SERVICE MANUAL
CONTENTS
SHARP CORPORATION
Digital Copier
Reverse Single Pass
Feeder (RSPF)
AR-RP1
MODEL
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
Advertisement
Table of Contents
Related Manuals for Sharp AR-RP1
Summary of Contents for Sharp AR-RP1
-
Page 1: Table Of Contents
SERVICE MANUAL Digital Copier Reverse Single Pass Feeder (RSPF) AR-RP1 MODEL CONTENTS [ 1 ] PRODUCT OUTLINE................1 [ 2 ] SPECIFICATIONS ..................1 [ 3 ] UNPACKING AND INSTALLATION ............1 [ 4 ] EXTERNAL VIEW AND INTERNAL STRUCTURE ........4 [ 5 ] OPEREATIONAL DESCRIPTIONS ............ -
Page 2: 1 ] Product Outline
With E-Sort PWB installed: SPF harness S S enable, S D enable, D enable, D S enable Intermediate tray (AR-RP1) Step screw Mixture of different Mixture paper feed : Not available during document sizes copying. Available during FAX (same width... - Page 3 2) Remove the rear cabinet of the copier. 5) Remove the document glass holder cover (right side). Remove the seven screws and remove the cabinet. Remove the Remove the two screws. connector cover. 6) Attach the cushion (one position). Remove the cover of the double-sided adhesive tape and paste the cushion taking care not to allow it to extend over the plate edges.
- Page 4 9) Remove the PWB shield plate. 11) Install the interface harness. Remove the six screws. Connect the interface harness from the SPF to the machine and tighten the screws. 12) Remove the filament tape. Remove the filament tape at four positions. 10) Install the SPF harness and the ring core (included together with the unit).
-
Page 5: 4 ] External View And Internal Structure
[4] EXTERNAL VIEW AND Code Name Type Transport clutch — — INTERNAL STRUCTURE SPF motor Stepping Drives document motor feed on the tray, transport, and 1. External view paper exit roller. Gate solenoid — — — Interface PWB — — Document length Detects the detection SW... -
Page 6: Document Size Detection
2. Out line of operations 3. Document size detection [Duplex documents] 1) Document size detection with the document set tray When documents are set on the document set tray in the auto selec- 1) Document set (Document set sensor ON) tion mode of paper/copy magnification ratio, the document size is 2) Document size detection (Document width sensors W1, W2, W3 detected and paper and the copy magnification ratio are automatically... -
Page 7: 6 ] Adjustments
(2) SPF document off center adjustment [6] ADJUSTMENTS Note : When performing this adjustment, check that the paper off- center is properly adjusted. (1) RSPF sub scanning direction magnification ratio adjustment 1) Set the center position adjustment test chart (made by yourself) on the RSPF. -
Page 8: 7 ] Disassembly And Assembly
(4) OC (SPF) open/close detection position [7] DISASSEMBLY AND ASSEMBLY adjustment 1) Set a paper of A4 (8.5 x 11") on the OC table. 1. External fitting section Check that the document size display on the operation panel is the same as the set paper size. - Page 9 2) Document transport section cover 5) Pickup solenoid (Note) Remove section A of the pickup solenoid from the solenoid arm groove. 3) Document feed section cover 6) Clutch gear ass’y 4) Sensor PWB...
- Page 10 7) Pickup roller ass’y 3. Interface PWB (Note) When assembling the pickup roller ass’y 4, check that rib A is on the rib of the solenoid arm. 4. Document tray section 1) Document tray 8) Pick up roller, paper feed roller...
- Page 11 2) Rack cover 5. Drive frame section 1) Drive frame unit 3) Document length sensor SW 2) Transport belt...
-
Page 12: Transport Section
3) Drive frame ass’y and drive belt 6. Transport section 1) Clutch (Note) When assembling, check that the rib is in the clutch groove A and fix it with E-ring. 4) Pressure release solenoid 2) Transport roller gear 5) SPF motor... - Page 13 3) Reverse gate 6) PS roller 7) Paper feed paepr guide upper (Note) When assembling, check that the paper feed paper guide upper 2 is securely set to rib A and boss B. 4) Transport roller 8) Paper feed paper guide upper 5) Book sensor...
-
Page 14: 8 ] Maintenance
9) Paper exit roller [8] MAINTENANCE 1. Maintenance parts Name Work item Service call Remark Pickup roller Cleaning Separation pad Cleaning Paper feed roller Cleaning PS roller Cleaning Transport roller Cleaning Paper exit roller Cleaning 10) Gate solenoid (Note) When performing maintenance, refer to [6] DISASSEMBLY AND ASSEMBLY. - Page 19 4. Parts arrangement [Parts surface] [Solder surface]...
- Page 20 COPYRIGHT 1999 BY SHARP CORPORATION All rights reserved. Printed in Japan. No part of this publication may be reproduced, stored in a retrieval system, or transmitted. In any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.
