Summary of Contents for SED GPH-610R

  • Page 1: User Manual

    SED GPH-610R User Manual www.malux.se...
  • Page 2 www.malux.se...
  • Page 3 SED GPH-610R User Manual - 1 - www.malux.se...

  • Page 4: Table Of Contents

    SED GPH-610R User Manual Contents WARNING ............................- 7 - CHAPTER 1 GETTING STARTED ....................- 8 - ........................- 8 - AFETY RECAUTIONS (SAR) ................- 10 - PECIFIC ABSORPTION RATE INFORMATION ........................- 11 - NVIRONMENTAL CARE ........................- 12 - RODUCT DISPOSAL ..........................
  • Page 5 SED GPH-610R User Manual Making an Emergency Call ....................- 29 - Viewing Missed Calls ......................- 29 - Menu during a Point-to-Point call ..................- 31 - Managing Multiple Calls ......................- 31 - 2.4 GSM-R O ......................- 32 - PERATIONS Initiating a point-to-point call ....................
  • Page 6 SED GPH-610R User Manual Input Language Support ......................- 39 - Switching Between Input Modes ................... - 39 - Word input ..........................- 39 - Alphabet input ........................- 40 - Switching between abc/ABC ....................- 41 - Number input ......................... - 41 - Sign ............................
  • Page 7 SED GPH-610R User Manual 4.5 SMS ............................- 54 - Write Message ........................- 54 - Inbox ............................- 55 - Outbox ........................... - 57 - Archive Box ........................... - 57 - Template ..........................- 58 - 4.6 S ..........................- 58 - ETTINGS Broadcast ..........................
  • Page 8 SED GPH-610R User Manual Cell Lock (Optional) ....................... - 67 - 4.8 S ..........................- 67 - ETTINGS Profiles ........................... - 67 - Display ........................... - 68 - Tone Setup ..........................- 70 - Security Setup ........................- 70 - Phone Setup ..........................

  • Page 9: Warning

    No part of this manual may be reproduced in any form or by any means without the written consent of Shenzhen SED Wireless Communication Technology Co., Ltd. This manual describes the features and functions of the SED GPH-610R handheld only. Due to product version upgrades or other reasons, this manual is subject to change without notice. Unless otherwise stated, this manual serves only as an instruction manual.

  • Page 10: Chapter 1 Getting Started

    SED GPH-610R User Manual Chapter 1 Getting Started The wireless device described in this manual the handheld or its accessories. Improper use runs on GSM-R networks. For more information by children may damage the handheld or its about applicable networks, consult your service accessories and cause injuries.
  • Page 11 SED GPH-610R User Manual vehicle at the roadside before using the dangerous substances, such as fuel and handheld. chemical reagents. Do not place your handheld above or near the Hospitals: airbag when it is unfolded, as the expanded Switch off your handheld in hospitals and near...

  • Page 12: Specific Absorption Rate (Sar) Information

    Temperature range: Improper use of battery may cause danger. Use The temperature range for using the handheld chargers approved by Shenzhen SED Wireless is -20° C to +55° C and the ambient temperature Communication Technology Co., Ltd. for adapter operation is 0° C to +40° C (Relative Humidity 20% to 80%).

  • Page 13: Environmental Care

    Environmental care waves. The highest SAR value for the GPH-610R Observe local regulations regarding the handheld when tested for compliance against disposal of packaging materials, exhausted the standard is 0.652 W/kg for ICNIRP batteries and old handhelds and promote their recommendation.

  • Page 14: Product Disposal

    SED GPH-610R User Manual Do not dispose of the battery with the product, it means the product is covered by the general household waste. European Directive 2002/96/EC. Please be aware of the local collection regulations for electrical and electronic The packaging material is recyclable.
  • Page 15 SED GPH-610R User Manual Declaration of Conformity Shenzhen SED Wireless Communication Technology Co., Ltd. 11/F,SED Science and Technology Building, Nanshan District, Shenzhen 518000 China declare under our sole responsibility that the product SED GPH-610R R-GSM 900/DCS 1800 is in conformity with the following standards:...
  • Page 16 SED GPH-610R User Manual The product is marked with CE and the Notified Body number according to the Directive 1999/5/EC: Date: 20 May 2014 Authorization: Signature: Name: Frank HE Position: Vice President - 14 - www.malux.se...

