Dell™ Latitude™ E6440
Technical Guidebook
July 2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Latitude E6440 and is the answer not in the manual?

Questions and answers

Related Manuals for Dell Latitude E6440

Summary of Contents for Dell Latitude E6440

  • Page 1 Dell™ Latitude™ E6440 Technical Guidebook July 2013...

  • Page 2: Table Of Contents

    Table of Contents Latitude E6440 Product Views and Detailed Engineering Specifications 17 – 44 3 - 9 Technical Specifications Primary storage 18-25 E6440 Weight, Dimensions, Top/Right Optical drives 26-27 View Ports and connectors E6440 Back/Left View Webcam E6440 Bottom View...

  • Page 3: Latitude E6440 Product Views And Technical Specifications

    Latitude E6440 Product Views and Technical Specifications...

  • Page 4: E6440 Weight, Dimensions, Top/Right View

    Latitude E6440 Weight, Dimensions, Top/Right View 15. ODD Microphone 16. ODD tray release button 2. Display release button 17. Wireless switch. 3. Camera 18. Express card reader. 4. Camera status indicator 19. Fingerprint reader. 5. Microphone 20. SD card reader 6.

  • Page 5: E6440 Back/Left View

    Latitude E6440 Back/Left View 1. Security cable slot 2. USB 3.0 with power share. 3. RJ45 connector. 4. Battery status indicator. 5. HDD activity indicator. 6. Power status indicator 7. HDMI connector 8. Power connector 9. VGA connector 10. USB 3.0 connector 11.

  • Page 6: E6440 Bottom View

    Latitude E6440 Bottom View 1. Battery release latch (right) 2. SIM card slot 3. E-dock connector 4. Battery bay. 5. Battery release latch (left) 6. SD card reader 7. Speaker...

  • Page 7: Latitude E6440 Technical Specifications

    500GB FIPS Self-Encrypting Drive Storage Options Up to 180GB Solid State Drives 256GB Self-Encrypting Solid State Drive Dell Fast Response Free Fall Sensor and HDD Isolation (standard on the motherboard) DVD-ROM, DVD+/-RW Optical Drive Options High Quality Speakers Stereo global headset...
  • Page 8 Intel® vPro™ Technology’s advanced management features (optional, requires Intel WiFi® Link Systems Management WLAN) Limited Hardware Warranty ; Standard 3-year On Site Service after Remote Diagnosis (3-3-3); Warranty and Service Optional 3-year Dell ProSupport™ for IT ; 4 year and 5 year service and support options...
  • Page 9 A 64-bit operating system is required to support 4GB or more of system memory Intel Rapid Start requires a Solid-State Drive (SSD) or properly configured HDD + SSD Limited Hardware Warranty: For copy of Limited Hardware Warranty, write Dell USA LP, Attn: Warranties, One Dell Way, Round Rock, TX 78682 or see www.dell.com/warranty GB means 1 billion bytes and TB equals 1 trillion bytes;...

  • Page 10: Marketing System Configurations

    Marketing System Configurations...

  • Page 11: Operating Systems

    Latitude E6440 – Operating Systems Microsoft® Windows 7® Home Premium SP1 (32 and 64 bit), Microsoft® Windows 7® Home Premium w/MUI SP1 (32 and 64 bit), Windows operating system Microsoft® Windows 7® Professional w/MUI SP1 (32 and 64 bit), Microsoft® Windows 7® Professional SP1 (32 and 64 bit), Microsoft®...

  • Page 12: Intel Architecture

    Intel processor Technology ® Haswell Architecture Latitude E6540 is built with Intel 4 Generation Core processor Technology • Latest Intel 22nm Process Technology. • 4 generation Standard Voltage (2-chip) Dual Core Processor and Chipset • Intel Integrated HD Graphics 4600 ®...

  • Page 13: Memory

    Memory • Your computer supports a maximum of 16GB of memory when you use two 8GB DIMMs; however, 32-bit operating systems, such as the 32-bit version of Microsoft® Windows® 7, can only use a maximum of 4GB of address space. Moreover, certain components within the computer require address space in the 4GB range. Any address space reserved for these components cannot be used by computer memory;...

