PLEASE READ BEFORE USE AND SAVE.
Charge the battery for about 8 hours before initial use.
Panasonic World Wide Web address: http://www.panasonic.com
for customers in the USA or Puerto Rico
KX-TG2650N
Model No.
Operating Instructions
2.4GHz Cordless Phone
Pulse-or-tone dialing capability
Caller ID Compatible

Advertisement

Table of Contents
loading

Related Manuals for Panasonic KX-TG2650N

Summary of Contents for Panasonic KX-TG2650N

  • Page 1 PLEASE READ BEFORE USE AND SAVE. Charge the battery for about 8 hours before initial use. Panasonic World Wide Web address: http://www.panasonic.com for customers in the USA or Puerto Rico 2.4GHz Cordless Phone KX-TG2650N Model No. Pulse-or-tone dialing capability Operating Instructions...

  • Page 2: Before Initial Use

    Please read IMPORTANT SAFETY INSTRUCTIONS on page 64 before use. Read and understand all instructions. Thank you for purchasing your new Panasonic cordless telephone. Caller ID and Call Waiting Service, where available, are telephone company services. After subscribing to Caller ID, this phone will display a caller’s name and phone number.

  • Page 3: For Best Performance

    For Best Performance Battery Charge A rechargeable Nickel-Metal Hydride (Ni-MH) battery powers the handset. Charge the battery for about 8 hours before initial use (p. 11). Base Unit Location/Noise Calls are transmitted between the base unit and the handset using wireless radio waves.

  • Page 4: Table Of Contents

    Contents Preparation Location of Controls ....... . . 6 Displays ......... . . 9 Settings.
  • Page 5 Intercom ......... . . 44 Transferring a Call Using the Intercom .

  • Page 6: Location Of Controls

    Location of Controls Base unit (LOCATOR/INTERCOM) Charge Contacts (p. 12) Speaker (p. 22) DIGITAL SP-PHONE (Speakerphone) /HEADSET Button and Indicator (p. 21, 25, 54) Antennas (p. 3, 10) Button (p. 44) Display (p. 9, 58) Button (p. 49) (PAUSE) Button (p. 29) (REDIAL) Button (p.
  • Page 7 Button (p. 50) (TONE) (VOICE!MAIL) (EDIT) (EXIT) Button (p. 51) (FLASH/CALL!WAIT) Button (p. 33, 43) (CLEAR) CALLER ID Indicaor (p. 27) Navigator Key Button (p. 48) (p. 22, 28, 40) Button (p. 31) Button (p. 28, 41) Headset Jack (p. 54)
  • Page 8 Location of Controls Handset Ringer/Charge Indicator (p. 11, 35) Back side Speaker (p. 19) Button (VOICE!MAIL) (p. 48) Headset Jack (p. 54) (Talk) Button (p. 18, 25) (Speakerphone) Button (p. 19, 25) Navigator Key (p. 15, 19, 28, 40) Charge Contact (p. 12) Button (p.

  • Page 9: Displays

    Displays Handset 0 new call & $The voice mail icon indicates you have received voice mail messages (p. 46). %The directory icon displays when storing or viewing the directory items (p. 36, 40). &The battery icon indicates the battery strength (p. 11). Standby mode: While the handset is off the base unit, the display becomes blank after you finish using the handset (making/answering a call, viewing the Caller...

  • Page 10: Settings

    Settings Connections Raise the antennas. •USE ONLY WITH Panasonic AC ADAPTOR PQLV10 (Order No. PQLV10Z). •The AC adaptor must remain connected at all times. (It is normal for the adaptor to feel warm during use.) •To connect a standard telephone on the same line, see page 55.

  • Page 11: Battery Charge

    Battery Charge Place the handset on the base unit and charge for about 8 hours before initial use. •The ringer/charge indicator lights. •If the battery has been fully charged, the ringer/charge indicator light will turn from red to green. Battery strength You can check the battery strength on the handset display while the handset is on the base unit, while it is in use (making/answering a call etc.), or after viewing the Caller List or directory items, programming etc.

