-S32DP2 SERVICE MANUAL S3313AHS32DP2 SPLIT TYPE ROOM AIR CONDITIONERS OUTDOOR UNIT INDOOR UNIT AH-S22DP2 AU-S22DP2 AH-S25DP2 AU-S25DP2 AH-S32DP2 AU-S32DP2 MODELS In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its original condition and only parts identical to those specified should be used. -
Page 2: Specifications
AH-S32DP2 SPECIFICATIONS INDOOR UNIT OUTDOOR UNIT INDOOR UNIT OUTDOOR UNIT INDOOR UNIT OUTDOOR UNIT MODEL ITEMS AH-S22DP2 AU-S22DP2 AH-S25DP2 AU-S25DP2 AH-S32DP2 AU-S32DP2 Cooling capacity(Min. ~ Max.) 2.0 (1.0 - 2.6) 2.1 (1.0 - 2.9) 2.7 (0.9 - 3.7) Moisture removal... -
Page 3: External Dimensions
AH-S22DP2 AH-S25DP2 AH-S32DP2 EXTERNAL DIMENSIONS 1700 18.5 Power supply cord INVERTER AIR CONDITIONER CRMC-A442JBE0 R03(AAA) 2PCS. SHARP CORPORATION Length unit (mm) 22.0 Figure E-1. INDOOR UNIT 37.5 179.5 Figure E-2. OUTDOOR UNIT 182.5... -
Page 4: Wiring Diagrams
AH-S22DP2 AH-S25DP2 AH-S32DP2 815 (unit size) Ceiling More than 50mm Center of wall hole: Leftward piping Center of wall hole: Backward piping Outline of indoor unit Figure E-3. INSTALLATION DIMENSIONS WIRING DIAGRAMS Figure W-1. Wiring Diagram for AH-S22DP2/S25DP2/S32DP2... - Page 5 AH-S22DP2 AH-S25DP2 AH-S32DP2 Figure W-2. Wiring Diagram for AU-S22DP2/S25DP2 Figure W-3. Wiring Diagram for AU-S32DP2...
-
Page 6: Electrical Parts
AH-S22DP2 AH-S25DP2 AH-S32DP2 ELECTRICAL PARTS For Model AH-S22DP2/S25DP2/S32DP2 DESCRIPTION MODEL REMARKS Indoor fan motor ML-A901 220 - 240V, 50Hz 220 - 230V, 60Hz Indoor fan motor capacitor – 430V or 450V, 2µF Transformer – Primary; AC 220 - 240V, 50/60Hz Secondary;... -
Page 7: Block Diagram
AH-S22DP2 AH-S25DP2 AH-S32DP2 BLOCK DIAGRAMS INDOOR UNIT 2.5A protection DC power supply circuit AC power Fan motor phase control circuit Indoor fan motor Rotation pulse input circuit Fan motor pulse detect AC clock circuit Louvre motor drive circuit(upper) Flow direction control (louver motor upper) - Page 8 AH-S22DP2 AH-S25DP2 AH-S32DP2 OUTDOOR UNIT for AU-S22DP2/S25DP2 15 A protection Unit-unit wiring (AC power Power supply circuit Smoothing Filter circuit circuit and serial signals) (built into IPM) 3.15 A CPU oscillator circuit protection Outdoor fan motor relay drive circuit Outdoor fan motor...
-
Page 9: Microcomputer Control System
AH-S22DP2 AH-S25DP2 AH-S32DP2 MICROCOMPUTER CONTROL SYSTEM... - Page 10 (BROWN) FROM TERMINAL“1”OF TERMINAL BOARD 4P (BLACK) FROM FAN MOTOR TERMINAL“N”OF TERMINAL BOARD 4P (BLUE) TERMINAL“2”OF TERMINAL BOARD 4P (RED) FROM FAN MOTOR FROM THERMISTOR FROM LOUVRE MOTOR (TOP) FROM LOUVRE MOTOR (BOTTOM) Figure L-2 Printed Wiring Board for AH-S22DP2/S25DP2/S32DP2...
- Page 11 AH-S22DP2 AH-S25DP2 AH-S32DP2...
