Inspire Ignite Wireless User Manual

Ignite Wireless User Guide Rev 1.0
Connecting to WiFi
Before you can register this device, you must first connect it to your WiFi network. WPS is
the simplest way to do this. Alternatively you can use access point mode, which is more
involved.
Before starting, ensure that the Thermostat is connected to your Relay Module. Ensure that
the unit shows a signal strength and that the Relay Module is powered up. If you put the
batteries in the Thermostat before powering the Relay Module, it may take upto 10 minutes
to connect.
You should find a WPS button on your router. If you are unsure where the WPS button is, or if
your router supports this, consult your router manual.
The button or a light on the router will normally flash to indicate that it is in WPS mode. This
will usually timeout after 2 minutes.
With the router in WPS mode, press pairing button (Middle) on the Relay Module, this will
make all 3 lights flash green. Press the middle button again, now just the middle light will
be flashing. Once synced the middle light will turn alternate colours.
Access Point
You should ONLY use this if your router doesn't support WPS, or if you have tried this several
times and it has failed to connect.
Press pairing button (Middle) on the Relay Module, this will make all 3 lights flash green.
Then press and hold middle button for 5 seconds, all 3 lights should now be solid amber.
Shortly a new open WiFi network will appear called Inspire, connect to this WiFi network,
and browse to http://inspirehomeauto.co.uk
Select your router from the list provided and enter your WiFi password. This can usually be
found on your router.
Click 'Add'
If this doesn't connect, double check your password and try again. Please note, passwords
are case sensitive.
1
