Philips 247E3LHSU2/00 Service Manual

Color, 23.6"w
Hide thumbs
Table of Contents

Advertisement

Quick Links

23.6 W LCD Color Monitor
247E3LHSU2/00
Service
247E3LHSU2/69
Service
247E3LHSU2/01
Service
247E3LHSU2/25
247E3LHSU2/75
247E3LPHSU2/94
247E3LPHSU2/01
Description
Table of Contents......................................................1
Revision List.............................................................2
Important Safety Notice............................................3
1. Monitor Specifications............................................5
2. LCD Monitor Description........................................8
3. Operation Instructions............................................9
3.1 General Instructions.......................................9
3.2 Control Buttons.............................................9
3.3 OSD Menu......................................................10
4. Input/output Specification.....................................12
4.1 Input Signal Connector.......................................12
4.2 Resolution & Preset Modes.................................12
4.3 Pixel Defect Policy.......................................13
4.4 Failure Mode of Panel...................................16
5. Block Diagram.................................................17
5.1 Scaler Board.....................................................17
5.2 Power Board.......................................................18
6. Schematic Diagram.............................................. 20
6.1 Scaler Board..............................................20
6.2 Power Board.......................................................26
6.3 Key Board..................................................29
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE
CHASSIS AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN
SERVICING ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING
REFER TO BACK COVER FOR IMPORTANT SAFETY GUIDELINES
Copyright 2013 Philips Consumer Lifestyle
247E3LHSU/00
247E3LPHSU/00
247E3LHSU/01
247E3LPHSU/01
247E3LHSU/25
247E3LPHSU/27
247E3LHSU/27
247E3LPHSU/69
247E3LHSU/69
247E3LPHSU/75
247E3LHSU/73
247E3LPHSU/93
247E3LHSU/75
247E3LPHSU/94
247E3LHSU/93
247E3LPHSU/96
247E3LHSU/96
247E3LPHSU2/27
247E3LPHSU2/93
247E3LPHSU2/96
247E3LPHSU2/00
247E3LPHSU2/69
Page
Description
6.4 LED Board.................................................30
6.5 Headphone Jack Board.................................31
6.6 IR Board....................................................32
7. PCB Layout...............................................34
7.1 Scaler Board............................................34
7.2 Power Board..............................................35
7.3 Key Board..................................................38
7.4 LED Board.................................................38
7.5 Headphone Jack Board.................................38
7.6 IR Board....................................................39
8. Wiring Diagram.............................................40
9. Scaler Board Overview...................................42
10. Mechanical Instructions................................44
11. Repair Flow Chart........................................47
12. ISP Instructions..................................................51
13. DDC Instructions................................................59
15. Monitor Exploded View.......................................87
16. Recommended & Spare Parts List......................88
17. General Product Specification.......................101
SAFETY NOTICE
Subject to modification
Jan.22, 2013
K
Chassis: Meridian 3
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 247E3LHSU2/00 and is the answer not in the manual?

Questions and answers

Related Manuals for Philips 247E3LHSU2/00

Summary of Contents for Philips 247E3LHSU2/00

  • Page 1: Table Of Contents

    CHASSIS AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES. CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING REFER TO BACK COVER FOR IMPORTANT SAFETY GUIDELINES Copyright 2013 Philips Consumer Lifestyle Subject to modification Jan.22, 2013...

  • Page 2: Revision List

    Update BOM for 247E3LPHSU/27 and 247E3LPHSU/94 Dec.22,2011 Update BOM for 247E3LPHSU/00, 247E3LPHSU/69 and 247E3LPHSU/96 May 10,2012 Add CTN model 247E3LHSU/25 and 247E3LHSU/73 Jun.5,2012 Add CTN model for 247E3LHSU2/00 Add CTN model 247E3LHSU2/69, 247E3LHSU2/01, 247E3LHSU2/25, Jul.6,2012 247E3LPHSU2/27, 247E3LPHSU2/93 and 247E3LPHSU2/00 Jul.19,2012 Add CTN model 247E3LPHSU2/96 Jul.27,2012...

  • Page 3: Important Safety Notice

    Meridian 3 Important Safety Notice This electronic user guide is intended for anyone who uses the Philips monitor. Take time to read this user manual before you use your monitor. It contains important information and notes regarding operating your monitor. The...
  • Page 4 Meridian 3 IMPORTANT: Always activate a moving screen saver program when you leave your monitor unattended. Always activate a periodic screen refresh application if your monitor will display unchanging static content. Uninterrupted display of still or static images over an extended period may cause “burn in”, also known as “after-imaging”...

