SERVICE
TFT-LCD Monitor
T220 / T220(G)
T200 / T200(G)
Refer to the service manual in the GSPN (see the rear cover) for the more information.
LCD-Monitor
Chassis
: LTW22HS / LTW22GS
LTW20HS / LTW20GS
Model
: T220 / T220(G)
T200 / T200(G)
Manual
1. Precautions
2. Product specifications
3. Disassembly and Reassemble
4. Troubleshooting
5. Exploded View & Part List
6. Wiring Diagram
7. Schematic Diagram
Contens

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T220 and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung T220

Summary of Contents for Samsung T220

  • Page 1 LCD-Monitor Chassis : LTW22HS / LTW22GS LTW20HS / LTW20GS Model : T220 / T220(G) T200 / T200(G) SERVICE Manual TFT-LCD Monitor Contens 1. Precautions 2. Product specifications 3. Disassembly and Reassemble 4. Troubleshooting 5. Exploded View & Part List 6. Wiring Diagram 7. Schematic Diagram T220 / T220(G) T200 / T200(G) Refer to the service manual in the GSPN (see the rear cover) for the more information.
