Summary of Contents for JVC LT-32HG25J
-
Page 2: Logo & License
Dear Customer, This apparatus is in conformance with the valid European directives and standards regarding electromagnetic compatibility and electrical safety. European representative of Victor Company of Japan, Limited is: JVC Technical Services Europe GmbH Postfach 10 05 04 61145 Friedberg Germany... -
Page 3: Table Of Contents
Contents Logo & License ............1 Setup ..............19 Features ..............3 Confi guration ............ 19 Introduction ............. 3 Language Settings ..........21 Package Contents ..........3 Installation............21 Important Safety Information ........4 Analogue TV Menu System ........22 Mains supply ............ -
Page 4: Features
Features Introduction • Remote controlled colour LCD TV. Thank you for choosing this product. This manual will guide you for the proper • Fully integrated digital TV (DVB-T DVB-T2 - MPEG2 operation of your TV. Before operating the MPEG4). TV, please read this manual thoroughly. •... -
Page 5: Important Safety Information
Important Safety Information Mains supply This television is designed to operate from a 220 V - 240 V Volts 50Hz AC mains supply. Other power sources may damage it. Check that the rating label states 220 V - 240 V AC ( - ) before you plug it in for the fi rst time. -
Page 6: Cleaning
Cleaning Disconnect the mains supply and use a lightly dampened soft cloth. Do not use chemical solvents or strong detergents as these may damage the cosmetic surfaces or the screen. Never allow water droplets to remain on the screen as moisture can cause permanent discolouration. Greasy marks must only be romeved with a commercial cleaner specifi... -
Page 7: Overview Of The Remote Control
Overview of the Remote Control TV/DTV: TV – Digital TV OK: OK / Confi rm / Freezing Picture (in analogue mode) / Channel list (in DTV mode) : Cursor left MENU: Menu on-off ZOOM: Image size RED: Sound menu (Analogue TV) GREEN: Picture Menu (Analogue TV) AV: Source selection : Programme up / down... -
Page 8: Inserting Batteries In The Remote Control
Inserting Batteries in the Power Connection Remote Control IMPORTANT: The TV set is designed to operate on 220 V - 240 V AC, 50 Hz. • Remove the battery cover located on the back of • After unpacking, allow the TV set to reach the the handset by gently pulling backwards from the ambient room temperature before you connect the indicated part. -
Page 9: Switching The Tv On/Off
Switching the TV On/Off Using the Cable Holder To Switch the TV On • Connect the power cord to the 220 V - 240 V AC 50 Hz. • Switch the “ ” button on the left side pannel to position “|”... -
Page 10: Lcd Tv And Operating Buttons
LCD TV and Operating Buttons FRONT and REAR VIEW FRONT VIEW Control Buttons Standby button TV/AV button Programme Up/Down buttons Power LED Volume Up/Down buttons Note: Press buttons at the same time to view main menu. Viewing the Connections- Back Connectors Subwoofer Out is for connecting an external, active subwoofer to the set to give a much deeper bass effect. - Page 11 EXT 1 inputs or outputs for external devices. Connect the SCART cable between EXT (SCART) sockets on TV and EXT (SCART) socket on your external device (such as a decoder, a VCR or a DVD player). Note: If an external device is connected via the EXT (SCART) sockets, the TV will automatically switch to AV mode.