  • Page 5: Monitor Specifications

    Meridian 3 1. Monitor Specifications Picture/Display Monitor Panel Type TFT-LCD Backlight Panel Size 23.6" W (59.9 cm) Aspect Ratio 16:9 Pixel Pitch 0.2715 x 0.2715 mm Brightness 300 cd/m² Smart Contrast 20,000,000:1 Contrast Ratio (typ.) 1000:1 Response Time (typ.) Smart Response 2ms (available for model 247E3LH, 247E3LPH) Optimum Resolution 1920x1080@60Hz...
  • Page 6 Meridian 3 100VAC +/-5VAC, 115VAC +/-5VAC, 230VAC +/-5VAC, 50Hz +/-3Hz 60Hz +/-3Hz 50Hz +/-3Hz Normal Operation 59.11 BTU/hr 59.9 BTU/hr 59.83 BTU/hr Sleep 1.71 BTU/hr 1.71 BTU/hr 1.71 BTU/hr 1.02 BTU/hr 1.02 BTU/hr 1.02 BTU/hr Power LED indicator On mode: White, Standby/Sleep mode: White (blinking) Power Supply Built-in, 100-240VAC, 50/60Hz Power (247E3LPH)
  • Page 7 Black (Back), Black/Blue tint (Front) Finish Glossy Note: 1. EPEAT Gold or Silver is valid only where Philips registers the product. Please visit www.epeat.net registration status in your country. 2. This data is subject to change without notice. Go to www.philips.com/support...

  • Page 8: Lcd Monitor Description

    Meridian 3 2. LCD Monitor Description The LCD monitor will contain a scaler board, a power board, a LED board, a headphone board, two IR boards (247E3LPH) and a key board. The scaler board houses the flat panel control logic, brightness control logic and DDC.

  • Page 9: Operation Instructions

    Meridian 3 3. Operating Instructions : Adjust the speaker volume.(247E3LH) 3.1 General Instructions : Set the sensor level for backlight Press the power button to turn the monitor on or off. automatic control. (247E3LPH) The other control knobs are located at front panel of / : Adjust the OSD menu.

  • Page 10: Osd Menu

    3.3 OSD Menu 5. Turn on your computer and monitor. If the monitor displays an image, installation is complete. On-screen Display (OSD) is feature in all Philips LCD monitors. It allows an end user to adjust screen Install the base stand performance or select functions of the monitors directly 1.
  • Page 11 Meridian 3 247E3LH The OSD tree Below is an overall view of the structure of the On-Screen Display. You can use this as a reference when you want to work your way around the different adjustments later on. 247E3LPH Basic and simple instruction on the control keys In the OSD shown above, you can press buttons at the front bezel of the monitor to move the cursor,...

  • Page 12: Input/Output Specification

    Meridian 3 4. Input/Output Specification Hot Plug Detect (All versions) and HEC 4.1 Input Signal Connector Data+ (Optional, HDMI 1.4+ with D-sub Connector Ethernet) Pin No. Signal Name 4.2 Resolution & Preset Modes Green/ SOG Maximum Resolution Blue 1920 x 1080 at 60 Hz (analog input) Sense (GND) 1920 x 1080 at 60 Hz (digital input) Cable Detect (GND)

  • Page 13: Pixel Defect Policy

    No manufacturer can guarantee that displays a dark pattern. There are three types of bright panels will be free from pixel defects, but Philips dot defects: guarantees that any monitor with an unacceptable number of defects will be repaired or replaced under warranty.
  • Page 14 In order to qualify for repair or replacement due to pixel - Green + Blue = Cyan (Light Blue) defects during the warranty period, a TFT LCD panel in a Philips flat panel monitor must have pixel or sub pixel defects exceeding the tolerances listed in the following tables.
  • Page 15 Meridian 3 Bright Dot Defects Acceptable level 1 lit subpixel 2 adjacent lit subpixels 3 adjacent lit subpixels (one white pixel) Distance between two bright dot defects* >15mm Total bright dot defects of all types Black Dot Defects Acceptable level 1 dark subpixel 5 or fewer 2 adjacent dark subpixels...

  • Page 16: Failure Mode Of Panel

    Meridian 3 4.4 Failure Mode Of Panel Quick reference for failure mode of LCD panel this page presents problems that could be made by LCD panel. It is not necessary to repair circuit board. Simply follow the mechanical Polarizer has bubbles instruction on this manual to eliminate failure by replace LCD panel.
  • Page 22 D405 RLZ5.6B C429 NC/100N16V D404 RLZ5.6B C428 NC/100N16V D403 RLZ5.6B C427 NC/100N16V C426 100N16V C425 100N16V C432 NC/0.1UF50V D406 NC/RLZ5.6B...
  • Page 24 R617 NC/750R 1/10W 5% OUTR R616 NC/0R05 1/16W SE-1 R615 NC/750R 1/10W 5% OUTL R614 NC/0R05 1/10W R613 NC/0R05 1/10W...

  • Page 34: Pcb Layout

    Meridian 3 7. PCB Layout 7.1 Scaler Board 715G4872M0F000004I Remark: Parts position can be searched by using FIND function in PDF. CN410 CN701 CN408 SET5 CN411 SET2 SET3 C709 C437 C705 R470 FB606 C702 CN409 C701 R702 R752 SET11 Q702 C435 R717 U703...

  • Page 35: Power Board

    Meridian 3 7.2 Power Board Power 715G4750P02000001S Remark: Parts position can be searched by using FIND function in PDF. GND1 CN902 BD901 J905 C801 CN801 D902 D904 J801 R932 D901 L801 Q903 R935 Q901 ZD902 L901 C908 C927 FB801 F902 R919 R903 J904...
  • Page 36 Meridian 3 Converter 715G4711P0D0000040 Remark: Parts position can be searched by using FIND function in PDF. C813 C815 R814 C801 IC801 R825 L801 L802 R844 C811 C810 C804 CN804 CN805...
  • Page 37 Meridian 3 715G3918P03000004F Remark: Parts position can be searched by using FIND function in PDF. R810 C813 C808 C807 R801 R802 C801 Q801 F801 R825 IC802 IC801 L801 C811 R844 CN802 ZD801 R843 CN801 R830 C804 C810 CN805 CN803 CN804...

