Operating Instructions
LED TV
Thank you for purchasing this Panasonic product.
Please read these instructions carefully before operating this product and
retain them for future reference.
Please carefully read the "Safety Precautions" of this manual before use.
The images shown in this manual are for illustrative purposes only.
M0216-0
Australia
TH-50DX700A TH-50DX700Z
TH-58DX700A TH-58DX700Z
TH-65DX700A TH-65DX700Z
For more detailed instructions, please refer to
[eHELP] (Built-in Operating Instructions).
●
How to use [eHELP]
Model No.
New Zealand
(p. 22)
TQB4GC1532
English
Advertisement
Table of Contents
Related Manuals for Panasonic TH-50DX700A
Summary of Contents for Panasonic TH-50DX700A
-
Page 1: Operating Instructions
● How to use [eHELP] (p. 22) Thank you for purchasing this Panasonic product. Please read these instructions carefully before operating this product and retain them for future reference. Please carefully read the “Safety Precautions” of this manual before use. -
Page 2: Table Of Contents
● For information about the trademarks, refer to [eHELP] (Support > Licence). The illustration for TH-58DX700A is used in this manual unless otherwise mentioned. Illustrations shown may be different between models and countries. Contents Be Sure to Read Important Notice··················································· 3 Safety Precautions ···············································... -
Page 3: Important Notice
Panasonic has no authority to and does not grant you that permission and explicitly disclaims any right, ability or intention to obtain such permission on your behalf. -
Page 4: Safety Precautions
● Do not use an unapproved pedestal / mounting plug. equipment. Be sure to ask your local Panasonic dealer to perform the setup or installation of approved wall-hanging brackets. ● Do not apply any strong force or impact to the display ●... - Page 5 Do not use the pedestal if it becomes warped or Caution physically damaged. If this occurs, contact your ● nearest Panasonic dealer immediately. The TV and Touch Pad Controller use the 2.4 GHz radio frequency ISM band (Bluetooth ). To avoid ®...
- Page 6 Support the TV as shown below to prevent injury that there are no breakable objects around you to avoid may be caused by the tipping or falling of TV. any accidental damage or injury. ● The recommended viewing distance is at least 3 times of the image height.
-
Page 7: Accessories
Remote Control Optional accessories (p. 18) ● N2QAYB001008 3D Eyewear ● If you need 3D Eyewear, please purchase Panasonic optional accessories. ● Use Panasonic 3D Eyewear supporting Bluetooth wireless technology for active shutter 3D. Touch Pad Controller ● For information about 3D Eyewear: (p. - Page 8 Take out the pedestal and the TV from the packing case and put the TV onto a work table with the screen panel down on the clean and soft cloth (blanket, etc.) ● Use a flat and firm table bigger than the TV. ●...
- Page 9 50-inch model 58-inch model ■ <Style1> English...
- Page 10 50-inch model 58-inch model ■ <Style2> English...
- Page 11 65-inch model ■ <Style1> English...
- Page 12 65-inch model ■ <Style2> English...
- Page 13 ■ Preventing the TV from falling over Band (2) It is recommended to secure the pedestal to a furniture as shown to prevent the TV from falling over. ● This information is designed to reduce the risk of injuries caused by the TV falling over. However, no Screw (2) measure can guarantee protection in all cases.
-
Page 14: Connections
Connections Terminals Australia ● External equipment and cables shown are not supplied with this TV. ● Please ensure that the unit is disconnected from the mains socket before attaching or disconnecting any cables. ● Check the terminal type and cable plugs are correct for connection. - Page 15 ■ ■ Mains lead Satellite dish New Zealand AC 220-240 V 50 / 60 Hz Mains lead Satellite cable Satellite dish ● For Satellite TV 65-inch model ● To ensure your satellite dish is correctly installed, please consult your local dealer. Also consult the received satellite broadcasting companies for details.
-
Page 16: Wireless Connection
■ Wired connection Other connections ■ DVD Player (COMPONENT equipment) Internet environment LAN cable (Shielded) (Viewing) ● Use Shielded Twist Pair (STP) LAN cable. ■ Wireless connection (Listening) Internet environment Built-in wireless LAN Access point DVD Player ■ Camcorder / Game equipment Connections for 4K compatible equipment (VIDEO equipment) - Page 17 ■ USB HDD (for recording) ● Fix cables as necessary. ● When using the optional accessory, follow the option’s ● Use USB 1 port for connecting the USB HDD. assembly manual to fix cables. ● For details, refer to [eHELP] (Recording). ■...