  • Page 17: Your Handheld

    SED GPH-610R User Manual Your Handheld Indicator Light sensor Earpiece Volume keys PTT key Emergency call prompt Left soft key Right soft key Call key Hang up/power key Microphone Socket - 15 - www.malux.se...
  • Page 18 SED GPH-610R User Manual Loud speaker Camera Battery and rear cover Note: The pictures in this manual are for function illustration purposes only and may differ from your handheld. - 16 - www.malux.se...

  • Page 19: Description Of Icons

    SED GPH-610R User Manual Description of Icons Signal strength: The number of strips indicates the signal strength in ascending order. Network not found: The handheld is out of network coverage. Manual select mode: The manual network selection mode is active.
  • Page 20 SED GPH-610R User Manual Roaming: The handheld is in roaming mode. Power on attaching: GPRS will be attached when powered on. GPRS attached: GPRS is attached successfully. GPRS activated: The GPRS function has been activated and data is being transmitted.
  • Page 21 SED GPH-610R User Manual Cell lock or Cell forcing has been open - 19 - www.malux.se...

  • Page 22: Preparations

    SED GPH-610R User Manual Preparations Insert a valid SIM card before using the handheld. SIM cards are provided by network service providers. Note: Keep SIM cards beyond the reach of children. Installing the SIM card and battery 1. Press the button on the rear case, and 2.
  • Page 23 SED GPH-610R User Manual Ensure that the gap in your SIM card and the gap for the SIM card slot point in the same direction and that the side with a metal part faces down. Then slide the SIM card into the SIM card slot.
  • Page 24 SED GPH-610R User Manual Insert the battery into the space, position the rear case on the back of the handheld, and push it upward to attach to the handheld. - 22 - www.malux.se...

  • Page 25: Charging The Battery

    Connect the charger to the socket at the bottom of the handheld. Ensure that the side marked with “SED” on the charger is consistent with the front of the handheld. Plug the charger connector into the power socket. After the handheld indicates that charging is complete, remove the charger from the handheld and then remove the other connector from the power socket.

  • Page 26: Chapter 2 Basic Operations

    SED GPH-610R User Manual After the PIN check succeeds, your handheld Chapter 2 Basic Operations will connects to the network. Note: If you enter incorrect PINs three times 2.1Switching On/Off consecutively, the screen displays the message that the PIN is locked. You need to enter you Starting up personal unlock code (PUK).

  • Page 27: Handheld Modes

    SED GPH-610R User Manual 2.2 Handheld Modes Call Mode When you make or answer a call, the handheld Standby Mode enters call mode. Standby is the basic mode. After you switch on 2.3 Basic Call Functions your handheld, the handheld enters standby mode.
  • Page 28 SED GPH-610R User Manual - 26 - www.malux.se...

  • Page 29: Answering A Call

    SED GPH-610R User Manual Using the Phonebook to Make Calls Answering a Call Select a phone number from the phonebook to When receive an incoming call, the handheld make a call, and then displays information about the call. If you have...
  • Page 30 SED GPH-610R User Manual During the call, the duration of the call and the caller number are displayed on the screen (if the number is in your phonebook, the name is displayed). Note: An incoming call will interrupt any other menu operation or function.

  • Page 31: Ending A Call

    SED GPH-610R User Manual Ending a Call Note: After the handheld enters the hands-free mode, the speaker may be loud. Therefore, do  Press To end a call. not place the handheld near your ear before After the call ends, the duration of the call pressing the hands-free key.
  • Page 32 SED GPH-610R User Manual  Press in the list of missed calls to display details about each missed call, including the phone numbers of missed calls, and the time of the last three missed calls from a single number and the missed call times.

