Summary of Contents for Seitron CHEMIST 400

  • Page 1 CHEMIST 400 CHEMIST 400 CHEMIST 400 CHEMIST 400 Combustion Analyzer Combustion Analyzer Combustion Analyzer Combustion Analyzer TÜV SÜD approved: s e i t r o n EN 50379-1 EN 50379-2 dispositivi elettronici 1.BimSchV (RgG 291) di regolazione, misura e controllo SEITRON S.p.A.

  • Page 2: Table Of Contents

    Important information Intended purpose INTRODUCTION General Description of the Combustion Analyser General features of the Flue Gas Analyser CHEMIST 400 Main configurations TECHNICAL SPECIFICATIONS Technical Specifications Overview of Flue Gas Analyser Components Measurement and Accuracy Ranges USING THE FLUE GAS ANALYSER...
  • Page 3 ANNEX C - Flue gas analysis according to Italian Law No. 10 WARRANTY CERTIFICATE SEITRON S.p.A. - ALL RIGHTS RESERVED - Total or partial reproduction of this document by any means (including photocopying or storage on any electronic medium) and transmittal of same to third parties in any manner, even electronically, is strictly prohibited unless explicitly authorised in writing by SEITRON S.p.A.

  • Page 4: Important Information

    Read these operation and maintenance manual carefully before use. The professional personnel must be familiar with this manual and follow the instructions contained herein. This manual describes the operation, function and maintenance of the English version for CHEMIST 400 - Flue Gas Analyzer.

  • Page 5: Intended Purpose

    This chapter describes the areas of application for which the CHEMIST 400 is intended. Using the CHEMIST 400 in other application areas is on the risk of the operator and the manufacturer assumes no responsibility and liability for loss, damage or costs which could be a result. It is mandatory to read and pay attention to the operating/maintenance manual.

  • Page 6: Introduction

    The memory can store 300 complete analyses and the data downloaded onto a PC by means of dedicated SW and a mini-USB serial communication cable. It is also interesting to note that “CHEMIST 400” has just one “Li- Ion” rechargeable battery pack used for powering the instrument and the printer; it also has a luminous and large (42 x 60mm) LCD display boasting excellent readability thanks to its backlighting and also to the zoom function.
  • Page 7 1.3 CHEMIST 400 Main configurations CHEMIST CHEMIST CHEMIST CHEMIST CHEMIST CHEMIST CHEMIST 400B 404N 404S 400X O2 SENSOR CO+H2 SENSOR CO SENSOR NO SENSOR NO2 SENSOR SO2 SENSOR NOT EXPANDABLE EXPANDABLE TO 4 SENSORS AUTOMATIC AUTOZERO CO DILUTION BLUETOOTH CALIBRATION...

  • Page 8: Technical Specifications

    TECHNICAL SPECIFICATIONS 2.1 Technical Specifications Autozero: Automatic autozero cycle (with probe inserted in the stack except for Chemist 400B and Chemist 401 versions). Dilution: Expansion system of the CO sensor measuring range up to 50,000ppm (5.00%v/v) programmable as a simple protection of the CO sensor with triggering threshold programmable by the user.

  • Page 9: Overview Of Flue Gas Analyser Components

    2.2 Overview of Flue Gas Analyser Components B B B B C C C C P P P P Q Q Q Q N N N N O O O O A A A A E E E E G G G G F F F F M M M M D D D D...
  • Page 10 Seitron does, however, certify measurement accuracy only when a calibration certificate has been issued by its own laboratory or by an authorised laboratory.
  • Page 11 The cold junction is compensated by a Pt 100 resistance thermometer which measures the temperature at the M M M M thermocouple connector (pos. in Fig. 2.2). The type K thermocouple (nickel/nickel chromium) permits continuous measurements up to 800°C. If special- purpose probes are used, the instrument is able to measure temperatures as high as 999.9°C.
  • Page 12 A calibration certificate is provided with each and every instrument where every parameter is accompanied by the relevant nominal value, measured value, permissible error tolerances and measured error. Electromagnetic compatibility The instrument was designed to comply with Council Directive 2004/108/EC governing electromagnetic compatibility. Seitron’s declaration of conformity may be found in Annex B. K900000000SE 022628A0 071013...