  • Page 14: Primary Storage And Intel Rapid Start Technology

    Primary Storage and Intel Rapid Start Technology Primary Storage E6440 320GB 7200rpm 500GB Solid State Hybrid (8GB cache) 500GB 7200rpm Self Encrypting Drive, FIPS certified Solid State Performance Hybrid 128GB Mobility SSD 180GB Mobility SSD 256GB Mobility Self Encrypting SSD (SED) Mobility Solid State Drives offer highly reliable, durable and lightweight storage.

  • Page 15: Connectivity Options

    Connectivity Options Connectivity Option E6440 WWAN Dell Wireless 5570 HSPA+ (42Mbps) Mini Card (Full mini card) Intel Centrino Advanced-N 6235 + Bluetooth 4.0 ® ® (802.11a/b/g/n 2x2 Half Mini Card) WLAN Intel Centrino Ultimate -N 6300 ® ® ® (half mini card) (802.11a/b/g/n 3x3 Half Mini Card)

  • Page 16: Security And Keyboard Specifications

    FIPS certified Trusted Platform Module (TPM) Optional Dell ControlVault™ with Swipe Fingerprint Reader, Smart Card Reader, Contactless Smart Card Reader and 34mm Express Card Optional Dell ControlVault™ with Smart Card Reader and 34mm Express Card Keyboard Specs Number of keys 83 (U.S)

  • Page 17: Detailed Engineering Specifications

    Detailed Engineering Specifications...

  • Page 18: Primary Storage

    5% to 95% non-condensing Max Dew point Temperature Altitude Range -1000 ft to 40000 ft For hard drives, GB means 1 billion bytes ; actual capacity varies with preloaded material and operating environment and will be less. Dell Confidential - NDA Use only...
  • Page 19 5% to 95% non-condensing Max Dew point Temperature Altitude Range -1000 ft to 40000 ft For hard drives, GB means 1 billion bytes ; actual capacity varies with preloaded material and operating environment and will be less. Dell Confidential - NDA Use only...
  • Page 20 5% to 95% non-condensing Maximum Wet Bulb Temperature Altitude Range -1000 ft to 40000 ft For hard drives, GB means 1 billion bytes ; actual capacity varies with preloaded material and operating environment and will be less. Dell Confidential - NDA Use only...
  • Page 21 5% to 95% non-condensing Max Dew point Temperature Altitude Range -1000 ft to 40000 ft For hard drives, GB means 1 billion bytes ; actual capacity varies with preloaded material and operating environment and will be less. Dell Confidential - NDA Use only...
  • Page 22 5% to 95% non-condensing Max Dew point Temperature Altitude Range -1000 ft to 40000 ft For hard drives, GB means 1 billion bytes ; actual capacity varies with preloaded material and operating environment and will be less. Dell Confidential - NDA Use only...
  • Page 23 128GB SSD 128GB SATA SOLID STATE DRIVE Capacity (GB) Approximately (2.75 x 3.94 x 0.268 inches) Dimensions inches (W x D x H) Interface type and Maximum speed Up to 6Gb/s (SATA 3.0) MTBF 1.2M hours Logical Blocks 250,069,680 Power Source Power Consumption (reference only) Idle 0.5W, Active 2.5W Environmental Operating Conditions (Non-Condensing):...
  • Page 24 180GB SSD 180GB SATA SOLID STATE DRIVE Capacity (GB) Approximately (2.75 x 3.94 x 0.268 inches) Dimensions inches (W x D x H) Interface type and Maximum speed Up to 6Gb/s (SATA 3.0) MTBF 1.2M hours Logical Blocks 1,230,918,888 Power Source Power Consumption (reference only) Idle 0.5W, Active 2.5W Environmental Operating Conditions (Non-Condensing):...
  • Page 25 256GB mSATA SED SSD (Opal certified) 256GB MSATA OPAL SELF-ENCRYPTING DRIVE – SOLID STATE DRIVE Capacity (GB) Approximately (1.175 x 2.00 x 0.150 inches) Dimensions inches (W x D x H) Interface type and Maximum speed Up to 6Gb/s (SATA 3.0) MTBF 1.2M hours Logical Blocks...

  • Page 26: Optical Drives

    Maximum Wet Bulb Temperature Altitude Range -200 to 3048m Environmental Non-Operating Conditions (Non-Condensing): Operating Temperature Range -40C to 65C Relative Humidity Range 5% to 95% RH Maximum Wet Bulb Temperature Altitude Range -200 to 10600m Dell Confidential - NDA Use only...
  • Page 27 Maximum Wet Bulb Temperature Altitude Range -200 to 3048m Environmental Non-Operating Conditions (Non-Condensing): Operating Temperature Range -40C to 65C Relative Humidity Range 5% to 95% RH Maximum Wet Bulb Temperature Altitude Range -200 to 10600m Dell Confidential - NDA Use only...