  • Page 33: Menu During A Point-To-Point Call

    SED GPH-610R User Manual Menu during a Point-to-Point call 3 Drop Hold: Drops the held call. 4 Drop All: Drops all ongoing and held calls. During an ongoing call, you can press 5 Build Multi-Call: Sets up triple calls in to enter a menu.

  • Page 34: Gsm-R Operations

    SED GPH-610R User Manual 2.4 GSM-R Operations Initiating a point-to-point call The GSM-R function is a dedicated function of In standby mode, you can input the phone this handheld, specifically designed and number, short number or function number of developed for railway-related services. It needs...

  • Page 35: Initiating A Railway Emergency Call

    SED GPH-610R User Manual initiate a broadcast call by selecting the call as follows: broadcast call in the menu. You can also Press during the ongoing group call. choose Main Menu > GSM-R > Group Calls The screen informs you that means and select Broadcast.

  • Page 36: Exiting A Broadcast Call

    SED GPH-610R User Manual Press during the ongoing group  call. The screen informs you that means ‘Close’, and means ‘Leave’. Press to exit the group call. The recipients of the group call can Press to exit the group call.

  • Page 37: Occupying Uplink During An Ongoing Group Call

    SED GPH-610R User Manual 2 During a group or broadcast call, you can ongoing broadcast call. enter the number of the group call or broadcast Receiving a point-to-point call in an ongoing call in standby mode. The handheld automatically joins the group call or broadcast group call or broadcast call call.

  • Page 38: Receiving A Group/Broadcast Call During A Group/Broadcast Call

    SED GPH-610R User Manual After viewing the alert tone message of a new Receiving a group/broadcast call during a point-to-point call, group/broadcast call Press to answer this call or  If you receive the alert tone for a new group call press to reject the call.

  • Page 39: Receiving A Group/Broadcast Call In An Ongoing Point-To-Point Call

    SED GPH-610R User Manual Receiving a group/broadcast call in an Automatic high-priority answering ongoing point-to-point call If the priority of a call received in idle mode meets automatic answering, your handheld If you receive the alert tone of a group call or automatically answers this call.

  • Page 40: Operation Of Function Numbers

    SED GPH-610R User Manual Operation of function numbers In standby mode, you can directly enter the character string of a function number and then press to register, de-register, interrogate, or forcibly de-register the function number. You can also choose Identity to perform operations related to the function number.

  • Page 41: Chapter 3 Input Modes

    SED GPH-610R User Manual Input Language Support Chapter 3 Input Modes This handheld supports English, German. Switching Between Input Modes When using a handheld, you need to input text When you access text input, the current input information from time to time. For instance, mode is displayed at the bottom of the screen.

  • Page 42: Alphabet Input

    SED GPH-610R User Manual You can press up or down button to view words, Alphabet input and press OK button to select words, and then use numberic button to input words. The alphabet input mode has alphabets of different languages. After entering the alphabet input mode, press the corresponding number key for a letter to enter that letter.

  • Page 43: Switching Between Abc/Abc

    SED GPH-610R User Manual signs: press once to enter A, press it quickly Press the up or down key to select a line,  twice to enter B, and three times to enter C. and then press the corresponding number Switching between abc/ABC key to enter the desired digit.

  • Page 44: Chapter 4 Menu

    SED GPH-610R User Manual settings. If a menu option is marked by a digit, you can also press the number key to select Chapter 4 Menu the option. Entering a menu by shortcut 4.1 Using a Menu In standby mode, you can press shortcut keys to enter menus or sub-menus.