- Page 12 AH-S22DP2 AH-S25DP2 AH-S32DP2...
- Page 13 AH-S22DP2 AH-S25DP2 AH-S32DP2 FROM FROM FROM DIODE BRIDGE PTC1 DIODE BRIDGE FROM FROM DB1 " ~ " DB1 " ~ " CONTROL BOX TERMINAL BOARD " 1 " T5(DB1~) (BLACK) (BROWN) (GREEN/ YELLOW) FROM FAN MOTOR 3A 250V WPE3 T6(GRAY)
-
Page 14: Functions
AH-S22DP2 AH-S25DP2 AH-S32DP2 FUNCTIONS 1. INDOOR UNIT 1-5 OFF-timer 1-1 Temperature Adjustment The OFF-timer is set by pressing the OFF-timer button. Operation is as follows: (1) Cooling Set temperature When the room temperature is higher than the preset temperature by 2˚Cor more, the unit runs at the... - Page 15 AH-S22DP2 AH-S25DP2 AH-S32DP2 Setting not memorized 1-10 Power ON start Timer setting If a jumper wire is inserted into the place indicated Full power setting JP99 on the indoor control board, and the power plug is inserted. Cooling mode will be automatically...
- Page 16 AH-S22DP2 AH-S25DP2 AH-S32DP2 2. DESCRIPTION OF ODOR SENSOR (1) Outline of the odor sensor The odor sensor is used to cluster display during operation. This odor sensor sensitively reacts to the various air contaminations such as a volatile organic solvent, fragrant materials and tabacco burning gas.
- Page 17 AH-S22DP2 AH-S25DP2 AH-S32DP2 What to Odor Sensor react to ? Odor Sensor also may react to vapour of insecticides, cosmetics, alcohol, hemicals and the like, and to extreme change of temperature / humidity. (2) Detection of the air contamination by the fluctuation ratio of sensor resistance The output voltage from the odor sensor is input into the microcomputer to detect the air contamination.
-
Page 18: Tips About Indicator Panel
AH-S22DP2 AH-S25DP2 AH-S32DP2 (2) Dust detection by using the sensor The output voltage from the optical allergen sensor is input into the indoor units microcomputer to detect the air contamination (dust). This method inputs the sensor voltage per unit of time and calculates the relative fluctuation to determine whether the air is contaminated or not. -
Page 19: Self Clean Operation
AH-S22DP2 AH-S25DP2 AH-S32DP2 PLASMA CLUSTER OPERATION You can choose PLASMA CLUSTER AUTO OPERATION, AIR CLEAN OPERATION or REFRESHING OPERATION During operation, press the PLASMACLUSTER button to select the mode. PLASMACLUSTER AUTO AIR CLEAN REFRESHING CANCEL • In the AIR CLEAN operation, the blue PLASMACLUSTER lamp on the unit will light up. - Page 20 AH-S22DP2 AH-S25DP2 AH-S32DP2 TIP ABOUT PLASMACLUSTER OPERATION The ionizer inside the air conditioner will release cluster ions, which are collective mass of positive and negative ions, into the room. The cluster ions reduce airborne mold fungus and deodorize/decompose odor- causing molecules.
- Page 21 AH-S22DP2 AH-S25DP2 AH-S32DP2 2. OUTDOOR UNIT seconds when operation begins, operation is stopped. In this case, the outdoor fan does not stop, and 170 2-1 Frequency control seconds after operation is stopped, another try will (1) AC current peak control be made.
-
Page 22: Function And Operation Of Protective Procedures
AH-S22DP2 AH-S25DP2 AH-S32DP2 FUNCTION AND OPERATION OF PROTECTIVE PROCEDURES Operation Self diagnostic display Function Description Detection Restart Restart Indoor Outdoor time condition times Indoor fan Stops operation if no rotation pulse When indoor Operation OFF No limit lock signal is input from the indoor fan motor for fan is rotating one minute. - Page 23 AH-S22DP2 AH-S25DP2 AH-S32DP2 Operation Self diagnostic display Function Description Detection Restart Restart Indoor Outdoor time condition times Compressor Lowers the operating frequency if the During Automatically No limit overheating temperature of the compressor chamber compressor restarts after safety control thermistor (TH1) rises above 105ϒ C.
