Front fork
Take out the front fork
Warning
Rest the motorcycle firmly to avoid turnover.
1.
Rest the motorcycle on the flat ground.
2.
Place a proper bracket under the frame and the engine
to surpport the front wheel.
3.
Removal
Front wheel
Front fender
4.
Loosen
Loosen the bolt
Cover bolt
Note:
When removing the front fork,remove the 2 bolts for
fastening the front fork.
Removal of front fork
1.
Removal
Cover bolt(and O-ring)
2.
Oil drain
3
.Removal
Spacer
Spring seat
Spring
6-20
CHAS