  • Page 12: Battery Information

    •If you DO NOT recharge the handset battery for more than 15 minutes, the display will keep indicating “Recharge battery” and/or “ to flash. Battery information After your Panasonic battery is fully charged (p. 11): Operation While in use (TALK)

  • Page 13: Selecting The Dialing Mode

    Selecting the Dialing Mode You can program the dialing mode using the handset near the base unit. If you have touch tone service, set to “Tone”. If rotary or pulse service is used, set to “Pulse”. Your phone comes from the factory set to “Tone”. Make sure the unit is in the standby mode initially.

  • Page 14: Selecting The Line Mode

    Settings Selecting the Line Mode If the line is connected to a low voltage system such as a PBX, set to “B”. Otherwise the Call Waiting Caller ID Feature may not be used (p. 50). Your phone comes from the factory set to “A”. Use the handset near the base unit.

  • Page 15: Programmable Functions

    Programmable Functions You can program the following function items using the handset near the base unit. The display shows the programming instructions. See the corresponding pages for function details. Make sure the unit is in the standby mode initially. Press (FUNCTION/CH) <Function menu>* Save directory...

  • Page 16: Setting The Auto Talk Feature

    Programmable Functions Setting the Auto Talk Feature The Auto Talk feature allows you to answer a call by lifting the handset off the base unit without pressing feature, turn the feature ON by programming. Your phone comes from the factory set to OFF. Make sure the unit is in the standby mode initially.

  • Page 17: Selecting The Ringer Volume

    Selecting the Ringer Volume You can set the handset and base unit ringer volumes to HIGH, LOW or OFF. If set to OFF, the handset/base unit will not ring. Handset ringer volume Make sure the unit is in the standby mode initially. Press (FUNCTION/CH) Press...

  • Page 18: Making Calls

    Making Calls With the Handset For best performance, extend the antenna fully (p. 8). Reciever Microphone Press Dial a phone number. •The dialed number is displayed. •After a few seconds, the display will show the length of the call and the battery strength. To hang up, press handset on the base unit.
  • Page 19 To have a hands-free phone conversation (Using Digital Duplex Speakerphone) Press •The button lights. Dial a phone number. •The dialed number is displayed. •After a few seconds, the display will show the length of the call and the battery strength. When the other party answers, talk into the microphone.

  • Page 20: Lighted Handset Keypad

    Making Calls If noise interferes with the conversation Extend the antenna, press move closer to the base unit. To redial the last number dialed on the handset Press To dial after confirming the entered number Dial a phone number. •If you misdial, press (CLEAR/INTERCOM) and dial again.

  • Page 21: With The Base Unit

    (HOLD/RINGER) Press (DIGITAL!SP-PHONE) •The DIGITAL SP-PHONE indicator lights. Dial a telephone number. When the other party answers, talk into the MIC (microphone). To hang up, press •The indicator light goes out. •To switch to the handset while using the base unit speakerphone: —If the handset is off the base unit, press...

  • Page 22: Speaker (P

    Making Calls Hands-free Digital Duplex Speakerphone For best performance, please note the following: •Talk alternately with the caller in a quiet room. •If the other party has difficulty hearing you, press speaker volume. •If the other party’s voice from the speaker cuts in/out during a conversation, press To adjust the speaker volume (8 levels) while talking To increase, press...

  • Page 23: Simultaneous Keypad Dialing

    Simultaneous Keypad Dialing You can use the base unit like a standard telephone. After pressing to make a call with the handset near the base unit, you can also dial using the base unit keypad. Handset: Press Base unit: Dial a telephone number while hearing a dial tone on the handset.

  • Page 24: Answering Calls

    Answering Calls When a call is received, the unit rings, “Incoming call” is displayed and the ringer/charge indicator flashes. If you subscribe to a Caller ID service, the calling party information will be displayed after the first ring (p. 26). In order to view the Caller ID information, please wait until the second ring to answer a call.

