Dimensions and description

6
1
2
3*
98 130 162 193
4
Fig. 2 Pipe work connector location
Regular boiler:
[1] Hot water flow (1")
[2] Gas (3/4")
[3*] Not used on the regular boiler
[4] Hot water return (1")
[5] Condensate outlet
[6] 80/125 Flue outlet
System boiler:
[1] Heating and DHW flow (1")
[2] Gas (3/4")
[3*] DHW return (1") (only if optional diverter valve kit is fitted)
[4] Heating return (1")
[5] Condensate outlet
[6] 80/125 Flue outlet
Product Name
466
Ø80
141 253
5
394
Appliance information | 5
Ø125
83 61 78 111 59
4 3* 2 1
6 720 ... ... (YYYY/MM)