  • Page 13: Measurement And Accuracy Ranges

    2.3 Measurement and Accuracy Ranges MEASUREMENT SENSOR RANGE RESOLUTION ACCURACY 0 .. 25.0% vol 0.1% vol ±0.2% vol Electrochemical sensor ±10 ppm 0 .. 200 ppm Electrochemical sensor 0 .. 8000 ppm 1 ppm ±5% measured value 201 .. 2000 ppm with H compensation ±10% measured value...

  • Page 14: Using The Flue Gas Analyser

    100% charge cycle by connecting the instrument to the power pack for 3 hours. If the problem persists, replace the battery pack with a SEITRON original or contact the SERVICE CENTRE to carry out the necessary repairs.
  • Page 15 THE POWER SUPPLY/BATTERY CHARGER IS A SWITCHING TYPE ONE. THE APPLICABLE INPUT VOLTAGE RANGES BETWEEN 90Vac AND 264Vac. INPUT FREQUENCY: 50-60Hz. THE LOW VOLTAGE OUTPUT IS 12 VOLT WITH AN OUTPUT CURRENT GREATER THAN 1.5A. LOW VOLTAGE SUPPLY CONNECTOR: DC PLUG 2.1x5.5x9 mm. WITH CENTRAL POSITIVE AND EXTERNAL GND.

  • Page 16: Operation

    OPERATION 4.1 Working principle The gas sample is taken in through the fumes probe, by a diaphragm suction pump inside the instrument. The measuring probe has a sliding cone that allows the probe to be inserted in holes with a diameter of 11 mm to 16 mm and to adjust the immersion depth: the fumes picking point must be roughly in the centre of the flue section.

  • Page 17: Connecting The Combustion Air Temperature Probe

    the measurement cells. This is also the reason why it is important to periodically drain the trap, anyhow at the end of each test (see chapter 'MAINTENANCE'). A replaceable low-porosity line filter is placed after the condensate trap aimed at keeping the solid particles suspended in the gases.

  • Page 18: Keypad Overview

    4.7 Keypad overview Select / Modify On / Off Confirm Cancel / Exit Memory Menu Print Menu Zoom on Analysis Configure Menu Draught Menu Measurements Menu Analysis Menu Info Menu WARNING: to turn-on / off the instrument it is necessary to press and hold the On/Off button for at least 2 seconds.

  • Page 19: Info Menu

    4.8 Info Menu This menu provides information regarding instrument status: Battery status: Shows the status of the internal battery. The battery charge status is shown graphically and in text as a percentage between 0 and 100%, together with the battery voltage. Sensors Configuration: It allows to check which sensors are installed on the instrument, and in which position they are installed.

  • Page 20: Flow Chart - Info Menu

    4.8.1 Flow Chart - Info Menu Activates the Info Menu. To return to the previous screen, press INFORMATION BATTERY STATUS ►Battery status Bat: 91 ٪ The battery symbol filling up means that battery charging is Sensors Config. Vbat:7.82 V Sensors diagnostic ongoing.
  • Page 21 Sensors Config. Calibration Sensors diagnostic Gas Path Check ►Memories diagnostic ▼ INFORMATION INFO SERVICE ▲ Sensors Config. Seitron S.p.A. Sensors diagnostic Tel.+39 0424 567842 Gas Path Check Fax.+39 0424 567849 Memories diagnostic CHEMIST 404S ►Info Service SN:000001 Ver:1.00 ▼ PN:000000 CRC:8BBB...