  • Page 25: With The Base Unit

    With the Base Unit Press (DIGITAL!SP-PHONE) Talk into the MIC. To hang up, press (DIGITAL!SP-PHONE) MIC (DIGITAL!SP-PHONE)

  • Page 26: Caller Id Service

    Caller ID Service This unit is compatible with a Caller ID service offered by your telephone company. If you subscribe to a Caller ID service, the calling party’s information will be shown on the handset and base unit displays after the first ring.

  • Page 27: To Check The Number Of New Calls

    To check the number of new calls When new calls have been received, the CALLER ID indicator flashes on the base unit. The handset and base unit displays show the number of new calls. Ex. You have received 10 new calls. While the handset is on the base unit: Handset display 10 new calls...

  • Page 28: Using The Caller List

    Using the Caller List Viewing the Caller List You can view the caller list with the handset or base unit. Caller List information includes the caller’s name and phone number, the time and date the call was received, and the number of times that caller called. Make sure the unit is in the standby mode initially.

  • Page 29: Calling Back From The Caller List

    What “√” means When the display shows “√”, you have already viewed this calling information, answered the call or called back the caller. If a caller calls more than once The number of times the same caller called is displayed ( 2 to 9).

  • Page 30: Editing The Caller's Phone Number

    1 – Area code •The order in which patterns a–d are displayed depends on how the telephone number is displayed in step 3. After editing the number, you can continue with calling back or storing procedures. To call back, press To store the number in the directory, press the instructions on the display (see page 32).
  • Page 31 Phone no. d 1 – Area code •The order in which patterns a–d are displayed depends on how the telephone number is displayed in step 2. After editing the number, you can continue with calling back. Press (DIGITAL!SP-PHONE) •The number edited in step 3 will not be maintained in the Caller List.

  • Page 32: Storing Caller List Information In The Directory

    Using the Caller List Storing Caller List Information in the Directory You can store names and phone numbers that are in the Caller List into the directory. You can also turn the call group feature on for certain callers (p. 35). Storing must be carried out with the handset.

  • Page 33: Erasing Caller List Information

    Erasing Caller List Information After checking the Caller List, you can erase some or all of the entries with the handset or the base unit. Make sure the unit is in the standby mode initially. To erase a specific caller from the Caller List With the handset/base unit: Press...

  • Page 34: One-Touch Dialer

    One-Touch Dialer You can store a phone number in the stored number is dialed with a one-touch operation. Storing a Phone Number in the DIRECT Button Make sure the unit is in the standby mode initially. Press (FUNCTION/CH) Press Ö Ñ...

  • Page 35: Dialing The Stored Number In The Direct Button

    Dialing the Stored Number in the DIRECT Button Press (DIRECT) •The stored number is displayed. Press •The number is dialed. •You can also dial the stored number by pressing (DIRECT). •If your line has rotary or pulse service, any access numbers stored after pressing (TONE) will not be dialed.

  • Page 36: Storing Names And Numbers In The Directory

    Using the Directory Storing Names and Numbers in the Directory Store a name and number, then if required, turn the call group feature on for the item. Storing must be carried out with the handset. Make sure the unit is in the standby mode initially. Press (FUNCTION/CH) While the arrow points to “Save...
  • Page 37 To turn the call group feature on, select “On” by pressing Ü If not required, select “Off”. •When “On” is selected, the display will light in orange and a different ringer pattern will be “Off” heard. When ringer pattern will be heard. Press (Next key).

  • Page 38: Selecting Characters To Enter Names

    Using the Directory Selecting Characters to Enter Names The handset dialing buttons ( used to enter letters and symbols. The letters are printed on the dialing buttons. Pressing each button selects a character as shown below. Keys Blank Ü To move the cursor to the left á...
  • Page 39 For example, to enter “Tom Jones”: Press (FUNCTION/CH) While the arrow points to “Save directory”, press Press Press six times, then press move the cursor to the right. Press four times. Press twice to enter a blank. á Press Press six times, then press move the cursor to the right.