  • Page 38: Key Board

    Meridian 3 7.3 Key Board 715G4799K01000004F Remark: Parts position can be searched by using FIND function in PDF. R005 ZD002 CN001 U001 R001 R002 R003 ZD004 7.4 LED Board 715G4864T01000004F Remark: Parts position can be searched by using FIND function in PDF. LED001 CN002 7.5 Headphone Jack Board 715G4909T01000004S...

  • Page 39: Ir Board

    Meridian 3 7.6 IR Board (only for 247E3LPH) 715G4595R01000001S Remark: Parts position can be searched by using FIND function in PDF. U053 CN053 R065 C059 715G4813T01000004S Remark: Parts position can be searched by using FIND function in PDF. CN052 Q053 CN051 C053 ZD052...

  • Page 40: Wiring Diagram

    CN406 CN804...
  • Page 41 CN406 CN805...

  • Page 44: Mechanical Instructions

    Meridian 3 10. Mechanical Instructions Step 2: Remove the rear cover 1. Remove the one screw and open the latches along the red arrowhead direction as the picture to open other latches. Step 1: Remove the stand base ASSY 1. Place the monitor face on a safe surface, and remove the COVER HINGE.
  • Page 45 Meridian 3 247E3LPH Step 4: Remove the main_frame 1. Disconnect the FFC cable. 2. Disconnect the lamp cable. 247E3LH Step 3: Remove the bezel 1. Disconnect the cables and remove the two screws to remove the key board, two IR boards and LED board.
  • Page 46 Meridian 3 Step 5: Remove the boards 3. Disconnect all the connectors. 1. Remove the screws that secure the connectors. 247E3LH 247E3LH (four screws) 247E3LPH 247E3LPH (two screws) 2. Remove the screws to remove the power board and scaler board from the main frame. 247E3LH (eight screws) 247E3LPH (seven screws)

  • Page 47: Repair Flow Chart

    Meridian 3 11. Repair Flow Chart 1. No Power No power Check power cable is Re-plug the power cable tightened? Check Power “On/Off” Turn on the Power “On/Off” switch is “On”? Check the LED Check the AC power indicator is OK? Replace the power board and check connections Replace main board and check connections Replace key board and check connections...
  • Page 48 Meridian 3 No Video (Power LED White) No Video (Power LED White) Press the power Replace the main board button is OK? Replace the power The end board and connection Replace the main The end board and connection Check the FFC cable Replace the FFC cable or panel or panel...
  • Page 49 Meridian 3 3. DIM DIM (image overlap, focus or flicker) Reset in factory mode The end Set to the optimal The end frequency, select the recommended frequency Readjust the phase and pixel The end clock in the user mode Pull out signal cable and Check the signal cable check “Self Test Feature and the PC...
  • Page 50 Meridian 3 4. Color is not optimal Color is not optimal Color shift Miss color Reset the factory mode Replace the signal cable In the user mode, set the “color settings” until customer satisfy The end Pull out the signal cable and check the screen color display is normal? Replace the signal cable or PC...

  • Page 51: Isp Instruction

    Meridian 3 12. ISP Instruction When do the parts, need the tools as follow: 1. An i486 (or above) personal computer or compatible. 2. Microsoft operation system Windows 95/98/2000/XP. 3. USB port driver and ISP tool “EasyWrite V2011.0209.exe” 4. ISP JIG (715GT089-B/C) x1 5.
  • Page 52 Meridian 3 Click “Finish” to complete the USB serial port driver installation.
  • Page 53 Meridian 3 12.3 Install the ISP tool Take 227E3L for example: 1. Double-click to install ISP program. 2. Double-click to run the ISP tool. 3. Set the parameters to restore the HDCP key if the monitor has DVI or HDMI port. (1) Click the “Option”...
  • Page 54 Meridian 3 4. Setup ISP tool. Click “Setup ISP tool” to open the configuration window. 5. Configuration for ISP tool. Tick “FTDI”.
  • Page 55 Meridian 3 6. Load the F/W you want to upgrade. 7. Start to program. Click “Auto” to start programming.
  • Page 56 Meridian 3 8. Programing success. There will be the message in the red frame after successful programming. 12.4 Check the FW version after upgrade. The way to open factory menu. 1. Connect the video source to monitor and AC on. 2.
  • Page 57 Meridian 3 Reset the factory setting Power on the monitor and open the user menu. Do factory reset: Setup – Reset – Yes. Factory reset will turn off “Burn in” mode which screen color switches among red, green, blue and black. 12.5 Troubleshooting: “CheckSum Comparing Fail!”...
  • Page 58 Meridian 3 monitor power off. In this situation, you may AC off the monitor for a while and then AC on to retry. Maybe the defect will be cured. (3) Change ISP JIG or cable. (4) Change PC.