-
Page 24: Breakdown Diagnosis Procedure
AH-S22DP2 AH-S25DP2 AH-S32DP2... - Page 25 AH-S22DP2 AH-S25DP2 AH-S32DP2...
- Page 26 AH-S22DP2 AH-S25DP2 AH-S32DP2...
-
Page 27: Refrigeration Cycle
AH-S22DP2 AH-S25DP2 AH-S32DP2 REFRIGERATION CYCLE Indoor unit Evaporator Flare coupling Flare coupling 3-way 2-way valve valve Outdoor unit Capillary tube Silencer Compressor Condenser Accumulator Figure R-1. Refrigeration Cycle Standard conditions: AH-S22DP2/S25DP2/S32DP2 Indoor side Outdoor side Dry-bulb Temp. (˚C) Relative Humidity (%) Dry-bulb Temp. -
Page 28: Performance Curves
(Running frequency: 101Hz) 1200 1400 1000 1200 1000 Outside air temp.(˚C) Outside air temp.(˚C) Figure P-2. At Cooling for AH-S25DP2 Figure P-1. At Cooling for AH-S22DP2 (Running frequency: 97Hz) 1600 1400 1200 1000 Outside air temp.(˚C) Figure P-3. At Cooling for AH-S32DP2... -
Page 29: Disassembling Procedure
AH-S22DP2 AH-S25DP2 AH-S32DP2 DISASSEMBLING PROCEDURE FOR INDOOR UNIT [AH-S22DP2/S25DP2/S32DP2] SERVICING CAUTION : DISCONNECT THE UNIT FROM THE POWER SUPPLY BEFORE ANY 1. Open the opne panel, and remove 2 air filters. 5. Pull the front panel up. 2. Remove 4 screws fixing the front panel. - Page 30 AH-S22DP2 AH-S25DP2 AH-S32DP2 9. Remove the thermistor of the evaporator. 13. Remove the screw fixing the pipe holder. 10. Remove 4 connectors. 14. Remove 3 screws fixing the control box, and remove the control box. 11. Remove the thermistor holder from the evaporator.
- Page 31 AH-S22DP2 AH-S25DP2 AH-S32DP2 17. Remove the drain cover from the evaporator. Note: During reassembly, verify that the dew on the pipe is led to the drain pan. 20. Remove 2 screws fixing the motor cover, and pull up the fan.
- Page 32 AH-S22DP2 AH-S25DP2 AH-S32DP2 How to remove the display cover 1. Push the center of display cover from the back. 2. Remove the screw fixing the terminal board. 2. Slide the display cover to the right. How to assemble the display cover 1.
- Page 33 AH-S22DP2 AH-S25DP2 AH-S32DP2 How to remove the horizontal louver Slightly pull down the hinge area, deflect the louver, and CN101 and CN102 unhook it from the hinge. Remove the shaft from each of the left and right sides. 6. Remove 2 connectors.
- Page 34 AH-S22DP2 AH-S25DP2 AH-S32DP2 FOR OUTDOOR UNIT [AU-S22DP2/S25DP2/S32DP2] SERVICING CAUTION : DISCONNECT THE UNIT FROM THE POWER SUPPLY BEFORE ANY Right side view Left side view 1. Loose a screw fixing the side cover. Front view 2. Loose the unit to unit cord.
- Page 35 AH-S22DP2 AH-S25DP2 AH-S32DP2 DISASSEMBLING PROCEDURE OF THE FAN Loose 8. Remove the terminal cover of compressor. 1. Loose the fan nut and fan can take out. 9. Disconnect 3 terminals. 2. Fan motor is secured by 4 screws. 10. Loose 4 screws fixing the control box.
-
Page 36: Option
AH-S22DP2 AH-S25DP2 AH-S32DP2 OPTION HOW TO REPLACE THE DUST COLLECTION FILTER AND DEODORANT FILTER Precautions The dust collection filter and the deodorant filter are packed as accessory of this unit. During operation of the air conditioner, the filters remove dust and tobacco smoke from the air and discharges clean air. - Page 37 AH-S22DP2 AH-S25DP2 AH-S32DP2 CLEANING THE DEODORANT FILTER (GREEN) The filter should be cleaned every 3~6 months REMOVE THE AIR FILTERS CLEAN THE DEODORANT FILTER 1 Take off the deodorant filter from the air filters. 2 Soak the deodorant filter in mild detergent dilution for 10 to 20 minutes.
