Siemens SINAMICS G120 List Manual page 463

r3859.0 CO/BO: Compound braking/DC quantity control status word / Comp-br/DC_ctr ZSW
PM240 Access level: 3
Can be changed: -
Unit group: -
Min
-
Description: Display and connector output for the status word of the compound braking and DC quantity control.
Bit field: Bit
00
Dependency: Refer to: p3856
p3870 Long stator configuration / Long stator config
Access level: 3
Can be changed: U, T
Unit group: -
Min
-
Description: Sets the configuration when operating a long stator motor.
Bit field: Bit
00
01
Notice: The following restrictions apply to this function:
- it is not permissible to change over the drive data set.
- the encoder/drive may not be parked using a PROFIBUS telegram.
- a maximum of 4 drives may be connected to the Control Unit.
- it is not permissible to commutate with the zero mark (p0404).
Note: For bit 00:
All of the help functions for long stator motors can be enabled/disabled using this bit.
For bit 01:
When the bit is set, bit 14 (parking encoder active) is set to 0 in the encoder status word GX_ZSW independent of
whether the encoder is parked or not.
p3900 Completion of quick commissioning / Compl quick_comm
Access level: 1
Can be changed: C(1)
Unit group: -
Min
0
Description: Exits quick commissioning (p0010 = 1) with automatic calculation of all parameters of all existing drive data sets that
depend on the entries made during quick commissioning.
p3900 = 1 initially includes a parameter reset (factory setting, the same as p0970 = 1) for all parameters of the drive
object; however, without overwriting the entries made during the quick commissioning.
The interconnections of PROFIBUS PZD telegram selection (p0922) and the interconnections via p15 and p1500 are
re-established and all of the dependent motor, open-loop and control-loop control parameters are calculated
(corresponding to p0340 = 1).
p3900 = 2 includes the restoration of the interconnections of PROFIBUS PZD telegram selection (p0922) and the
interconnections via p15 and p1500 and the calculations corresponding to p0340 = 1.
p3900 = 3 only includes the calculations associated with the motor, open-loop and closed-loop control parameters
corresponding to p0340 = 1.
Value: 0:
1:
2:
3:
Notice: After the value has been modified, no further parameter modifications can be made and the status is shown in r3996.
Modifications can be made again when r3996 = 0.
SINAMICS G120 CU250S-2 Control Units
List Manual, 09/2017, A5E33842890
Signal name
Compound braking active
Signal name
Activate long stator help functions
Suppress Gx_ZSW.14
No quick parameterization
Quick parameterization after parameter reset
Quick parameterization (only) for BICO and motor parameters
Quick parameterization for motor parameters (only)
Calculated: -
Scaling: -
Unit selection: -
Max
-
1 signal
Yes
Calculated: -
Scaling: -
Unit selection: -
Max
-
1 signal
Active
Active
Calculated: -
Scaling: -
Unit selection: -
Max
3
2 Parameters
2.2 List of parameters
Data type: Unsigned32
Dyn. index: -
Func. diagram: 6797
Factory setting
-
0 signal
No
Data type: Unsigned16
Dyn. index: -
Func. diagram: -
Factory setting
0000 bin
0 signal
Inactive
Inactive
Data type: Integer16
Dyn. index: -
Func. diagram: -
Factory setting
0
FP
-
FP
-
-
463
