Operating Instructions

Error indicator readout

If the LED diagnostic readout displays an error code, such as LL, push in and turn
the red Emergency Stop button to reset the system.
List of Fault Codes
Display
01 System initialization Fault
02 System communication Fault
03 Invalid option setting Fault
12 Chassis Up/Down Switch ON at Power-up Fault
18 Pothole Guard Fault
31 Pressure Sensor Fault
32 Angle Sensor Fault
34 Reserved
42 Platform Left Turn Switch ON at power-up Message
43 Platform Right Turn Switch ON at power-up Message
46 Platform Joystick Enable Switch ON at power-up Fault
47 Platform Joystick not in neutral at power-up Message
52 Drive Forward Coil Fault
53 Drive Reverse Coil Fault
54 Lift Up Coil Fault
55 Lift Down Coil Fault
56 Right Turn Coil Fault
57 Left Turn Coil Fault
58 General Brake Coil Fault
59 Parallel Coil Fault
61 Motor Controller Current Sensor Fault
62 Motor Controller Hardware Failsafe Fault
Description
28
Lift Reaction
Disables All Motion
Disables All Motion
Disables All Motion
Disable Chassis Control
Disable Lifting and Driving
Disables All Motion
Disables All Motion
Diagnostic Message Only
Diagnostic Message Only
Disable Platform Control
Diagnostic Message Only
Disable Lifting and Driving
Disable Lifting and Driving
Disable Lifting and Driving
Disable Lifting and Driving
Disable Lifting and Driving
Disable Lifting and Driving
Disable Lifting and Driving
Disable Lifting and Driving
Controller Dependent
Controller Dependent