  • Page 40: Finding Items In The Directory

    Ö to enter the directory list. repeatedly until the to enter the directory list. Directory list =Caller’s list 1234567890 Press Ö. Press Ñ. Alphabet letter Symbol Number Telephone number (If no name is stored) Directory list =Caller’s list...

  • Page 41: Dialing From The Directory

    Index table Keys Index Other symbols, 1 A, B, C, 2 D, E, F, 3 G, H, I, 4 J, K, L, 5 •You can leave the directory list any time. If using the handset, press (OFF). If using the base unit, press (EXIT). •If “No items stored”...

  • Page 42: Editing An Item In The Directory

    Using the Directory Editing an Item in the Directory You can edit a name and phone number of a stored item and change the group setting (p. 35). Programming must be carried out with the handset. Make sure the unit is in the standby mode initially. Press Ü...

  • Page 43: Erasing An Item From The Directory

    Press (Next key). á •If you want to change the storing name, number or group setting, press Ñ (Edit key) repeatedly to reach the desired display and change it. Press (Save key). á •A beep sounds. •To continue editing other items, repeat from 3. •To return to the standby mode, press (OFF).

  • Page 44: Intercom

    Intercom A 2-way intercom is possible between the handset and the base unit. Paging the base unit from the handset Handset: Press (CLEAR/INTERCOM) to the paged party after the beeps. •“Intercom” is displayed. Base unit: When the other party’s voice is heard, answer using the MIC.

  • Page 45: Transferring A Call Using The Intercom

    During an intercom call: •Intercom calls can only be ended with the handset. •If the handset user has difficulty hearing the base unit user, decrease the base unit speaker volume by pressing Ö. •If an incoming call is received, the intercom call stops and the unit starts to ring.

  • Page 46: Voice Mail Service

    Voice Mail Service Voice mail service is an electronic on-line answering system offered by your telephone company. After subscribing, the voice mail system can answer calls automatically when your line is busy or if calls are not answered. Callers can leave messages by following the pre-recorded instructions.

  • Page 47: Setting The Voice Mail Tone

    To erase a stored number Press and hold (CLEAR/INTERCOM) •You can exit the programming mode any time by pressing (OFF). Setting the Voice Mail Tone If your voice mail service sends a voice mail tone after a new message has been recorded, set to “On”.

  • Page 48: Listening To Voice Mail Messages

    With the handset Press (VOICE!!MAIL) press •The unit is connected to the telephone line and dials the access number (p. 46). Follow the pre-recorded instructions. When finished, press •If “Voicemail” and “...

  • Page 49: Special Features

    Each time you place the handset on the base unit, the unit automatically selects one of more than a million security codes. These codes help prevent the unauthorized use of your telephone line by another cordless telephone user. How to Use the PAUSE Button...

  • Page 50: For Call Waiting Service Users

    •The first call is put on hold and you can answer the second call. •To return to the first caller, press (FLASH/CALL!WAIT) again. •The call waiting service cannot be used when a parallel connected telephone is in use. •If this function does not operate properly, consult your telephone company for details.

  • Page 51: Flash Button

    (optional) such as call waiting. Selecting the flash time The flash time depends on your telephone exchange or host PBX. You can select the following flash times: “700, 600, 400, 300, 250, 110, 100 or 90 ms (milliseconds)”. Your phone comes from the factory set to “700 ms”.

  • Page 52: Wall Mounting

    Wall Mounting This unit can be mounted on a wall phone plate. Connect the AC adaptor. Tuck the telephone line cord inside the wall mounting adaptor, then push it in the direction of the arrow. •The word “UP” should face upward.

  • Page 53: Using The Belt Clip

    To charge the handset battery: Place the handset on the cradle and adjust the angle of the cradle in the direction of the arrow as shown. •The ringer/charge indicator lights. Using the Belt Clip You can hang the handset on your belt or pocket using the belt clip. To attach the belt clip Ringer/Charge Indicator To remove the belt clip...