  • Page 22: Analysis Configuration Menu

    4.9 Analysis configuration menu Through this menu the user can configure the available parameters for a proper combustion analysis. Fuel: Lets the user select the type of fuel to be used during analysis. This datum can be varied either from this menu or during the analysis itself.
  • Page 23 screen. NOx/NO Factor NOx/NO: all the nitrogen oxides which are present in the flue emissions (Nitrogen oxide = NO, Nitrogen dioxide = NO ); total nitrogen oxides = NOx (NO + NO In the combustion processes, it is found out that the NO percentage contained in the fumes is not far from very low values (3%);...

  • Page 24: Flow Chart - Analysis Configuration Menu

    4.9.1 Flow Chart - Analysis configuration menu Activates the Configure Menu. All selected data can be modified by pressing cursor keys To cancel changes and return to the previous menu press CONFIGURATION ►Analysis config. Instrument config. CONFIGURATION FUEL FUEL PARAMETERS ►Fuel ►Natural gas 0.6600...
  • Page 25 FUEL FUEL PARAMETERS ▲ Butane 0.7400 Diesel oil 0.0071 Fuel oil 19.01 % Propane-Air 18150 kJ/kg ►Pellet 8% 19750 kJ/kg ▼ FUEL FUEL PARAMETERS ▲ Diesel oil 0.7610 Fuel oil 0.0089 Propane-Air 18.93 % Pellet 8% 15450 kJ/kg ►Wood 20% 17170 kJ/kg FUEL FUEL PARAMETERS...
  • Page 26 CONFIGURATION REFERENCE O REFERENCE O REFERENCE O REFERENCE O Fuel ►CO 1 1 1 1 ..0 0 0 0 % % % % NO,NOx NO,NOx NO,NOx NO,NOx Measurement units 0 0 0 0 ..0 0 0 0 % % % % ►O...
  • Page 27 CONFIGURATION ALARMS ALARMS ▲ Select the figure to be modified with the Reference ►Number Number Automatic analysis Measure Measure CO ev keys Condensation Active Active maximum maximum Modify the value of the highlighted NOx/NO factor Limit Limit 1500 2000 ►Alarms Unit Unit figure with keys...
  • Page 28 ◄ 9:;<=>?!“#$٪&’) ► the desired text can be entered or the ▼ user can confirm and exit. CONFIGURATION REPORT HEADER TEXT EDITING ▲ NOx/NO factor Seitron S.p.A._ ►1: Alarms Autozero/Pump ▲ Operator ◄ 9:;<=>?!“#$٪&’) ► ►Report header setup ▼ ▼...

  • Page 29: Instrument Configuration Menu

    4.10 Instrument configuration menu This menu is used to configure the instrument’s reference parameters described below: Bluetooth (When applicable): Through this sub menu the user can turn on and off the instrument Bluetooth wireless communication with a PC or PDA. WHEN THE INSTRUMENT BLUETOOTH INTERFACE IS TURNED ON, THE BATTERY LIFE IS REDUCED DOWN TO 10 HOURS.

  • Page 30: Flow Chart - Instrument Configuration Menu

    4.10.1 Flow Chart - Instrument configuration menu Activates the Configure Menu. All selected data can be modified by pressing cursor keys To cancel changes and return to the previous menu press CONFIGURATION ►Analysis config. Instrument config. CONFIGURATION Analysis config. ►Instrument config. CONFIGURATION BLUETOOTH BLUETOOTH...
  • Page 31 CONFIGURATION CO AUTO-DILUTION CO AUTO-DILUTION CO AUTO-DILUTION CO AUTO-DILUTION Bluetooth ►Mode Mode Mode Mode auto Calibration Limit 4000 Display contrast Time/date ►CO Auto-Diluition ▼ CO AUTO-DILUTION CO AUTO-DILUTION CO AUTO-DILUTION Mode auto Mode auto Mode auto ►Limit 4000 ►Limit 4000 ►Limit 4500 CONFIGURATION...

  • Page 32: Memory Menu

    4.11 Memory Menu This menu is used to display and print individual and average values of the analysis data stored in memory. Analysis data can be ordered either by memory position or by storage date; draught, smoke and ambient CO, NO values can also be recalled.