  • Page 45: Maintenance

    SED GPH-610R User Manual of your SIM card. interface and press to initiate a call. 1 Group Call: This menu lists activated group 4 BCT ID Management: This item lists the call numbers provided by the SIM card. You broadcast numbers provided by the SIM can select one number and press card.
  • Page 46 SED GPH-610R User Manual C1, C2, FNO, QBO, BSIC, RM, TX. 1 Train Emergency GC: You can use this 4 Working Alone: You can process working alone related setting menu to make Emergency GC active/inactive in SIM card. in this menu item.
  • Page 47 SED GPH-610R User Manual (1) The handset will start pre-alarming still motionless. The handset will once the handset has detected the vibrate continuously after entering operator is in danger. The t1 phase. pre-alarm state has two phases: t0 (2) If the operator is detected to still be and t1.
  • Page 48 SED GPH-610R User Manual will last 30 seconds. preset repetition time and start (3) If the operator is detected to still be remote alarming again. in danger after local alarming, the Note: The operator will only receive emergency handset will start remote alarming calls and allowed incoming calls after alarming started.

  • Page 49: Identity

    SED GPH-610R User Manual (1) Long pressing SLEFT key, an 4.3 Identity inquiry box will be popup. If your SIM card can register a function number, you can perform operations related to function (2) Start working alone alarm after the numbers through this menu.
  • Page 50 SED GPH-610R User Manual confirm the registration. The handheld sends a registration request to the network. The result is displayed in a pop-up box on the screen. Note: The result of function number registration depends on network conditions and the validity of the function number.
  • Page 51 SED GPH-610R User Manual displayed in a pop-up box on the screen. Note: When entering the FN number, you can press to open a list and select it from the list. 3) EFN: Refer to TFN. 4) CFN: Refer to TFN.
  • Page 52 SED GPH-610R User Manual numbers of other users, you can forcibly de-register a certain function number of a certain user. The MSISDN input window and the function number input window are available. Press to de-register the numbers after confirming that the numbers are correct.

  • Page 53: Names

    SED GPH-610R User Manual 4.4 Names number and the functional identity are transferred via UUIE. If several functional You can use the phonebook in the SIM card registrations were made, the most recently and that in the handheld to store contact registered number is transferred.

  • Page 54: View

    SED GPH-610R User Manual also prompt you to match multiple letters. window is displayed. After entering a message, select the related number to send the message During record browsing, you can press (if the current record is related to only one to dial the number of the present record.

  • Page 55: Write Sms

    SED GPH-610R User Manual 6 Send vCard: Select this option to send the storage status of the phonebooks, including the information of the current contact in vCard SIM card capacity and the handheld capacity. format. My vCard Write SMS You can use this item to maintain your name Select this option to send a text message to card.

  • Page 56: Delete All

    SED GPH-610R User Manual card. 4.5 SMS The SMS is a network service. The network you Note: When you copy a record in the handheld are using may not support this service. For to the SIM card, the name and phone number details, contact your network operator.

  • Page 57: Inbox

    SED GPH-610R User Manual modes, such as Smart German, German 2) Insert vCard: Select a contact number alphabet, Smart English, English alphabet, from the phonebook and send it in vCard and 123. format. 3) Phrase: Select a phrase coming with ...
  • Page 58 SED GPH-610R User Manual Press to view the short message, or Unread Updated long press to choose one of the following options: Partial 1 View: Views a message. Read SMS received long 2 Reply: Replies a message to the sender.

  • Page 59: Outbox

    SED GPH-610R User Manual Outbox When you read a message, press to send it. press to choose one of the Messages in the outbox marked with following options: 1 Forward: Forwards the message to others. have been sent. Messages marked with 2 Delete: Deletes the selected message.

  • Page 60: Template

    SED GPH-610R User Manual Template 4.6 Settings You can use common short messages as a You can set all parameters related to short template through this function. Select Template messages. Short messages are sent and in the Message menu to access a list of SMS received according to the parameter settings.

  • Page 61: Broadcast

    SED GPH-610R User Manual period is “1 Week”. traffic services may be available. Received cell 2 Storage Position: Sets the storage position broadcast messages are automatically of messages: Phone First or SIM First. displayed on the screen. You can directly read the messages.

  • Page 62: Missed Calls

    SED GPH-610R User Manual Missed Calls choose one of the following options: Enter this menu. The list of missed calls is Received Calls displayed on the screen. Select a missed call, Refer to the description of missed calls. and press...

