Getting started

1

Removal of transit bolts

The washing machine comes fitted with transit bolts*
to prevent any internal damage during transport.
• All transit bolt assemblies must be removed before installation.
• If the transit bolts are not removed and the machine is operated with them
fitted it will cause damage, excess vibration and noise.
• All transit bolt assemblies should be kept and re-used when transporting
your washing machine in the future.
1.
Using a 10mm spanner
(supplied), loosen the
transit bolt assembly by
25mm.
25mm
DO NOT unscrew the bolt
all the way out as this will
cause the bolt to separate
inside your machine
*9kg versions come with 5 transit bolts. All other models have 4 bolts.
8
2.
Ease out and remove the
transit bolt assembly by
twisting and pulling on the
section highlighted in red
on the diagram.
3.
Insert the transit bolt
cover caps supplied to
cover the holes.
