5.1.3

Using the QoS Option

Use the Quality of Service (QoS) option to monitor the UBC1301-AA00 error codewords,
payload header suppression, and service flows.
To monitor QoS parameters:
1. Click MTA from the left side menu.
2. Click QoS under MTA.
Field descriptions are listed below the screen example.
Label
Error Codewords
Unerrored Codewords
Correctable Codewords
Uncorrectable Codewords
Payload Header Suppression
PHS Status
Service Flows
SFID
Service Class Name
Ubee UBC1301-AA00 Advanced Wireless Voice Gateway Subscriber User Guide • March 2017
Displays the number of codewords passed without error.
Displays the number of codewords corrected.
Display the number of codewords that could not be corrected.
Displays whether the payload header is suppressed (on) or not (off). When
on, redundant information is not transmitted.
Displays the service flow ID number.
Displays the service class name string that the CMTS associates with a QoS
parameter set.
Description
Using the MTA Option