  • Page 33: Flow Chart - Memory Menu

    4.11.1 Flow Chart - Memory Menu Activates the Memory Menu. This menu is used to display and print the individual and average values of the analysis data stored in memory. Analysis data can be ordered either by memory position or by storage date; draught, smoke and ambient CO, NO values can also be recalled.
  • Page 34 RECALL MEMORY MEAS. CONDITIONS 1:19/12/10 15.30 Natural gas 2:19/12/10 16.00 Altitude 0 m 3:19/12/10 16.30 R.H. air 50% Average analysis Mario Rossi ►Meas. Conditions ▼ RECALL MEMORY RECALL DRAFT 2:19/12/10 16.00 3:19/12/10 16.30 -0.12hPa Average analysis Meas. Conditions T esterna: 20°C ►Draft ▼...

  • Page 35: Print Menu

    4.12 Print Menu This menu is used to access the following print and check configurations: Print report: Shows the details of the selected ticket type and allows to start printing. Print setup: Copies: Allows to set the number of printed copies and layout of the ticket. Model: The ticket layout selection is only valid for combustion analysis and can be chosen among Complete, Partial and Total.

  • Page 36: Flow Chart - Print Menu

    4.12.1 Flow Chart - Print Menu Enables the Print Menu. Allows to print the combustion analysis data on a paper ticket which reports the measurement values. The printed values are those shown on the display when the menu is enabled. This menu can be used for combustion analysis, even when recalled from the memory, for draught, smoke, ambient gas and for tightness test results.
  • Page 37 PRINT PRINT TEST PRINT TEST Print report Print setup Report test print Report test print Paper feed ►Print test Please wait ... Printer type START QUIT PRINT PRINTER TYPE PRINTER TYPE PRINTER TYPE Print report ►Type Built in Type Built in Type Bluetooth Print setup...

  • Page 38: Analysis Menu

    4.13 Analysis Menu Through this key the analysis results are displayed. Moreover the operator is allowed, once this key is further depressed, to display and possibly modify the analysis parameters before proceeding with the measurements. Measured values are: Oxygen percentage in the fumes. CO + H CO concentration in the fumes.

  • Page 39: Flow Chart - Analysis Menu (Zoom)

    4.13.2 Flow Chart - Analysis Menu (zoom) 4.2٪ 8.6٪ O O O O 4.2٪ O O O O 4.2٪ 2 2 2 2 2 2 2 2 ηs 91.4٪ 9.3٪ 9.3٪ 2 2 2 2 λ,n 1.25 ηt 91.4٪ 9.3٪ λ, λ, λ,...
  • Page 40 By pressing the Analysis key once more, and starting from any of the above screens, the user may proceed as follows: Activates the Analysis Menu. ANALYSIS SETUP ANALYSIS SETUP ANALYSIS SETUP ANALYSIS SETUP SELECT MEMORY ►Mem.: ►Mem.:001 Fuel.: Natural gas Date:--/--/-- Select the memory wherein to store the acquired data.

  • Page 41: Draught Menu

    4.14 Draught Menu The DRAUGHT menu gives access to the stack draught measurement. Being a negative pressure, in accordance with standard UNI10845, draught must be measured using the negative pressure input P-. The correct values for a natural draught boiler are therefore positive by definition. Before performing the measurement the instrument allows the user to input the external air temperature as required by the standard.