  • Page 63: Tools

    SED GPH-610R User Manual 4.7 Tools The menu Tools consists of submenus Calendar, Calculator, Alarm Clock, Record, USB Mode, STK ,Version Check, Working Alone (Optional), Bluetooth Setup (Optional), RF Monitoring, Cell Forcing (Optional) and Cell Lock (Optional). You can choose Menu > Tools to access this menu.
  • Page 64 SED GPH-610R User Manual interface for selecting a date. You can function. Enter the calendar interface and press enter the target date on the screen, and to enter the following entry setting options: then press to go to the date or Create: You can edit a new entry.

  • Page 65: Calculator

    SED GPH-610R User Manual between dates, go to the desired date Calculator and set or view the current calendar if The calculator can perform simple operations any. such as addition, subtraction, multiplication, Note: The “*” icon indicates that the and division. Press number keys to enter reminder frequency is everyday in the calendar numbers, and press direction keys to select “+”,...

  • Page 66: Record

    SED GPH-610R User Manual Name: By default, the name is alarm Record clock 1. You can change the name. Two options are available: Start Record and Enable/Disable: After an alarm is active, Playback. it is marked with an “*” behind the menu Start Record: Select Record to start bar.

  • Page 67: Stk

    SED GPH-610R User Manual vibration. and held by the users. You can process working alone related setting in this menu item. The availability of features in this menu ON/OFF: You can use this menu to open or depends on whether or not your SIM card close the working alone function, this option is set to OFF by default.

  • Page 68: Rf Monitoring

    SED GPH-610R User Manual The default name is SED GPH-610RE. 4) Rename: Rename device 3 Set Pair PINCode: Set Bluetooth pairing PIN code. Note: If support Bluetooth, the working alone is 4 Bluetooth Scan: Scan the surrounding canceled. Bluetooth devices. Press OK key to scan the RF Monitoring surrounding Bluetooth devices.

  • Page 69: Cell Lock (Optional)

    SED GPH-610R User Manual Note: If the forcing ARFCN is not a BCCH key in standby mode to access the Settings ARFCN, your handset will lose service. In menu. Dedicate mode, the forcing ARFCN shall be Profiles one of the six strongest neighbor cells that BSICs have been decoded.

  • Page 70: Display

    SED GPH-610R User Manual beyond the network service area or enters Mute. Select the desired alert type. Press a blind area), the indicator emits a red light, to confirm the setting and exit. Press and blinks at an interval of three seconds.
  • Page 71 SED GPH-610R User Manual Select Disable and press to close the automatic keypad light. The keypad light remains on. 6 List Ongoing Calls: Select Enable and press to activate the call display function in standby mode. The screen periodically displays the present group call/broadcast numbers on the standby interface.

  • Page 72: Tone Setup

    SED GPH-610R User Manual Tone Setup to unlock the keypad. 1 Call Ring: You can select an alert tone for 2 PIN Code: You can set the PIN. incoming calls. 1) Enable PIN: You can enable or disable 2 SMS Alert Ring: You can select an alert PIN check.

  • Page 73: Phone Setup

    SED GPH-610R User Manual times consecutively, your SIM card will 4) Date Format: You can set the date be locked. In that case, contact your format to “YYYY/MM/DD”, network service provider immediately “DD/MM/YYYY” or “MM/DD/YYYY”. and obtain a PUK from the network...
  • Page 74 SED GPH-610R User Manual operation. press on the standby interface to enter the sub-menu or press Note: Restart the handheld after restoring to exit directly. factory settings. All data previously recorded in 2) Down: This is the shortcut key for the handheld, including the phonebook and Group Calls by default.

  • Page 75: Call Setup

    SED GPH-610R User Manual Call Setup 3 Call Divert: Call divert is a network function. This function can divert incoming calls to This function allows you to perform call-related another designated handheld, voice mail or settings. Certain settings in this function require pager, thus avoiding missed calls.
  • Page 76 SED GPH-610R User Manual responding, the network returns the result of the operation. 6 Network Selection: This menu is used for selecting the network. You can choose automatic selection or manual selection. The 4 Call Bar: This service can set restrictions for selection state is displayed in the status bar, for making or answering calls.