-
Page 12: Viewing The Connections - Side Connectors
Viewing the Connections - Side Connectors CI Slot is used for inserting a CI card. A CI card allows you to view all the channels that you subscribe to. For more information, see “Common Interface” section. Important Notice: Side USB Input 1 is for service use only. Note that this USB connector does not have any other functions such as playing audio or picture fi... -
Page 13: Using Usb Input
Using USB Input Connecting the LCD TV to a PC •You can connect USB devices to your TV by using You can connect your PC to the TV and use it as a the USB input of the TV. This feature allows you to computer monitor. -
Page 14: Connecting To A Dvd Player
Connecting to a DVD Player Using Side AV Connectors If you want to connect a DVD player to your LCD You can connect a range of optional equipment TV, you can use connectors of the TV set. DVD to your LCD TV. Possible connections are shown players may have different connectors. -
Page 15: Input Selection
AV Mode Input Selection • Press the “TV/AV” button in the control panel on the Once you have connected external systems to your TV to switch between AV modes. TV, you can switch to different input sources. Operation with the Remote Control •... -
Page 16: General Operation
After automatic tuning is fi nalized, a programme list will appear on the screen. In the programme list you will see the programme numbers and names assigned to the programmes. If you do not accept the locations and/or the names of the programmes, you can change them in Program table. -
Page 17: Electronic Programme Guide (Epg)
Electronic Programme Guide (EPG) Press “0” button to view Guide Search menu. Using this feature, you can search the programme guide Some, but not all, channels send information about database in accordance with the genre selected or the current and next events. Please note that event with name match. -
Page 18: Analogue Teletext
Analogue Teletext Digital teletext is self explanatory with instructions for use on the text pages themselves. Analogue teletext explanations are on Page 29. Widescreen Depending on the type of the broadcast being transmitted, programmes can be viewed in a number of formats. -
Page 19: Renaming Channels
Renaming channels To rename a specifi c channel, the channel must be highlighted via pressing “ ” or “ ” buttons and then highlight the “Edit Name” item by pressing “ ” or “ ” buttons. Press “OK” button to activate rename feature. -
Page 20: Tv Setup
• The CAM should be correctly inserted, it is impossible to insert fully if reversed. The CAM or the TV terminal may be damaged if the CAM is forcefully inserted. • Connect the TV to the mains supply, switch on and then wait for few moments until the card is activated. - Page 21 Compressed sound Bitstream, you should connect • This function enables or disables the menu protection your TV to external equipment by using spdif out of system and allows the PIN code to be changed. your TV for enabling the sound output. If you have no •...
-
Page 22: Language Settings
Audio Description (Optional) IP Settings Audio description refers to an additional narration track for blind and visually impaired viewers of visual media. You can use this feature, only if the broadcaster supports that additional narration track. Select Audio Description and press OK button to view contents. Use “... -
Page 23: Analogue Tv Menu System
Select YES and follow the on screen prompts as described in initial settings on page 14. Analogue TV Menu System Highlight Yes or No by using “ ” or “ ” buttons and Picture Menu press OK button to confi rm. If Yes is selected, automatic search starts. -
Page 24: Sound Menu
Equaliser Press “ ” or “ ” button to select Noise Reduction. Press “ ” or “ ” to choose from one of these options: Press “ ” or “ ” button to select Equaliser. Press Low, Medium, High or Off. “... -
Page 25: Feature Menu
Child Lock Automatic Volume Limiting (AVL) function adjusts the Press “ ” or “ ” button to select Child Lock. sound to obtain fi xed output level between programmes Use “ ” or “ ” button to set the Child Lock On or Off. (For instance, volume level of advertisements tend to When On is selected, the TV can only be controlled be louder than programmes). -
Page 26: Install Menu
