Operation

Switch Operation
1. Depress the trigger switch slightly to start the tool slowly.
2. The speed increases with the amount of depression of the trigger for effi-
cient tightening of screws and drilling. The brake operates and the chuck
stops immediately when the trigger is released.
Reversing Switch Operation
(Forward ( ), Switch Lock, Reverse ( ))
CAUTION!
Do not operate reversing lever until the chuck comes to a complete stop. Shif-
ting during rotation of the chuck may damage the tool.
1. For reverse rotation, set the lever to reverse. Check the direction of ro-
tation before use.
2. After use, set the lever to its center position (switch lock). (Fig. 6)
Speed Selection
Choose a low or high speed to suit the job.
CAUTION: Check the speed selector switch before use.
Clutch Torque Setting
Adjust the torque to one of the 18 possible settings or " " position to the job.
CAUTION! Test the setting before actual operation. (Fig. 7)
Note:
When the brake operates, a braking sound may be heard. This sound indica-
tes engagement of the bit lock.
CAUTION:
●
To eliminate excessive temperature increase of the tool surface, do not
operate the tool continuously using two or more battery packs. Tool needs
cool off time before switching to another pack.
●
Do not close up vent holes on body sides of the body during operation.
Otherwise, the machine function is adversely affected to cause a failure.
●
Do NOT strain the tool (motor). This may cause damage to the unit.
●
Use the machine in such a way as to prevent the air from the body vent
holes from blowing directly or to your skin. Otherwise, you may get burnt.
● When operating with a Ni-MH battery pack, make sure the place is well-
ventilated.
For Appropriate use of Battery pack
NI-MH Battery Pack
●
Charge the Ni-MH battery fully before storage in order to ensure a longer
service life.
●
The ambient temperature range is between 0°C and 40°C.
If the battery pack is used when the battery temperature is below 0 °C, the
tool may fail to function properly. In that case, charge the battery until char-
ging is completed for appropriate functioning of the battery.
Battery Pack Life
The rechargeable batteries have a limited life. If operation time becomes ex-
tremely short after recharging, replace the battery pack with a new one.
Note:
●
Use under extremely hot or cold conditions will reduce operating capacity
per charge.
●
Battery pack contain Nickel-Cadmium batteries.
The batteries must be recycled or disposed of properly.
11