  • Page 54: Using An Optional Headset

    Using an optional Headset Plugging an optional headset into the handset or the base unit allows a hands-free phone conversation. Please use only the Panasonic KX-TCA88 headset. To order call the accessories telephone number on page 2. With the Handset...

  • Page 55: Adding Another Phone

    Adding Another Phone This unit will not function during a power failure. To connect a standard telephone on the same line, use the Panasonic T-adaptor KX-J66. To order, call the accessories telephone number on page 2. Standard Telephone...

  • Page 56: Fashion Plate Tm Snap-On Color Covers (Optional)

    KX-TGA10. Three different color covers are included; brownstone, charcol and wineberry. To order, call the accessories telephone number on page 2. Remove the battery cover by sliding while pressing the arrow. Remove the battery. Replace the color cover (steps 2 through 5) and reconnect the battery within 3 minutes after disconnecting the battery—otherwise memory may be erased.
  • Page 57 Unlock the other tab by pressing horizontally (#) and vertically ($), and partially pull down the color cover (%) in the same way. Remove completely the cover from the handset. Place the new color cover fitting the tabs on the cover into their slots on the handset.

  • Page 58: Battery Replacement

    Battery Replacement If “Recharge battery” is displayed and/or “ fully charged, replace the battery with a new Panasonic HHR-P509 (PQHHR150AA23) battery. To order, call the accessories telephone number on page 2. To avoid memory loss, replace within 3 minutes. Remove the cover by sliding while pressing the arrow.

  • Page 59: Error Messages

    Error Messages If the unit detects a problem, one of the following messages will be displayed on the base unit or cordless handset. Handset display Recharge battery No link to base. Place on cradle and try again. Please lift up and try again Directory full Not available...

  • Page 60: Before Requesting Help

    Before Requesting Help Problem “No link to base. Place on cradle and try again.” is displayed and an alarm tone sounds. The unit does not work. Static, sound cuts in/out, fades. Interference from other electrical units. The handset and/or the base unit do not ring.
  • Page 61 •Other telephone equipment may be interfering with your phone. Disconnect it and try again. •Other electrical appliances connected to the same outlet may be interfering with the Caller ID information. •Telephone line noise may be affecting the Caller ID information.
  • Page 62 Before Requesting Help Problem The handset or base unit display goes to the standby mode while viewing the Caller List. When a second call is received during a conversation, the unit does not display the new caller’s name and/or phone number. You cannot page the handset or the base unit.
  • Page 63 •If “EXIT=Headset” is displayed on the base unit, press (EXIT) the speakerphone to the headset. •Call our customer call center at 1-800-211-PANA(7262). •Panasonic’s e-mail address for customer inquiries: consumerproducts@panasonic.com for customers in the USA or Puerto Rico ONLY to continue the...

  • Page 64: Important Safety Instructions

    Important Safety Instructions When using this unit, basic safety precautions should always be followed to reduce the risk of fire, electric shock, or personal injury. 11. Read and understand all instructions. 12. Follow all warnings and instructions marked on this unit. 13.
  • Page 65 CAUTION: To reduce the risk of fire or injury to persons, read and follow these instructions. 1. Use only the battery(ies) specified. 2. Do not dispose of the battery(ies) in a fire. They may explode. Check with local waste management codes for special disposal instructions. 3.

  • Page 66: Fcc And Other Information

    The REN is useful in determining the quantity of devices you may connect to your telephone line and still have all of those devices ring when your telephone number is called. In most, but not all areas, the sum of the REN’s of all devices connected to one line should not exceed five (5.0).
  • Page 67 • If there is any trouble — disconnect the unit from the telephone line and connect a known working phone. If the known working phone operates properly, have your unit repaired by one of the authorized Panasonic Factory Service Centers. If the known working phone does not operate properly, consult your...
  • Page 68 Symptom •Send the unit to an authorized servicenter, prepaid and adequately insured. •Do not send your unit to the Panasonic Consumer Electronics Company listed below or to executive or regional sales offices. These locations do not repair consumer products. Panasonic Consumer Electronics Company,...