  • Page 28: Ports And Connectors

    Ports and Connectors E6440 Total 4 USB connectors. USB 3.0 (4) Video VGA, HDMI (video output) Network Adapter RJ-45 network adapter Four channel high definition audio Realtek ALC3226 Controller Stereo conversion: 24-bit (analog-to-digital and digital-to-analog) Internal Interface - high-definition audio codec. Audio External Interface - microphone-in and stereo headphone/headset combo connector Speakers: Average Power / Peak Power : 2X1W / 2x1.5W...

  • Page 29: Webcam

    Webcam Specifications Easy Remote Collaboration: Videoconference online with an optional built-in camera. • • Dell Webcam Central software pre-installed for camera setup on MS Windows 7 configurations only Webcam Features E6440 Camera Type HD fixed focus Sensor Type CMOS sensor technology Resolution: Motion Video Up to 1280 x 720 (0.92 MP)

  • Page 30: Wireless Lan

    Wireless Communications: Wi-Fi (WLAN) Intel® 6235 2X2 802.11n + Bluetooth 4.0 + WiDi Host interface Half Mini Card form factor, based on PCIe electrical interface Network standard IEEE 802.11a/b/g/n Wi-Fi Alliance Certifications Wi-Fi Certified for 802.11a, 802.11b, 802.11g, 802.11n, WMM, WPA, WPA2, and WPS Wi-Fi Direct for peer to peer device connections Operating Frequency Bands 2.4 GHz and 5 GHz...
  • Page 31 Wireless Communications: Wi-Fi (WLAN) Intel® 6235 2X2 802.11n + Bluetooth 4.0 + WiDi Wireless PAN Standard Dual Mode Bluetooth* 2.1, 2.1+EDR, 3.0, 3.0+HS, 4.0 (BLE) Bluetooth Data rates Up to 13Mbps Bluetooth Operating Frequency Bands 2.4GHz Bluetooth Profiles Supported Includes Streaming Stereo Quality Audio (A2DP), File Transfer (FTP), Dial-up Networking (DUN), Mice/Keyboards (HID), Printing (BPP), Digital Image Management (transfer, print, remote camera...
  • Page 32 Wireless Communications: Wi-Fi (WLAN) Intel ® Centrino ® Ultimate ® - N 6300 Host interface Half Mini Card form factor, based on PCIe electrical interface Network standard IEEE 802.11a/b/g/n Wi-Fi Alliance Certifications Wi-Fi Certified for 802.11a, 802.11b, 802.11g, 802.11n, WMM, WPA, WPA2, and WPS Operating Frequency Bands 2.4 GHz and 5.0 GHz Multi-Stream N...
  • Page 33 Wireless Communications: Wi-Fi (WLAN) Dell Wireless DW1506 Wi-Fi Host interface PCI Express™ Half Mini-Card Network standard 802.11b, 802.11g, and 802.11n Wi-Fi Allliance Certifications 802.11b, 802.11g, WPA, WPA2, WMM Operating Frequency Bands 2.4 GHz (802.11b/g/n) Dual Diversity Antenna Switching Dual diversity antenna switching for systems designed with main and auxiliary antennas.

  • Page 34: Mobile Broadband

    Wireless Communications: Mobile Broadband Dell Wireless DW5570 HSPA+ Mini Card Carrier AT&T Mobility Vodafone TeliaSonera Rogers Telstra Network HSPA+/3G HSPA+/3G HSPA/3G HSPA+/3G HSPA+/3G Speed (Downlink) < 21.1 Mbps < 21.1 Mbps < 7.2 Mbps < 21.1 Mbps < 21.1 Mbps Speed (Uplink) <...

  • Page 35: Wired Communications

    Wired Communications Integrated Modem V.92 Data/Fax Internal Modem Optional HDA Bus Network Adapter (NIC) – Intel – E6540 Intel® I217 Gigabit Ethernet Controller Integrated on system board External connector type RJ-45 Data Rates 10/100/1000 Mbps Controller bus architecture PCI-e V1.1x1 1000 Mbps: 535 mW Power consumption 100 Mbps: 260 mW...