Menu Timeout remote control. There are 200 programme storage locations 0 to 199. To set a specifi c display timeout for menu screens, set a value for this option. Band Press “ ” or “ ” button to select Menu Timeout. Use Band can be selected either C or S. -
Page 27: Source Menu
Program Table APS (Auto Programming System) Select Program Table by pressing “ ” or “ ” When you press the BLUE button for starting button. automatic tuning, Auto Programming System menu will appear on the screen: Press “ ” or “ ” button to select your country. If you want to exit from A.P.S. -
Page 28: Media Browser Menu
Playing .mp3 Files In source menu, highlight a source by pressing “ ” or “ ” button and switch to the selected source by If you play an mp3 fi le, the following screen can be pressing “ ” button. Source options are; TV, DTV, displayed during the playback by pressing the MENU EXT-1, EXT-2, SIDE AV, S-VIDEO, HDMI-1, HDMI-2, or BACK button once or twice in the USB menu. -
Page 29: Displaying Tv Information
Autoposition Displaying TV Information If you shift the picture horizontally or vertically to an Programme Number, Programme Name, Sound unwanted position, use this item to put the picture Indicator and Zoom Mode information is displayed into correct place automatically. This setting therefore on the screen when a new programme is entered or automatically optimizes the display. -
Page 30: Panoramic
use the 16:9 mode to restore the picture to its Teletext original shape. Teletext system transmits information such as news, sports and weather on your TV. Note that if the signal Use to view a normal picture (4:3 aspect ratio) as this degrades, for example in poor/adverse weather is its original size. -
Page 31: Teletext Subtitle (In Analogue Tv Mode Only)
Teletext Subtitle (in analogue TV mode Sound only) You can not hear any sound. Did you perhaps interrupt the sound, pressing the button? If you press button, teletext subtitle information will be displayed on the bottom right of the screen (if Sound is coming from only one of the speakers. -
Page 32: Appendix A: Pc Input Typical Display Modes
Appendix A: PC Input Typical Display Modes The display has a maximum resolution of 1920 x 1200. The following table is an illustration of some of the typical video display modes. Your TV may not support different resolutions. Supported resolution modes are listed below. If you switch your PC to an unsupported mode, a warning OSD will appear on the screen. -
Page 33: Appendix B: Av And Hdmi Signal Compatibility (Input Signal Types)
Appendix B: AV and HDMI Signal Compatibility (Input Signal Types) Source Supported Signals Available PAL 50/60 NTSC 60 EXT 1 RGB 50 RGB 60 PAL 50/60 NTSC 60 EXT 2 RGB 50 RGB 60 PAL 50/60 SIDE AV NTSC 60 PAL 50/60 S-VIDEO NTSC 60... -
Page 34: Appendix C: Supported File Formats For Usb Mode
Appendix C: Supported File Formats for USB Mode Format Remarks File Media Extension Video Audio (Maximum resolution/Bit rate etc.) MPEG 1/2 Sample Rate: 8kHz ~ 48kHz, Bit Rate: Music .mp3 Layer 1/ 2/ 32kbps~320kbps 3 (MP3) Photo MAX. Width 7680 Height 4320, 16 Mega-pixel Baseline .jpg JPEG... -
Page 35: Specifi Cations
Specifi cations Digital Reception (DVB-T) TV BROADCASTING Transmission Standards: PAL/SECAM B/G D/K K’ I/I’ L/L’ MPEG2, MPEG4 HD DVB-T RECEIVING CHANNELS i. DEMODULATION VHF (BAND I/III) -Symbol rate: COFDM with 2K/8K FFT mode. -Modulation: 16-QAM - 64-QAM FEC for all DVB UHF (BAND U) modes (automatically found) HYPERBAND... -
Page 36: Installing Using A Wall Mounting
INSTALLING USING A WALL MOUNTING INSTALLING / REMOVING THE STAND WARNING: The LCD display is very fragile, and must be protected at all times when installing / removing the stand. Be sure that no hard or sharp object, or anything that could scratch or damage the LCD display, comes into contact with it. - Page 37 Troubleshooting and Help Line Sound Symptoms Possible causes What to do No sound The volume is set to min. Turn the volume up. The mute is switched on. Press the mute button to release 'mute'. Crackling noises or distorted Interference from cars, fluorescent lights, Turn off one piece of equipment at a time to see if sound.
- Page 38 Picture interference like wavy Some other equipment is using the same Put other equipment on stand-by to see if the lines or patterns. Sound or colour frequency. interference stops: change the output frequency of interference may also be present. the equipment that is causing interference (see its instructions).