  • Page 59: Ddc Instruction

    Meridian 3 13. DDC Instruction General DDC Data Re-programming In case the main EEPROM with Software DDC which store all factory settings were replaced because a defect repaired monitor’ the serial numbers have to be re-programmed. It is advised to re-solder the main EEPROM with Software DDC from the old board onto the new board if circuit board has been replaced, in this case the DDC data does not need to be re-programmed.
  • Page 60 Meridian 3 13.3 Prepare the EDID written 1. EDID file has been putted in the DDC folder. 2. The VgaSinglePort.exe is the EDID writing tool. 3. The two file must be putted together as below. 13.4 The process of writing EDID and SN Take 247ELH for example: 1.
  • Page 61 Meridian 3 2. Tick the “Analog +DVI”, and click “Loadfile” to set the parameters. 247ELH 247ELPH...
  • Page 62 Meridian 3 3. Click the “Next” to load the EDID file. 4. Select the “Philips 247ELH” and then click “OK”, the tool will read the EDID information:...
  • Page 63 Meridian 3 5. Choose the “Only connect VGA” and “Write SN”, and key in the date and the 14 digital S/N. Remark: Please turn on the monitor before clicking “Program”. Or you maybe write EDID fail. 6. Click the “Program” to start programming after monitor power on. When it shows “Analog: PASS!, SN write OK!, HDMI: PASS! and HDMI2: PASS!”.
  • Page 64 Meridian 3 13.5 Check the SN 1. Connect the video source and power on monitor. 2. Press the “MENU” button to enter the user menu and select “Input”, you can check the 14 digital SN. Take 227E3L for example: 3. If this SN number is the same as what we had written by EDID tool, the EDID and SN writing is completed finally. 13.6 Troubleshooting 1.
  • Page 65 Meridian 3 247E3LH EDID Analog 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F ----------------------------------------------- 00| 00 FF FF FF FF FF FF 00 41 0C 85 C0 6A B7 0A 00 10| 34 14 01 03 6E 34 1D 78 2A EE D5 A5 55 48 9B 26 20| 12 50 54 BD 4B 00 D1 C0 81 80 95 0F 95 00 B3 00 30| 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C 40| 45 00 09 25 21 00 00 1E 00 00 00 FF 00 31 31 31...
  • Page 66 Meridian 3 1024 x 768 @ 60Hz VESA 1024 x 768 @ 75Hz VESA 1280 x1024 @ 75Hz VESA Established Timings 3:00 <-Standard Timing Identification: -> 1920 x 1080 @ 60Hz 1280 x 1024 @ 60Hz 1440 x 900 @ 75Hz 1440 x 900 @ 60Hz 1680 x 1050 @ 60Hz <-Detailed Timing Descriptions: ->...
  • Page 67 Meridian 3 HDMI 1 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F --------------------Block 0-------------------- 00| 00 FF FF FF FF FF FF 00 41 0C 85 C0 6A B7 0A 00 10| 34 14 01 03 80 34 1D 78 2A EE D5 A5 55 48 9B 26 20| 12 50 54 BD 4B 00 D1 C0 81 80 95 0F 95 00 B3 00 30| 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C 40| 45 00 09 25 21 00 00 1E 00 00 00 FF 00 32 33 31...
  • Page 68 Meridian 3 <-Established Timings: -> Established Timings 1: BD 720 x 400 @ 70Hz VGA,IBM 640 x 480 @ 60Hz VGA,IBM 640 x 480 @ 67Hz Apple,Mac II 640 x 480 @ 72Hz VESA 640 x 480 @ 75Hz VESA 800 x 600 @ 60Hz VESA Established Timings 2:4B 800 x 600 @ 75Hz VESA...
  • Page 69 Meridian 3 Detailed Timing Blocks start at Byte: 22 DTV Underscan YES DTV Basic Audio YES YCbCr (4:4:4) YES YCbCr (4:2:2) YES <-Video Short Block Description: -> 640 x 480 P 59.94/60Hz 4:3 720 x 480 P 59.94/60Hz 4:3 720 x 480 P 59.94/60Hz 16:9 1920 x 1080 I 59.94/60Hz 16:9 720(1440) x 480 I 59.94/60Hz 4:3 720(1440) x 480 I 59.94/60Hz 16:9...
  • Page 70 Meridian 3 Detailed Timing Descriptions: 1280x720 @ 60Hz H Image Size: 521 mm V Image Size: 293 mm Pixel Clock: 74 Hz Refreshed Mode: Non-Interlaced Detailed Timing Descriptions: 720x576 @ 50Hz H Image Size: 521 mm V Image Size: 293 mm Pixel Clock: 27 Hz Refreshed Mode: Non-Interlaced Block1 Checksum: F9...
  • Page 71 Meridian 3 HDMI 2 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F --------------------Block 0-------------------- 00| 00 FF FF FF FF FF FF 00 41 0C 85 C0 6A B7 0A 00 10| 34 14 01 03 80 34 1D 78 2A EE D5 A5 55 48 9B 26 20| 12 50 54 BD 4B 00 D1 C0 81 80 95 0F 95 00 B3 00 30| 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C 40| 45 00 09 25 21 00 00 1E 00 00 00 FF 00 32 33 31...