  • Page 42: Readings Menu

    'HOLD' key. Tightness test: Chemist 400 can perform the tightness test on heating plants which use combustible gases according to the standards UNI 7129 and UNI 11137: 2012, respectively applicable to new or renewed pipings and to existing pipings.
  • Page 43 Test pressure with air 5000 Pa. Note: Chemist 400 allows the user to perform the tightness test even with a combustible gas different from the supply gas. Anyway the reference standard does not provide a reference pressure in this situation, so the reference pressure is taken like test gas is the same.
  • Page 44 Open the faucet on the side where the syrynge is applied and withdraw exactly 100 ml (100 cc) of the gas • present in the piping. Press the ' ' button. Inject the gas present in the syringe back into the piping and then close the faucet again. •...
  • Page 45 Result: is the result of the tightness test. Compliant (piping suitable for operation): when the leakage flow calculated in the reference conditions is not greater than 1 dm /h for methane and not greater than 0,4 dm /h for LPG the system is authorized to operate without restrictions or intervention.

  • Page 46: Flow Chart - Readings Menu

    4.15.1 Flow Chart - Readings Menu Activates the Smoke Menu. MEASUREMENTS SMOKE PRINT In the Smoke menu the user can input the smoke value. The values entered with the arrow keys ►Smoke ►Measure 1: 2 ►Print report Ambient CO,NO Measure 2: - Print setup can be associated with the ongoing analysis Pressure...
  • Page 47 Tightness test flow-chart according to standards UNI 7129 and UNI 11137: 2012. TIGHTNESS TEST UNI 7129 STANDARD ►New piping ►Start test Existing piping Stabilization UNI 7129 STANDARD UNI 7129 STANDARD UNI 7129 STANDARD UNI 7129 STANDARD Start test ►Wait time 15 min Wait time Wait time...
  • Page 48 VOLUME MEASURE measurement procedure is correctly terminated, Inject the syringe Chemist 400 shows the contents in the piping m e a s u r e d v a l u e , otherwise it requires to repeat the gas injection with the syringe.
  • Page 49 PIPING VOLUME ADD TUBE Vtot 18.0 dm Select material with keys Vtub 0.0 dm amongi tas: Volume measure ►Material Copper ►Add tube Diameter 20 mm Steel, Copper, PE. Subtract tube Length 0.0 m Zero volume ADD TUBE Select nominal Vtub 0.0 dm diameter with...
  • Page 50 UNI 11137 STANDARD UNI 11137 STANDARD Start test ►Natural gas Stabilization L.P.G. Piping volume Combustible gas ►Test gas UNI 11137 STANDARD Natural gas ►L.P.G. UNI 11137 STANDARD Natural gas L.P.G. ►Air UNI 11137 STANDARD UNI 11137 STANDARD UNI 11137 STANDARD UNI 11137 STANDARD ►Start test Charge the pipe to...

  • Page 51: Flow Chart - Configure Analysis Menu

    4.16 Flow Chart - Configure Analysis Menu When depressed for at least 2 seconds, turns the instrument on. Adjusts the display contrast. CHEMIST 404S SN:00001 Ver:1.01 AUTOZERO STARTED WARNING Insert the gas probe in the chimney automatically, after 10 seconds. MEMORY RECALL MEMORY Key analyser parameters can be configured...

  • Page 52: Flue Gas Analysis

    4.17 FLUE GAS ANALYSIS To perform complete flue gas analysis, follow the instructions below. SOME IMPORTANT WARNINGS TO CONSIDER DURING THE COMBUSTION ANALYSIS ARE LISTED BELOW: FOR A CORRECT ANALYSIS NO AIR MUST FLOW INTO THE PIPE FROM OUTSIDE DUE TO A BAD TIGHTENING OF THE CONE OR A LEAK IN THE PIPELINE.

  • Page 53: Flue Gas Analysis

    the following data must be configured: Memory: use this submenu to define the memory in which the test data and client details are to be stored. Fuel: the user will be asked to define the type of fuel used by the plant. Operator: this is where the name of the test operator can be entered.