  • Page 36: Integrated Graphics Controller

    Integrated Graphics Controller Integrated Graphics Controller Intel HD, HD 4600 (Intel Haswell i3/i5/i7 Processors) Model E6440 Bus Type Internal PCIe Memory Interface N/A (unified memory architecture) Core i7: 400 MHz graphics core Clock Speeds Core i5: 400 MHz graphics core Core i3: N/A Core i7: 1300MHz Max Graphics dynamic frequency...

  • Page 37: Discrete Graphics Controller

    AMD Discrete Graphics Controller AMD® Radeon HD™ 8690M (GDDR5 2GB) Discrete Graphics Controller Graphics with AMD PowerXpress™ Models E6440 Graphics Memory 2GB GDDR5 Bus Type Internal PCIe Memory Interface 64-Bit Clock Speeds 975 MHz graphics core Estimated Maximum Power Consumption LVDS, Analog VGA, HDMI, DisplayPort, DVI(requires optional E-Port Display Support or E-Port Plus)

  • Page 38: Displays

    Display 14.0" HD E6440 Anti-Glare LCD display with LED backlight Type HD Anti-Glare Luminance (typical) 200 nits Dimensions Height 205.6mm(maximum) Width 320.9mm(maximum) Diagonal 14.0” Native Resolution 1366 x 768 Megapixels 1.05 Pixels per Inch (PPI) Contrast Ratio (min) 300:1 Response Time (max) 25 msec rise/fall Refresh Rate 60 Hz...

  • Page 39: Displays

    Display 14.0" HD+ E6440 Anti-Glare LCD display with LED backlight Type HD+ Anti-Glare Luminance (typical) 300 nits Dimensions Height 205.6mm(maximum) Width 320.9mm(maximum) Diagonal 14.0” Native Resolution 1600 x 900 Megapixels 1.44 Pixels per Inch (PPI) Contrast Ratio (min) 300:1 Response Time (max) 25 msec rise/fall Refresh Rate 60 Hz...

  • Page 40: Batteries

    Latitude E6440 – Battery Specification 6cell 65Whr 9cell 97Whr Battery Type Lithium ion Lithium ion Dimension Length 208.00 mm (8.18") 214.00 mm (8.43") Width 48.08 mm (1.9") 71.79 mm (2.83") Height 20.00 mm (0.79") 20.00 mm (0.79") Weight 348.00 g (0.77 lb) 524.00 g (1.16 lb)

  • Page 41: Power Adapters

    Power Adapters Auto/Air Adapter E4 65W E5 65W E5 90W E4 130W BFR/PVC free Specifications Input voltage 11-16VDC 100 to 240 VAC 100 to 240 VAC 100 to 240 VAC 100 to 240 VAC 100 to 240 VAC Input current (max) 9.0 A 1.5 A 1.5 A...

  • Page 42: Keyboards

    Latitude Keyboards Hot Key Definition Keyboard Shortcuts Keyboard Shortcuts Fn+F1 – Standby Fn+F10– Audio Puts the system into Standby (S3) - does Used for selecting the previous audio Previous not wake the system. track Fn+F2 – Num Lock Fn+F11 – Audio Used as Num Lock key.

  • Page 43: Touchpad

    Touch Pad Specifications Touch Pad X: 25.33+/-2.53 counts/mm = 643.38+/-64.26 DPI X/Y position resolution Y: 37.06+/-3.71 counts/mm = 941.32+/-94.23 DPI Sensor-active area: Size • Width: 77mm (3.03”) • Height: 41.5mm (1.63”) Multi-Touch Configurable Single Finger and Multi-Finger gestures Supported Gestures Windows 7 Circular Scrolling Supported (disabled by default)

  • Page 44: Operating Conditions And Mil-Std-810G Testing

    Vibration Operational (Method 514.6 I Cat 4) Vibration Non-Operational (Method 514.6 I Cat 24) IEC IP5x Dust Ingress Protection (IEC60529 Keyboard Spill Test Link to Product Safety, EMC and Environmental Data Sheets: http://www.dell.com/content/topics/global.aspx/about_dell/values/regulatory_compliance/dec_conform?c=us&cs=04&l=en&s=bsd&redirect=1 Tests completed by independent 3 party ISO/IEC-17025 certified laboratories.