  • Page 72 Meridian 3 <-Established Timings: -> Established Timings 1: BD 720 x 400 @ 70Hz VGA,IBM 640 x 480 @ 60Hz VGA,IBM 640 x 480 @ 67Hz Apple,Mac II 640 x 480 @ 72Hz VESA 640 x 480 @ 75Hz VESA 800 x 600 @ 60Hz VESA Established Timings 2:4B 800 x 600 @ 75Hz VESA...
  • Page 73 Meridian 3 DTV Underscan YES DTV Basic Audio YES YCbCr (4:4:4) YES YCbCr (4:2:2) YES <-Video Short Block Description: -> 640 x 480 P 59.94/60Hz 4:3 720 x 480 P 59.94/60Hz 4:3 720 x 480 P 59.94/60Hz 16:9 1920 x 1080 I 59.94/60Hz 16:9 720(1440) x 480 I 59.94/60Hz 4:3 720(1440) x 480 I 59.94/60Hz 16:9 1920 x 1080 P 59.94/60Hz 16:9...
  • Page 74 Meridian 3 H Image Size: 521 mm V Image Size: 293 mm Pixel Clock: 74 Hz Refreshed Mode: Non-Interlaced Detailed Timing Descriptions: 720x576 @ 50Hz H Image Size: 521 mm V Image Size: 293 mm Pixel Clock: 27 Hz Refreshed Mode: Non-Interlaced Block1 Checksum: E9...
  • Page 75 Meridian 3 247E3LPH EDID Analog 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F ----------------------------------------------- 00| 00 FF FF FF FF FF FF 00 41 0C 86 C0 6A B7 0A 00 10| 34 14 01 03 6E 34 1D 78 2A EE D5 A5 55 48 9B 26 20| 12 50 54 BD 4B 00 D1 C0 81 80 95 0F 95 00 B3 00 30| 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C 40| 45 00 09 25 21 00 00 1E 00 00 00 FF 00 31 31 31...
  • Page 76 Meridian 3 800 x 600 @ 75Hz VESA 1024 x 768 @ 60Hz VESA 1024 x 768 @ 75Hz VESA 1280 x1024 @ 75Hz VESA Established Timings 3:00 <-Standard Timing Identification: -> 1920 x 1080 @ 60Hz 1280 x 1024 @ 60Hz 1440 x 900 @ 75Hz 1440 x 900 @ 60Hz 1680 x 1050 @ 60Hz...
  • Page 77 Meridian 3 HDMI 1 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F --------------------Block 0-------------------- 00| 00 FF FF FF FF FF FF 00 41 0C 86 C0 6A B7 0A 00 10| 34 14 01 03 80 34 1D 78 2A EE D5 A5 55 48 9B 26 20| 12 50 54 BD 4B 00 D1 C0 81 80 95 0F 95 00 B3 00 30| 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C 40| 45 00 09 25 21 00 00 1E 00 00 00 FF 00 32 33 31...
  • Page 78 Meridian 3 <-Established Timings: -> Established Timings 1: BD 720 x 400 @ 70Hz VGA,IBM 640 x 480 @ 60Hz VGA,IBM 640 x 480 @ 67Hz Apple,Mac II 640 x 480 @ 72Hz VESA 640 x 480 @ 75Hz VESA 800 x 600 @ 60Hz VESA Established Timings 2:4B 800 x 600 @ 75Hz VESA...
  • Page 79 Meridian 3 DTV Basic Audio YES YCbCr (4:4:4) YES YCbCr (4:2:2) YES <-Video Short Block Description: -> 640 x 480 P 59.94/60Hz 4:3 720 x 480 P 59.94/60Hz 4:3 720 x 480 P 59.94/60Hz 16:9 1920 x 1080 I 59.94/60Hz 16:9 720(1440) x 480 I 59.94/60Hz 4:3 720(1440) x 480 I 59.94/60Hz 16:9 1920 x 1080 P 59.94/60Hz 16:9...
  • Page 80 Meridian 3 Pixel Clock: 74 Hz Refreshed Mode: Non-Interlaced Detailed Timing Descriptions: 720x576 @ 50Hz H Image Size: 521 mm V Image Size: 293 mm Pixel Clock: 27 Hz Refreshed Mode: Non-Interlaced Block1 Checksum: F9...
  • Page 81 Meridian 3 HDMI 2 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F --------------------Block 0-------------------- 00| 00 FF FF FF FF FF FF 00 41 0C 86 C0 6A B7 0A 00 10| 34 14 01 03 80 34 1D 78 2A EE D5 A5 55 48 9B 26 20| 12 50 54 BD 4B 00 D1 C0 81 80 95 0F 95 00 B3 00 30| 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C 40| 45 00 09 25 21 00 00 1E 00 00 00 FF 00 32 33 31...
  • Page 82 Meridian 3 <-Established Timings: -> Established Timings 1: BD 720 x 400 @ 70Hz VGA,IBM 640 x 480 @ 60Hz VGA,IBM 640 x 480 @ 67Hz Apple,Mac II 640 x 480 @ 72Hz VESA 640 x 480 @ 75Hz VESA 800 x 600 @ 60Hz VESA Established Timings 2:4B 800 x 600 @ 75Hz VESA...
  • Page 83 Meridian 3 DTV Basic Audio YES YCbCr (4:4:4) YES YCbCr (4:2:2) YES <-Video Short Block Description: -> 640 x 480 P 59.94/60Hz 4:3 720 x 480 P 59.94/60Hz 4:3 720 x 480 P 59.94/60Hz 16:9 1920 x 1080 I 59.94/60Hz 16:9 720(1440) x 480 I 59.94/60Hz 4:3 720(1440) x 480 I 59.94/60Hz 16:9 1920 x 1080 P 59.94/60Hz 16:9...
  • Page 84 Meridian 3 Pixel Clock: 74 Hz Refreshed Mode: Non-Interlaced Detailed Timing Descriptions: 720x576 @ 50Hz H Image Size: 521 mm V Image Size: 293 mm Pixel Clock: 27 Hz Refreshed Mode: Non-Interlaced Block1 Checksum: E9...

