- Page 1 S3 standard control panel English Package MD4 23/01/06 Installation Technical instructions instructions...
-
Page 2: Table Of Contents
Spare parts .................14 Control panel S3... -
Page 3: Symbols Used
(the user shall take care to ensure that the system is installed by a qualified fitter). Keep to the polarity shown on the terminals : phase (L), neutral (N) and earth 23/01/06 - 300008905-001-A Control panel S3... -
Page 4: Description
Flue gas thermometer (Package BP28) cabinet. The control panel is used to control boilers with 1 or 2-stage burners. The control panel S3 equips the boilers GT 330. 2 Presentation Control panel S3 includes: In the event that there is an abnormal rise in the temperature in the boiler 110°... -
Page 5: Presentation
(See Moving the thermostat stop). 4. Boiler thermometer 5. Location for flue gas thermometer (optional) 6. Timed circuit breaker (10 A) with delayed action and manual reset 7. Safety thermostat with manual reset (set to 110 °C) 23/01/06 - 300008905-001-A Control panel S3... -
Page 6: Commissionning
See the instructions supplied with the control unit and any remote control unit used. • Check that safety thermostat 7 is properly set. To do so, Unscrew the safety thermostat cover and press the reset button using a screwdriver. Control panel S3 23/01/06 - 300008905-001-A... -
Page 7: Mounting - Connections
1 or 2 cable channels, depending upon the type of boiler. Attach the cables to the cable clamps provided for this purpose. Keep to the polarity shown on the terminals : phase (L), neutral (N) and earth 23/01/06 - 300008905-001-A Control panel S3... -
Page 8: Electricity Supply - Flow Controller
For other electrical connections, use the 3 wire cable with a diameter of 0.75 mm². The flow controller contact is connected to the safety circuit in series (between terminal 5 on the terminal block and terminal L1 on the burner, for example). Control panel S3 23/01/06 - 300008905-001-A... -
Page 9: Connecting The Burner
The diagram shows the wire numbers and the terminals of the burner connectors. Connect the terminal block to terminals 4 to 12 on the fixed terminal block on the control panel using the male pins. 23/01/06 - 300008905-001-A Control panel S3... - Page 10 - I > 2 A cos = 0.7 The burner controls must be relayed, e.g. with the relaying kit (package BP 51, optional) 7-pin plugs for connecting to the control panel and burner connectors. Control panel S3 23/01/06 - 300008905-001-A...
-
Page 11: Connecting The Safety Thermostat Alarm Report
(thermostat with reversal contact). If the safety thermostat trips, a 230 V signal is present on this terminal. Open the control panel (3 screws at the back) to access the back of the safety thermostat. 23/01/06 - 300008905-001-A Control panel S3... -
Page 12: Connecting The Flue Gas Thermometer (Package Bp28)
- Cut the cover off with a cutter along the edges of the coloured rectangle - Clip the thermometer into the opening - Bring the sensor to the back of the boiler via the cable channel and insert it in the flue gas pipe. Control panel S3 23/01/06 - 300008905-001-A... -
Page 13: Skeleton Diagrams
Skeleton Diagrams 23/01/06 - 300008905-001-A Control panel S3... -
Page 14: Spare Parts
Spare parts 23/01/06 - 300008905-002-A To order a spare part, quote the reference number next to the part required. Control panel S3 for GT 330 DE DIETRICH THERMIQUE S.A.S. - Spare parts centre 4 rue d’Oberbronn - F-67110 REICHSHOFFEN -... - Page 15 30 to 90 °C setting thermostat 8555-5501 Setting button + Pin 9534-0286 Timed circuit breaker (10 A) 200005244 Standard beam 8219-4905 Electric circuit 9531-7395 7-pin plug 9531-7384 4-pin plug 9536-5613 Contact spring for pocket 9758-1286 Spring for pocket 23/01/06 - 300008905-001-A Control panel S3...
- Page 16 DE DIETRICH THERMIQUE S.A.S. DE DIETRICH HEIZTECHNIK www.dedietrich.com www.dedietrich.com Direction des Ventes France Am Concorde Park 1 - B 4 / 28 57, rue de la Gare A-2320 SCHWECHAT / WIEN F- 67580 MERTZWILLER +43 (0)1 / 706 40 60-0...
