ACCESSORIES

ADDITIONAL CONTROL PANEL

The controller may be equipped with an additional control panel – the Pellets
control 420. The panel may be installed in another location, e.g. in a flat, for
remote control of the system. For additional information, please contact estyma
electronics – see the contact details on the last page of this manual.

ROOM TEMPEATURE REGULATOR

The M RS ESTYMA controller can work with any temperature room regulator with
closing contacts.
Figure: Connection of a room regulator
Operation manual for M RS 420 ESTYMA control unit
The room regulator should be installed in a
location which is representative in terms of
the temperature in the flat, at a height of
1.5 – 2m.
Do not install the regulator near heat
sources (e.g. TV set, radiators), in places
exposed to direct
draughts, as it will adversely affect the
performance of the system.
solar radiation or
9