  • Page 85: White Balance, Luminance Adjustment

    Meridian 3 14. White Balance, Luminance Adjustment 1. Apparatuses and program: analyzer CA-210, PC, tool, FGA adjustment program (Philips LEDFGA.DDCI), Pattern generator. 2. Equipment installation: a. Connect analyzer CA-210 to PC by USB connector, install drive program CA-SDK Ver4.00 for CA-210 and restart PC after finish installing b.
  • Page 86 Meridian 3 5. Color Temp confirmation Connect the signal to the monitor, the monitor displays white-picture, use CA-210 to measure the Color Temp of the screen center and select the OSD to make sure whether the Color Temps accord with the SPEC. CIE coordinates 9300K 6500K/sRGB...

  • Page 88: Recommended & Spare Parts List

    Meridian 3 16. Recommended & Spare Parts List Recommended Parts List for 247E3LHSU/00 Item Location PCM CODES Description Remark FQ106 A34G2628AMCB1M0130 BEZEL L24WA-UPH1 FQ015 LEPCAQP1 LED BOARD ASSY FQ004 KEPCAQP3 KEY BOARD ASSY FQ014 HJPFAQP1 HEADPHONE JACK BOARD ASSY E750 750GBM236GEA12N000 LCD M236HGE-L10 C1 NB CMI E750...
  • Page 89 Meridian 3 U702 056G 563250 LDO LSP2159BD33AD TO-252 B-TY 1.5A/3.3V U704 056G 563506 IC AME8815BECS180Z TO-252 AME U601 056G 616110 AUDIO PAM8007NHR 3W SSOP-24 U106 056G 662 21 IC AOZ8804DI DFN-10 U107 056G 662 21 IC AOZ8804DI DFN-10 U110 056G 662 21 IC AOZ8804DI DFN-10 U112 056G 662 21...
  • Page 90 Meridian 3 FQ105 A34G2629AFLA3B0100 REAR COVER L24WA-Uph1 FQ110 A37G0265011 HINGE_24" FQ126 A34G2630AFL 1B0100 STAND FQ109 A34G2631AFL 1B0120 BASE L24WA-S1 FQ007 IRPCAQA7 IR BOARD ASSY FQ007 IRPCAQT1 IR BOARD ASSY E08902 089G 725LAA 2G D-SUB CABLE 1500MM E08901 089G404A15N HL AC POWER CORD 1500MM ECN602 095G8014 5D 66 HARNESS 5P-5P 200MM FQE102634I...
  • Page 91 Meridian 3 IC901 056G 379190 AC/DC CONVERTER LD7750RGR SOP-7 F901 084G 56 4 B FUSE 4A 250V F902 084G 56 4 B FUSE 4A 250V Spare Parts List for 247E3LPHSU/93 Location PCM Codes Description E08902 089G 725HAA 2G D-SUB CABLE 1500MM E08902 089G 725LAA 2G D-SUB CABLE 1500MM...
  • Page 92 Meridian 3 C435 067G315M1013HV 105°C 100UF,M,16V C601 067G315M2213HV EC 220UF 20% 16V 6.3*7 CN101 088G 35315FVCL HF HF D-SUB CONN V/T 15P BLUE H=10.4 CN101 088G 35315FVXH HF D-SUB CONN V/T 15P BLUE H=10.5 HF X401 093G 2251B J CRYSTAL 12MHZ NXS12.000AC30F-KAB10 CN409 311GW200C30ABL WAFER 2.0mm 2*15P...
  • Page 93 Meridian 3 R606 061G0402471 JF RST CHIPR 470 OHM 5% 1/16W FENGHUA R606 061G0402471 JT RST CHIP 470R 1/16W 5% TZAI YUAN R122 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA R460 061G0402472 JT RST CHIP 4K7 1/16W 5% TZAI YUAN R705 061G0402473 JF RST CHIPR 47KOHM +-5% 1/16W FENGHUA...
  • Page 94 Meridian 3 C603 065G120622615K CAP CHIP 1206 22UF K 16V X5R FB606 071G 56K121 HF CHIP BEAD 0805 120R 25% FB606 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF FB106 071G 59G301 CHIP BEAD CHIP BEAD 300 OHM 0603 FB105 071G 59G301 TA CHIP BEAD 300OHM 200mA FCM1608KF-301T02 FB101...
  • Page 95 Meridian 3 U001 056G 669 10 TOUCH KEY CG7246AMT QFN-16(COL) R005 061G0402561 JF RST CHIP 560R 1/16W 5% FENGHUA R001 061G0402561 JI RST 0402 560R 5% 1/16W R006 061G0603681 JI RST 0603 680R 5% 1/10W R006 061G0603681 JT RST CHIPR 680OHM +-5% 1/10W TZAI YUAN C001 065G040210232K CAP CHIP 0402 1N 50V X7R +/-10%...
  • Page 96 Meridian 3 D903 093G 60507 SCHOTTKY SRF1060 C0 10A 60V ITO-220AB D903 093G 60526 SCHOTTKY MBRF1060CT ITO-220AB D901 093G 52 66 DIODE FMX-12SL 10A/200V TO-220 D901 093G 60943 DIODE SFF1004G ITO-220AB D901 093G 60978 RECTIFIER UF1002FCT 10A 200V ITO-220AB C813 067G 4151017KV EC 100uF 50V ED 8*12 C810...
  • Page 97 Meridian 3 R940 061G0805102 JT RST CHIPR 1K OHM +- 5% 1/8W TZAI YUAN R931 061G0805104 JF RST CHIPR 100KOHM +-5% 1/8W FENGHUA R931 061G0805104 JT RST CHIPR 100KOHM +- 5% 1/8W TZAI YUAN R921 061G08051501FT RST CHIPR 1K5 +-1% 1/8W TZAI YAUN R921 061G08051501FY RST CHIP 1K5 1/8W 1%...
  • Page 98 Meridian 3 F901 084G 56 4 B FUSE 4A 250V F901 084G 56 4W FUSE 4A 250V ZD902 093G 3916352T ZD TZX22B ZD902 093G 39A6852T ZENER DIODES MTZJ22B DO-34 D904 093G 6452452T SWITCHING 1N4148-B4006 0.2A 100V DO-35 R919 061G152M47852T SY RST MOFR 0.47 OHM +-5% 2WS FUTABA R919 061G152M47852T HX...
  • Page 99 Meridian 3 R845 061G06031000FF RST CHIPR 100 OHM +-1% 1/10W FENGHUA R845 061G06031000FT RST CHIP 100R 1/10W 1% R812 061G06031000FT RST CHIP 100R 1/10W 1% R810 061G06031001FF RST CHIPR 1 KOHM +-1% 1/10W FENGHUA R810 061G06031001FT RST CHIP 1K 1/10W 1% R806 061G06031002FF RST CHIPR 10 KOHM +-1% 1/10W FENGHUA...
  • Page 100 100 Meridian 3 C812 065G080510131J CAP CHIP 0805 100P 50V NP0 +/-5% C803 065G080522141J CAP CHIP 0805 220P 100V NP0 +/-5% C806 065G080522522K CAP CHIP 0805 2.2uF K 25V X7R C807 065G080522522K CAP CHIP 0805 2.2uF K 25V X7R C806 065G080522522K CAP CHIP 0805 2U2 25V X7R +/-10% C807...