-
Page 18: Identifying Controls
Identifying Controls 7 OK ● Confirms selections and choices. ● Press after selecting channel positions to quickly change channel. ● Displays channel list. Remote Control 8 [Option Menu] ● Easy optional setting for viewing, sound, etc. 9 Coloured buttons (red-green-yellow-blue) ●... - Page 19 ■ Installing / Removing batteries Pull open Hook Close Note the correct polarity (+ or -) Touch Pad Controller The Touch Pad Controller is designed for convenient and intuitive operation, especially with [Home Screen] or internet content. ]: Standby On / Off switch ●...
- Page 20 ■ Installing / Removing batteries Red: Standby Green: On Orange: Standby with some functions (recording, etc.) active ● The LED blinks when the TV receives a command Slide open from the remote control. 4 Input mode selection ● Press repeatedly until you reach the desired mode. [Main Menu] ●...
-
Page 21: First Time Auto Tuning
First time Auto Tick the TV signal mode to tune, and then select [Start Auto Tuning] Tuning : tune (search for the available channels) : skip tuning Select your region (Satellite) New Zealand When the TV is turned on for the first time, it will Auto Tuning is now complete and the automatically search for available TV channels and give TV is ready for viewing. -
Page 22: Watching
Watching TV How to Use eHELP [eHELP] is the detailed operating instructions built into Turn power on the TV, and gives a more detailed explanation for a better understanding of the operation of each feature. (TV) Display [eHELP] (Remote Control) ●... -
Page 23: Viewing 3D Images
To view the 3D images ● Use Panasonic 3D Eyewear supporting Bluetooth wireless technology for active shutter 3D. ■ Playing back 3D-compatible Blu-ray disc (Frame Sequential format) ●... -
Page 24: Faqs
FAQs ● Parts of the TV may become hot. These temperature rises do not pose any problems in terms of performance or quality. Before requesting service or assistance, please follow When pushed with a finger, the display panel moves these simple guides to solve the problem. slightly and makes a noise ●... -
Page 25: Maintenance
Maintenance Specifications ■ First, remove the mains plug from the mains socket. Model No. : TH-50DX700A, TH-50DX700Z Display panel, Cabinet, Pedestal 50-inch model : TH-58DX700A, TH-58DX700Z 58-inch model Regular care: : TH-65DX700A, TH-65DX700Z 65-inch model Gently wipe the surface of the display panel, cabinet, Dimensions (W ×... - Page 26 Normal (Home) mode ETHERNET 10BASE-T / 100BASE-TX 50-inch model xxx W USB 1 / 2 / 3 58-inch model USB1: DC 5 V, Max. 900 mA [SuperSpeed USB xxx W (USB 3.0)] 65-inch model USB2 / 3: DC 5 V, Max. 500 mA [Hi-Speed USB xxx W (USB 2.0)] Standby power consumption...
- Page 27 ■ When using the wall-hanging bracket Built-in wireless LAN Choosing to wall mount the TV shall be done at the Standard compliance and Frequency range* owner’s risk. Always use a qualified installer to perform IEEE802.11a/n a TV wall bracket installation. Incorrect fitting may cause 5.15 GHz - 5.35 GHz, 5.47 GHz - 5.85 GHz equipment to fall, resulting in injury and product damage.
- Page 28 If there is a major failure in regard to the product which cannot be remedied then you must notify us within a reasonable period by contacting the Panasonic Customer Care Centre. If the failure in the product is not a major failure then Panasonic may choose to repair or replace the product and will do so in a reasonable period of time from receiving notice from you.
- Page 29 New Zealand WARRANTY - New Zealand only NEW ZEALAND Distributed in New Zealand by Panasonic New Zealand Limited 350 Te Irirangi Drive East Tamaki, Private Bag 14911, Panmure Auckland Tel. 09 272 0100 Customer Care Center Email: Customerservice@nz.panasonic.com www.panasonic.co.nz Warranty Information on Disposal in other Countries outside the European Union This symbol is only valid in the European Union.