  • Page 54: Flow Chart - Flue Gas Analysis

    4.17.5 Flow Chart - Flue Gas Analysis When depressed for at least 2 seconds, turns the instrument on. Adjusts the display contrast. CHEMIST 404S SN:00001 Ver:1.01 AUTOZERO STARTED WARNING Insert the gas probe in the chimney automatically, after 10 seconds. MEMORY RECALL MEMORY ►Mem.:...
  • Page 55 How to proceed in manual mode (standard sequence). MEMORY SAVE ANALYSIS 4.2٪ 8.6٪ 9.3٪ ηs 91.4٪ ►Save analysis Memory 001/1 ηt 91.4٪ λ,n 1.25 Display average Draft Save test 1. Tf 190.1C 146p Select memory Smoke 15.4C Recall memory CO,NO amb ∆T 74.7C Delete single...
  • Page 56 How to proceed in manual mode (quick sequence). SAVE ANALYSIS 4.2٪ 8.6٪ 9.3٪ ηs 91.4٪ Memory 001/1 ηt 91.4٪ λ,n 1.25 Draft Tf 190.1C 146p Smoke 15.4C CO,NO amb Save test 1. ∆T 74.7C SAVE QUIT ►RefO ▼ SAVE ANALYSIS 4.2٪...
  • Page 57 How to proceed in automatic mode. 4.2٪ 8.6٪ 9.3٪ ηs 91.4٪ ηt 91.4٪ λ,n 1.25 Tf 190.1C 146p 15.4C ∆T 74.7C ►RefO ▼ 4.2٪ 8.6٪ ηs 91.4٪ 9.3٪ λ,n 1.25 ηt 91.4٪ Tf 190.1C 146p 15.4C ∆T 74.7C ►RefO 001/1:120 ▼...

  • Page 58: Measuring The Differential Pressure (Optional Kit)

    4.18 Measuring the Differential Pressure (OPTIONAL KIT) The instrument is fitted with an internal temperature-compensated piezoresistive transducer to measure positive and negative pressures. This sensor, which is mounted on the instrument, is of the differential type. If the special KIT is purchased, the sensor can be used to measure the differential pressure thanks to the positive and negative pressure connectors.

  • Page 59: Sensors

    SENSORS 5.1 Sensors arrangement SENSORS ARRANGEMENT INSIDE GRAPHICAL DISPLAY THE SENSORS COMPARTMENT OF ARRANGEMENT SENSORS TYPE POSITION POSITION QUIT CONFIRM POSITION POSITION 5.2 Sensor types and relevant positioning POSITION CODE Flex-Sensor O Cod. AACSE11 Flex-Sensor O Cod. AACSE15 Flex-Sensor CO+H Cod.

  • Page 60: Gas Sensors Life

    Sensor characteristics diminish as the reagents are consumed and when these have been used up completely the sensor must be replaced. The sensors must be recalibrated on a regular basis to assure measuring accuracy: recalibration can only be performed by a qualified SEITRON service centre. Chart 5.4 illustrates the characteristics inherent to each sensor.

  • Page 61: Expandability To 4 Sensors

    5.5 Expandability to 4 sensors In the Chemist 400 instruments range, two are the versions which can be expanded: CHEMIST 402: 2 sensors, expandable to 3 or 4 CHEMIST 403: 3 sensors, expandable to 4 sensors. sensors. POSITION S1 POSITION S3...

  • Page 62: Cxhy Sensor For Measurement Of The Unburnt Hydrocarbons

    5.6 CxHy sensor for measurement of the unburnt hydrocarbons The unburnt hydrocarbons are chemicals produced by an incomplete combustion of molecules (hydrocarbons) made of Carbon and Hydrogen. These are usually named as HC or (better) CxHy: when this is filled with the actual values for the number of C and H atoms, the actual type of fuel is exactly defined.

  • Page 63: Co 2 Sensor For Carbon Dioxide Measurement In Combustion Processes

    5.9 Installing the CO sensor When the CO (position S3/S4) is mounted in the CHEMIST 400, it is mandatory to configure the autozero by setting it at 60 seconds, in order to allow for a proper pre-heating of the sensor itself. CONFIGURATION ►Fuel...

  • Page 64: Maintenance

    Do not exceed sensor overload thresholds. • When the analysis is over disconnect the sample probe and let Chemist 400 draw fresh air for a few minutes, • or at least until the displayed parameters return to their original values.