  • Page 101: General Product Specification

    All optical characteristics are determined according to panel specification after warming up longer than 30 minutes. Product Profile EDID Header 247E3LH User visible strings on .inf file Philips 247ELH (24inch Wide LCD MONITOR 247E3LH) Manufacturer ID ( EDID data) Product ID, "xxxx" 4 codes MSB(byte 12): C0 LSB (byte 11): 85...
  • Page 102 Scaler should be capable of below items. 1) Scaler must support color engine for Image enhancement feature (SmartImage) 2) Scaler must have enough memory to support PerfecTune feature and Philips OSD 3) Scaler must support SmartContras,500K:1 DCR preferred 4) VGA signal Auto adjustment: Monitor automatically adjusts and optimizes resolution and frequency based on input signal defined by “Source”...
  • Page 103 Meridian 3 103 Vsync Positive/Negative Composite sync TTL level, input impedance 2.2k ohm terminate (Positive/Negative) Sync on green video 0.3 Vp-p Negative (Video 0.7 Vp-p Positive) 2). DVI-D Digital Input signal: Single TMDS link (Three channels: RX0-/+, RX1-/+, RX2-/+) 3) HDMI ( option , refer to Quick specification table) Follow HDMI 1.4 specification TMDS channel: Carries audio, video and auxiliary data.
  • Page 104 104 Meridian 3 Common Mode Voltage: – 300mV) – (AV – 37.5mV) Differential Sensitivity: 150mVp-p Maximum differential Voltage: 1560mVp-p (+5V Power) Power Supply Voltage: 4.7V – 5.3V Maximum Current Consumption: 50mA (DDC Signal) Maximum Capacitance: 50pF (HPD Signal) High Voltage Level: 2.4V –...
  • Page 105 Meridian 3 105 Pin assignments: Pin No. Signal Green/ SOG Blue Sense (GND) Cable Detect (GND) Red GND Green GND Blue GND DDC +3.3V or +5V Logic GND Sense (GND) Bi-directional data H/H+V sync V-sync Data clock DVI Cable The input signals are applied to the display through DVI-D cable. Length : Please refer to M3 cable bundle summary file Connector type...
  • Page 106 106 Meridian 3 White connector thumb-operated jackscrews with transplant pin protective cover. Pin Assignment: Pin No. Description TMDS Data2+ TMDS Data2 Shield TMDS Data2– TMDS Data1+ TMDS Data1 Shield TMDS Data1– TMDS Data0+ TMDS Data0 Shield TMDS Data0– TMDS Clock+ TMDS Clock Shield TMDS Clock–...
  • Page 107 Spanish, Italian, Russian, OSD Translation Simplified Chinese, Portuguese, Turkish (9) OSD TREE Power On Logo: Power On Show up Philips logo 3 seconds Change to input signal. Power On logo This picture is reference only. The official drawing will send out by PM.
  • Page 108 108 Meridian 3 EPA 5.0 spec. as below Panel size Native resolution Max. Power (W) 16"(16:9) 1366x768 14.5 17"(4:3) 1280x1024 21.9 17"(16:10) 1440x900 21.2 18.5"(16:9) 1366x768 16.6 19"(16:10) 1440x900 22.7 19"(4:3) 1280x1024 23.6 20"(16:10) 1680x1050 20"(16:9) 1600x900 24.5 22"(16:10) 1680x1050 22"(16:9) 1920x1080 31.6...
  • Page 109 Meridian 3 109 Audio 3.17.1 Frequency Response The amplifier and speaker combination shall provide a frequency response of 300 Hz to 20 kHz, with +/- 3 dB variation over the entire response range. 3.17.2 Total Harmonic Distortion Total harmonic distortion shall be limited to 5% THD at the maximum wattage speaker rating specified in section 1.3, at 1 kHz, when the input is 1.0Vrms.
  • Page 110 110 Meridian 3 User must be detected in the following range: 40 up to 100 cm (+ 20cm). Detection angle: +- 35 degree (for IR LED) SENSOR key control, Adjust detection distances (0~4 scales), default is 3, tolerance: (±10cm) 0: 0FF 1: 90 cm 2: 100 cm 3: 110 cm...