-
Page 38: Replacement Parts List
AH-S22DP2 AH-S25DP2 AH-S32DP2 REPLACEMENT PARTS LIST [AH-S22DP2/AH-S25DP2/AH-S32DP2] REF. NO. PART NO. DESCRIPTION Q'TY CODE CABINET AND UNIT PARTS 1- 1 CMOT-A389JBKZ Fan motor sub ass’y 1- 2 PGUMSA046JBE0 Damper rubber 1- 3 CHLD-A067JBK0 Bearing ass’y 1- 4 DCHS-A399JBKZ Cabinet sub ass’y [AH-S22DP2/AH-S25DP2]... - Page 39 Tube ass’y [AH-S22DP2/AH-S25DP2] 3- 1 CPIPCA679JBKZ Tube ass’y [AH-S32DP2] 3- 2 PSEN-A005JBKZ Flare nut ass’y (1/4") 3- 3 PSEN-A004JBKZ Flare nut ass’y (3/8") [AH-S22DP2/AH-S25DP2] 3- 3 PSEN-A016JBKZ Flare nut ass’y (1/2") [AH-S32DP2] 3- 4 PVLV-0341JBE0 Flare Union (1/4") 3- 5 PVLV-0342JBE0 Flare Union (3/8") [AH-S22DP2/AH-S25DP2]...
- Page 40 AH-S22DP2 AH-S25DP2 AH-S32DP2 INDOOR UNIT FOR AH-S22DP2/AH-S25DP2/AH-S32DP2 4-11 1-29 4-12 4-13 1-42 1-23 1-35 1-43 4-10 1-45 1-40 1-39 1-26 1-12 1-46 2-11 1-40 1-22 1-32 2-18 2-13 2-53 1-18 2-57 1-51 1-50 1-38 2-14 1-21 2-12 2-43 1-31 1-33...
- Page 41 AH-S22DP2 AH-S25DP2 AH-S32DP2 REPLACEMENT PARTS LIST [AU-S22DP2/AU-S25DP2/AU-S32DP2] REF. NO. PART NO. DESCRIPTION Q'TY CODE CONTROL BOX PARTS 1- 1 CMOTLA902JBEZ Fan motor [AU-S22DP2/S25DP2] 1- 1 CMOTLA903JBEZ Fan motor [AU-S32DP2] 1- 2 RTRN-A256JBE0 Current transfoemer CT1 1- 3 QW-VZD863JBZZ Lead wire (Bulkhead - TBE)
- Page 42 AH-S22DP2 AH-S25DP2 AH-S32DP2 REF. NO. PART NO. DESCRIPTION Q'TY CODE 2- 5 PFPFPB911JBEZ Motor angle cushion 2- 6 GCAB-A195JBTA Front panel 2- 7 GGADFA037JBFA Fan guard 2- 8 PSEL-C045JBEZ Motor angle cushion 2- 9 PSEL-C048JBEZ F panel insulator 2-10 PSEL-C049JBEZ...
- Page 43 AH-S22DP2 AH-S25DP2 AH-S32DP2 REF. NO. PART NO. DESCRIPTION Q'TY CODE SCREWS AND NUTS 4- 1 LX-BZA140JBE0 Special screw 4- 2 LX-BZA072JBE0 Special screw (for 2/3 way valve unit) 4- 3 XTTSA40P14000 Tapping screw 4- 4 LX-BZA166JBE0 Special screw 4- 5...
- Page 44 AU-S32DP2 4-17 1-55 3-13 1-46 3-11 2-16 1-14 1-47 3-11 1-16 3-17 2-17 3-10 1-18 1-17 1-16 2-19 2-11 3-21 3-21 3-12 2-10 2-17 3-16 4-14 3-15 3-18 3-20 2-13 2-12 3-19 4-14 i d e 2003. 03. SHARP CORP.