  • Page 65: Replacing The Particulate Filter

    6.5 Replacing the particulate filter If the particulate filter appears black, especially on the inner surface (see adjacent example), it has to be replaced immediately. In this way gas flow is not obstructed. Blackened particulate filter 6.6 Replacing the gas sensors The gas sensors of the instrument shall be periodically replaced (see the following table) with new or recalibrated sensors.
  • Page 66 Locate the sensor to be replaced; here is an example of a connected sensor to be replaced. Electrical connection Disconnect the sensor to be replaced; here is an example of a disconnected sensor to be replaced. K900000000SE 022628A0 071013...
  • Page 67 The sensor is bayonet-connected to its socket; rotate it anticlockwise to remove it. Here is an example of a rotated sensor. While rotating the sensor, take care not to exert any pressure onto the printed circuit above: exert pressure only onto the plastic body. After rotating the sensor, pull it upward;...
  • Page 68 Rotate the sensor clockwise until hearing a click (See point 4). While rotating the sensor, take care not to exert any pressure onto the printed circuit above: exert pressure onto the plastic body only. Reconnect the sensor (See point 3). Close the back door of the sensor compartment again, and tighten screws again (See point 1).

  • Page 69: On-Site Recalibration

    6.7 On-site recalibration It is possible to make a recalibration of the instrument’s gas sensors with suitable known concentration gas cylinders. Recalibration of Oxygen (O ) sensor is not availbale since it is already recalibrated during every autozero sequence. The access to the sensor recalibration is password protected, the password is ' 1111 '. To carry on the recalibration the following instruments are needed: - Known concentration gas cylinder suitable for the sensor, complete with a pressure regulator - Flow meter...
  • Page 70 CONFIGURATION PASSWORD PASSWORD ▲ Operator Enter the recalibration menu password Report header setup 0 0 0 0 1 1 1 1 Micromanometer 1111. Language ►Calibration CALIBRATION CO CALIBRATION Installed sensors which can be recalibrated are shown, and Action calibrate ►CO can be chosen for recalibration.
  • Page 71 Apply the gas to the instrument and regulate the cylinder output pressure so that the flow meter shows a • minimum flow (0,5 l/m) this ensures that the instrument is getting exactly the gas needed by its internal pump. The instrument measures the concentration of the appllied gas; wait at least 3 minutes for the measure to •...

  • Page 72: Replacing The Battery Pack

    6.8 Replacing the battery pack Follow these instructions to replace the battery pack: Undo the fixing screw on the battery Extract the battery pack. compartment cover, and extract it . Remove the battery pack connector, and replace the pack with a new one following the reverse procedure described above.

  • Page 73: Replacing The Printer Paper Roll

    6.9 Replacing the printer paper Follow these instructions to change the paper roll in the printer. Remove the printer cover by exerting a light Push inward the plastic thin plate to remove the pressure outward, as shown by the arrow. cover of the paper compartment, as shown by the arrow, until the cover comes out.

  • Page 74: Troubleshooting

    7.0 TROUBLESHOOTING 7.1 Troubleshooting guide SYMPTOM PROBABLE CAUSES AND REMEDIES The instrument does not work at all. When the On/Off a. Keep the On/Off key depressed for at least 2 pushbutton is pressed the instrument does not come seconds. b. The battery is low; connect the battery charger to the instrument.
  • Page 75 Troubleshooting guide SYMPTOM PROBABLE CAUSES AND REMEDIES The rear lighting of the display is not on. The backlighting LED’s are faulty. Contact the nearest service centre to replace the display. The batteries last less than 9 hours. a. Battery capacity is limited by low temperatures. To achieve a longer battery life it is recommended to store the instrument at higher temperatures.