  • Page 111: Visual Characteristics

    Meridian 3 111 Fig. 2: 2 monitors standing back to back. The monitors may influence each other. So Monitor 1 may produce unexpected brightness-switches in monitor 2 (and vice versa). Furthermore, user 1 could perhaps (via monitor 1) influence the powersensor readout on monitor 2. Fig.
  • Page 112 Mechanical Characteristics Cosmetic - Philips ID Mechanical data files - ProE files required Location of Philips logo - Per Philips make-up sheet Between panel and front bezel 19"W: 0.2mm<GAP< 1.0mm, 20"W: 0.2mm<GAP<1.2mm Between bezel and rear cover: 0.4mm (without art groove) Between rear cover and AC socket: 1.0mm...
  • Page 113 Base / Pedestal to be Flame Retardant UL 94-HB. All major plastic parts (bezel, back cover) need to be molded from same resin. Plastic resin type selection should be referred to “plastic-Philips Pool monitor”. Texture/Glossing of housing The texture area and texture no should follow Philips make-up sheet.
  • Page 114 Tilt 2,000 times, can’t appear mechanical problem Kensington Lock Must meet Kensington_slot.spec “TYE-M0004”. MMD request metal plate in Kensington hole. Product dimension / Weight (Refer to Philips approved SHT 191/SHT560) Black rim with assembly (L/R) <2.0mm (Top/Bottom) <2.5mm Display Oblique <1mm difference between L&R of upper and lower profile...
  • Page 115 3. Cold Drop test (for design reference) Un-package test 1. Sine vibration (operating) 2. Half sine shock test (non operation) Pallet / Container loading (Refer to Philips approved SHT 560) Transportation standards refer to TYE-M0002, UAN-D1534 and UAW-0309. Air shipment - Sea container 20'(pallet/slip sheet)
  • Page 116 Base / Pedestal to be Flame Retardant UL 94-HB. All major plastic parts (bezel, back cover) need to be molded from same resin. Plastic resin type selection should be referred to “plastic-Philips Pool monitor”. Texture/Glossing of housing The texture area and texture no should follow Philips make-up sheet.
  • Page 117 Detail document refer to Philips Engineering Reference Book. Kensington Lock Must meet Kensington_slot.spec “TYE-M0004”. MMD request metal plate in Kensington hole. Product dimension / Weight (Refer to Philips approved SHT 191/SHT560) Transportation Transportation standards refer to UAN-D1534/00/01/02. Transportation packages Net weight Packaging and wrapping shall be sufficient to protect the product against damage or loss during shipment from the supplier to the destination specified in the purchase order.

  • Page 118: Environmental Characteristics

    118 Meridian 3 Sea container 20'(pallet/slip sheet) Sea container 40'(pallet/slip sheet) Sea container 40' High Cube (pallet/slip sheet) Land 45‘ Truck and Trailer (800X1200mm pallet) Land 45‘ Truck and Trailer (1000X1200mm pallet) for UK Truck shipment- Transportation request for all regions except China/India C.
  • Page 119 4. When the HV circuitry is operating properly there is no possibility of an x- tube must be the same type as the original, including suffix letter, or a Philips radiation problem. High voltage should always be kept at the manufacturer's approved type.
