To dim the display lights on a Pioneer AVH-2330NEX, touch the hard key on any source to bring up the on-screen controls. Then, press the button that appears on the left side to switch the dimmer on or off. When the dimmer is on, the display becomes dimmer. Touch the button again to restore brightness. The sub-display will disappear after a few seconds if not interacted with.

This answer is automatically generated

Shane Wallace

March 13, 2025

Applying and reapplying the parking brake still does not give me access to the Bluetooth settings

2 comments:

Mr. Anderson

March 13, 2025

If you cannot access the Bluetooth settings on your Pioneer AVH-2330NEX after applying the parking brake, ensure that the parking brake is fully engaged. The system disables certain functions, including Bluetooth settings, unless the parking brake is applied. If the settings remain grayed out, check if the parking brake wiring is correctly connected or if there is an issue with the parking brake switch.

This answer is automatically generated

Shane Wallace

March 13, 2025

@Mr. Anderson I'm not having any luckies in the parking brake is there another way to go around using the parking brake

Alan

April 8, 2025

preset radio channels

1 comments:

Mr. Anderson

April 9, 2025

To preset radio channels on the Pioneer AVH-2330NEX:

1. Tune to the desired radio channel using the arrow keys or by directly entering the channel number.
2. Press and hold one of the preset buttons (e.g., number 1 to 6) for a few seconds.
3. The selected channel will be saved to that preset button.

Alternatively, you can use the BSM (Best Stations Memory) function:

1. Touch the BSM option to begin the search.
2. The system will automatically store the six strongest broadcast frequencies under preset buttons 1 to 6.

Note: Using BSM may overwrite existing presets.

This answer is automatically generated
