Toro 20942 Operator's Manual

46cm Lawn Mower
Model No. 20942—Serial No. 317000001 and Up
Introduction
This rotary-blade, walk-behind lawn mower is intended
to be used by residential homeowners. It is designed
primarily for cutting grass on well-maintained lawns
on residential properties. It is not designed for cutting
brush or for agricultural uses.
Read this information carefully to learn how to operate
and maintain your product properly and to avoid
injury and product damage. You are responsible for
operating the product properly and safely.
You may contact Toro directly at www.Toro.com for
product and accessory information, help finding a
dealer, or to register your product.
Whenever you need service, genuine Toro parts, or
additional information, contact an Authorized Service
Dealer or Toro Customer Service and have the model
and serial numbers of your product ready.
identifies the location of the model and serial numbers
on the product.
1. Model and serial number plate
Write the product model and serial numbers in the
space below:
Model No.
Serial No.
This manual identifies potential hazards and has
safety messages identified by the safety-alert symbol
(Figure 2), which signals a hazard that may cause
serious injury or death if you do not follow the
recommended precautions.
© 2017—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
Figure 1
Figure 1
Register at www.Toro.com.
1. Safety-alert symbol
This manual uses 2 words to highlight information.
Important calls attention to special mechanical
information and Note emphasizes general information
worthy of special attention.
Net Torque: The gross or net torque of this engine
was laboratory rated by the engine manufacturer in
accordance with the Society of Automotive Engineers
(SAE) J1940. As configured to meet safety, emission,
and operating requirements, the actual engine torque
on this class of mower will be significantly lower. Go to
www.Toro.com to view specifications on your mower
model.
Contents
Introduction ............................................................... 1
Safety ....................................................................... 2
General Safety ................................................... 2
Safety and Instructional Decals .......................... 3
Setup ........................................................................ 4
1 Assembling the Handle .................................... 4
2 Installing the Recoil-Starter Rope in the
Rope Guide..................................................... 4
3 Filling the Engine with Oil ................................. 4
g188341
4 Assembling the Grass Bag............................... 5
Product Overview ..................................................... 6
Specifications .................................................... 6
Operation .................................................................. 6
Before Operation ................................................... 6
Before Operation Safety ..................................... 6
Filling the Fuel Tank ............................................ 7
Checking the Engine-Oil Level............................ 7
Adjusting the Cutting Height ............................... 8
During Operation ................................................... 8
During Operating Safety ..................................... 8
Starting the Engine ............................................. 9
Using the Self-Propel Drive................................. 9
Shutting Off the Engine....................................... 9
Mulching the Grass Clippings ............................. 9
Bagging the Grass Clippings ............................ 10
Rear-Discharging the Grass Clippings .............. 10
Original Instructions (EN)
Form No. 3414-173 Rev B
Operator's Manual
Figure 2
All Rights Reserved *3414-173* B
Printed in China
g000502
