READ YOUR OPERATOR'S MANUAL COMPLETELY AND CAREFULLY BEFORE
ATTEMPTING TO SET UP OR OPERATE YOUR NEW REEL MOWER. ALL OPERATORS OF THIS
EQUIPMENT SHOULD READ AND UNDERSTAND ALL SAFETY RULES PRINTED ON THE MACHINE
AND IN THIS OPERATOR'S MANUAL BEFORE USE.
NOTICE: On the nameplate of your machine you will find the serial number and MFG date code of your unit.
Please record these numbers on this manual cover for future service reference.
MFG. DATE ________ PURCHASE DATE: _________
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-800-444-6742, 8:00 a.m.-6:00 p.m., EST, Monday-Thursday,
8:00 a.m.-5:00 p.m., EST, Friday.
TM
CAUTION - FOR YOUR SAFETY
16 in. REEL MOWER
ITEM / ARTICULO # 227682
MODEL / MODELO #26133
PRINTED IN CHINA
Advertisement
Table of Contents
Related Manuals for Task Force 26133
Summary of Contents for Task Force 26133
- Page 1 ITEM / ARTICULO # 227682 16 in. REEL MOWER MODEL / MODELO #26133 CAUTION - FOR YOUR SAFETY READ YOUR OPERATOR’S MANUAL COMPLETELY AND CAREFULLY BEFORE ATTEMPTING TO SET UP OR OPERATE YOUR NEW REEL MOWER. ALL OPERATORS OF THIS EQUIPMENT SHOULD READ AND UNDERSTAND ALL SAFETY RULES PRINTED ON THE MACHINE AND IN THIS OPERATOR’S MANUAL BEFORE USE.
-
Page 2: Table Of Contents
TABLE OF CONTENTS PRODUCT SPECIFICATIONS ………………………………………………………………………….…………..…………………2 SAFETY INFORMATION ………………………………………………………………………………….…………..…………………3 CARE AND MAINTENANCE …………………………………………………………………………….…………..………………….3 ASSEMBLY INSTRUCTIONS ………………………………………………………………………….…………..……………….4/5 CUTTING HEIGHT ADJUSTMENT ………………………………………………………………….…………..…………..….. ………………………………………………………………….…………..…………..…....7 BLADE ADJUSTMENT CHECKING THE ADJUSTMENT ……………………………………………………………….…………..……………..……7 TWO-YEAR LIMITED WARRANTY …………………………………………………………………….…………..…………………8 PARTS DIAGRAM ……………………………………………………………………………………………….…………..…….. 9/10 PRODUCT SPECIFICATIONS 16 IN. REE L MOWER Item No. -
Page 3: Safety Information
SAFETY INFORMATION Never place hands, fingers or feet inside the reel. Although a motor does not power this mower, when the wheels turn the reel spins and can cut. Never mow when grass is wet as it can be slippery. Do not use the reel mower while barefoot or while wearing sandals. -
Page 4: Assembly Instructions
ASSEMBLY INSTRUCTIONS Before attempting to assemble, empty carton and compare parts with parts list below. Note: • Carefully remove the parts from the box. • Inspect the parts to make sure no breakage or damage occurred during shipping. • Do not discard the packing material until all parts are examined. •... - Page 5 ATTACHING THE HANDLE TO THE MOWER BASE: (Fig.2) 1. Align holes (1) at the lower end of each handle arm with short posts (2) extending from the mower base side plates. Slide lower ends of handle arms onto posts. 2. After handle arm holes are on posts, use pliers to snap C-clips (1) onto the slotted (2) posts on both sides to secure handle.
-
Page 6: Cutting Height Adjustment
OPERATION CUTTING HEIGHT ADJUSTMENT: (Fig. 3) 1. The cutting height of the 16 in. reel mower can be adjusted from 5/8 – 1-7/8 in. using the roller assembly. 2. For the lowest cutting position, loosen and remove the adjust ment nuts on both sides of roller assembly. Position bolt through the bottom hole of the plastic roller bracket and t op hole of the mower side plate. -
Page 7: Blade Adjustment
OPERATION MOWER BLADE ADJUSTMENT: (Fig. 4) WARNING: BLADES ARE EXTREMELY SHARP. TO AVOID INJURY, DO NOT TOUCH BLADES WHEN MAKING ADJUSTMENT. Note: Blades are factory adjusted. • Misalignment can occur, often caused by blades being too loose or too tight. This can cause an uneven cut or difficulty pushing the mower. -
Page 8: Two-Year Limited Warranty
TWO-YEAR LIMITED WARRANTY The manufacturer warranties that this product is free from defects in material and workmanship for two (2) years from the date of the original purchase by the original purchaser only. THIS WARRANTY IS NOT TRANSFERABLE AND DOES NOT COVER: Products sold damaged or incomplete, sold “as is”, sold reconditioned or used as rental equipment. -
Page 9: Parts Diagram
PARTS DIAGRAM... - Page 10 PARTS DIAGRAM LIST Item Description Housing Reel blades Top push handle Center handle pieces Lower handle Spring Spring washer Bearing Wheel cover Gear wheel Shaft Foam grip Washer Bolt Wheel Cutting bar adjustment lever Flat washer Height adjustment knob Long rear roller Short rear roller Long shaft Knob...