  • Page 76: Spare Parts And Technical Assistance

    Particulate/water filter assembly AAC TA03A: Particulate/water filter assembly with steel pipe and connector AAC UA02: Adapter cable USB-A / mini USB-B. 8.3 Service Centres Seitron S.p.A. Via Prosdocimo, 30 I-36061 Bassano del Grappa (VI) ITALY Tel.: +39.0424.567842 Fax.: +39.0424.567849 E-mail: info@seitron.it http://www.seitron.it...

  • Page 78: Annex A - Analysis Report Examples

    UNI 10389-1 8.6 ٪ L. 10/1991 and s.m.i. ηs 91.4 ٪ D.Lgs. 192/2005 and s.m.i. ηc 4.9 ٪ ηt 91.4 ٪ Chemist 400 148 ppm Serial: 999989 40 ppm Memory: 01 /NO: 1.03 Analysis: average 41 ppm Date: 22/11/10 Analysis: 2 Time: 10.15...
  • Page 79 λ,n 1.25 L. 10/1991 and s.m.i. T flue 190.2 °C D.Lgs. 192/2005 and s.m.i. T air 15.4 °C ∆T 174.8 °C Chemist 400 8.6 ٪ Serial: 999989 ηs 91.4 ٪ Memory: 01 ηc 4.9 ٪ Analysis: average ηt 91.4 ٪...
  • Page 80 COMPANY Ltd. Park Road, 9 Park Road, 9 Tel.02/12345678 Tel.02/12345678 Oper.: John Smith Oper.: John Smith Sign.: ______________ Sign.: ______________ Chemist 400 Test according to Serial: 999989 UNI 11137: 2012 standard Indirect method Memory: 01 Chemist 400 Date: 20/04/05 Sign.: 999989 Time: 10.15...

  • Page 82: Annex B - Declaration Of Conformity

    UBA committee for the use as emissions measurement device, according to the 1.BimSchV scheme (RgG 291) Ing. Vito Feleppa Managing Director Seitron S.p.A. 1 Valid for configurations equipped with the following sensors: sensor: Cod. AAC SE11 - Cod. AAC SE15...

  • Page 84: Annex C - Flue Gas Analysis According To Italian Law No. 10

    Legislative Decree 192/2005 and the UNI 10389-1 standard Preamble It is Seitron's intention, by means of this compact guide, to provide boiler installers/service technicians with a quick and easy way to understand whether a boiler conforms to the requirements of Italian Law no. 10 dated January 1991, and subsequent modifications and supplements, and Legislative Decree 192/2005.
  • Page 85 Stack loss is calculated by applying a simple formula which relates it to other easily measurable parameters: Qs = A2 + B Tf-Ta Where: A2, B = factor that depends on the fuel used Tf = flue gas temperature Ta = combustion air temperature = % carbon dioxide in the flue gas Thus in order to calculate the stack loss and hence the thermal efficiency of a plant, one must measure the two temperatures (flue gas and air) and the level of carbon dioxide contained in the flue gas (% CO...
  • Page 86 L. 10/1991 and s.m.i. D.Lgs. 192/2005 and s.m.i. Oxygen O Chemist 400 The percentage of oxygen in air is around 21%: an ideal combustion process Serial: 421023 will “burn” all the oxygen present; in truth, however, the residual percentage is Memory: 01 never zero due to the presence of excess air.
  • Page 87 Instructions for accurate testing In order to achieve a certain degree of accuracy when conducting flue gas analysis, the following should be respected: the boiler being checked should be running in steady state conditions the flue gas analyser should be switched on at least 3 minutes before testing (time to auto-calibrate) with the probe located in fresh air the point in which the probe is inserted for analysis has to be at a distance of approximately twice the stack diameter or, alternatively, as directed by the boiler manufacturer.

  • Page 88: Warranty Certificate

    24 months from purchasing date. Seitron undertakes to repair or replace, free of charge, those parts that, in its opinion, are found to be faulty during the warranty period. The products which are found defective during the above mentioned periods of time have to be delivered to Seitron’s Laboratories carriage paid.
