Summary of Contents for Wen 2305
- Page 2 Table of Contents Specifications………………………………………………………. General Power Tool Safety Warnings……………………………… Safety Rules for Rotary Tools……………………………………… Additional Safety Warnings……………………………………….. Components of a Rotary Tool……………………………………… Assembly…………………………………………………………… Operating Instructions……………………………………………… Maintenance………………………………………………………… Accessories…………………………………………………………. One (1) Year Limited Warranty…………………………………….. 2 ...
-
Page 3: Specifications
Specifications Model: 2305 Rating: 120V, 60Hz, AC only Input: 1.0 Amp No Load Speed: 8,000-30,000 RPM Collet Size: Supplied with 1/8" (3.2 mm) & 3/32" (2.3 mm) Weight: 1.1 lbs Package Contents: 1--Rotary Tool 1--Flex Shaft 1--Storage Case... -
Page 4: General Power Tool Safety Warnings
General Power Tool Safety Warnings Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Work area safety Keep work area clean and well lit. Cluttered or dark areas invite accidents. Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. -
Page 5: Safety Rules For Rotary Tools
Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewelry or long hair can be caught in moving parts. If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. - Page 6 If cutting into existing walls or other blind areas where electrical wiring may exist is unavoidable, disconnect all fuses or circuit breakers feeding this worksite. Do not operate the flexible shaft with a sharp bend. Over bending the shaft can generate excessive heat on the jacket or hand piece.
-
Page 7: Additional Safety Warnings
The direction of feed with the bit into the material when carving, routing or cutting is very important. Always feed the bit into the material in the same direction as the cutting edge is exiting from the material (which is the same direction as the chips are thrown). Feeding the tool in the wrong direction, causes the cutting edge of the bit to climb out of the work and pull the tool in the direction of this feed. -
Page 8: Extension Cords
Certain cleaning agents such as gasoline, carbon tetrachloride, ammonia, etc. may damage plastic parts. Risk of injury to user. The power cord must only be serviced by a WEN Service Facility. Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to cause cancer, birth defects or other reproductive harm. - Page 9 Protect your extension cords from sharp objects, excessive heat and damp or wet areas. Use a separate electrical circuit for your tools. This circuit must not be less than a #12 wire and should be protected with a 15 A time-delayed fuse. Before connecting the motor to the power line, make sure the switch is in the OFF position and the electric current is rated the same as the current stamped on the motor nameplate.
- Page 10 Com m ponents s of a Ro otary Too Hanger On n/Off Switch Brush Cap Housing Ca ap S S peed Dial Collet Nu ut aft Lock tton Flex Shaft 10 ...
-
Page 11: Assembly
Assembly Warning: Always unplug Rotary Tool before changing accessories, changing collets or servicing your Rotary Tool. Collet nut To loosen, first press Shaft Lock Button and rotate the shaft by hand until the lock engages the shaft preventing further rotation. Caution: Do not engage lock while the Rotary Tool is running. - Page 12 The cable e will becom me loose from m the jacket and will unc c ontrollably whip or lash h around. 1. T Turn the tool off. 2. R Remove the h housing cap from the too 3. P ress the Spin ndle Lock B utton, unscr...
-
Page 13: Operating Instructions
Operating Instructions ON/OFF switch 1. The on/off switch is located on the underside of the handle. It has two setting “0” (Off) and “I” (On). 2. To switch on the tool, press the switch into the “I” (On) position. There is no need to hold it down as it will automatically lock in position. -
Page 14: Maintenance
This will properly “seat” your brushes, which extends the life of both your brushes and your tool. To maintain peak efficiency of the motor, we recommend every 40 - 50 hours the brushes be examined. Only genuine WEN replacement brushes specially designed for your tool should be used. -
Page 15: Accessories
Ventilation openings and switch levers must be kept clean and free of foreign matter. Do not attempt to clean by inserting pointed objects through openings. Caution: Certain cleaning agents and solvents damage plastic parts. Some of these are: gasoline, carbon tetrachloride, chlorinated cleaning solvents, ammonia and household detergents that contain ammonia. -
Page 16: One (1) Year Limited Warranty
(1) year from date of purchase. Ninety (90) days for all WEN Products, if the tool is used for professional or commercial use. SELLER’S SOLE OBLIGATION AND YOUR EXCLUSIVE REMEDY under this One (1) Year Limited Warranty...