  • Page 77: Data Service

    SED GPH-610R User Manual Data Service This function allows you to configure GPRS data communication settings. If the setting is On, your handheld can be used as a modem. This function needs network support. For details, consult your network service provider.

  • Page 78: Document

    SED GPH-610R User Manual Note: 1 You can still connect a GPRS network 4.9 Document even if Power on Attach is set to Document is used to browse the information in Disable. Each time when dialing, it will your TF card, including Sound, Picture, firstly make GPRS attachment.

  • Page 79: Video

    SED GPH-610R User Manual 2 Delete: Deletes the picture. 2 Delete: Deletes the selected video. 3 Rename: Renames the picture. 3 Rename: Renames the selected video. 4 Delete All: Deletes all pictures in the 4 Delete All: Deletes all videos in the document.

  • Page 80: Record

    SED GPH-610R User Manual pause to play this video file, press record, press to stop playing it. stop playing it. 2 Delete: Deletes the selected record. 2 Delete: Deletes the selected audio file. 3 Rename: Renames the selected record. 3 Rename: Renames the selected audio file.

  • Page 81: Camera

    SED GPH-610R User Manual 4.10 Camera 2) Shutter Sound: Sets the shutter sound function. If you select On, a shutter sound will Select the Camera menu, and press be heard while you press during the enable the camera function. The scene taken photographing.
  • Page 82 SED GPH-610R User Manual 2 Video Camera: In video mode, the icon for folder and views a document list. the video camera function is on the top left. At 2) Video Resolution: Sets the video this moment, you can resolution to 240*320 or 176*144.

  • Page 83: Chapter 5 Reference Information

    SED GPH-610R User Manual Chapter 5 Reference Information PIN2 Access Password Usually PIN2 is provided with the SIM card. PIN2 implements certain functions, such as the The handheld and SIM card support multiple passwords to protect against unauthorized charge rate. These functions are implemented only when supported by your SIM card.

  • Page 84: Battery Use

    SED GPH-610R User Manual If you enter an incorrect PUK2 ten consecutive parameters set by the network operator. times, you cannot use certain functions any The battery charge time depends on the  more. Contact your local service provider for a remaining battery capacity and the type of new SIM card.

  • Page 85: Careful Maintenance

    SED GPH-610R User Manual cold, even if the battery is fully charged. Do not put the handheld in a dusty place;  Usually the discharge characteristics of otherwise, its movable parts will be lithium-ion batteries deteriorate in an damaged. environment below zero Celsius degrees.

  • Page 86: Glossary

    SED GPH-610R User Manual agents to clean the handheld. depend largely on the frequency of the signals Do not paint the handheld. Paint may stick it receives. Handhelds and base stations must  on the movable parts of the device and be equipped with antennas.
  • Page 87 SED GPH-610R User Manual handheld. operate a handheld. Line Recognition Service Common SMS This service allows you to display or hide your It is a network service that involves sending own number when making a call. and receiving information to and from other users.
  • Page 88 SED GPH-610R User Manual vCard Electronic Business Card Functional Number International Code Location Number ISDN Integrated Services Digital Network Mobile Originated MSISDN Mobile Station International ISDN Number Mobile Terminated Coach Number Push-To-Talk PLMN Closed User Group Public Land Mobile Network...

  • Page 89: Troubleshooting

    SED GPH-610R User Manual Troubleshooting If your handheld has a problem, refer to the following symptom descriptions and solutions. If the problem persists, contact the retailer or service provider. Symptom Solution  Ensure that the handheld has been powered on.
  • Page 90 SED GPH-610R User Manual  Ensure that the SIM card has been inserted. No network is  Check that your current position is covered by the service network. available.  Move the location to change the reception status.  Ensure that the battery has been installed.
