Toner Cartridge Errors

Insert Yellow/Cyan/Magenta/Black Cartridge

Non-Xerox Toner, Invalid Yellow/Magenta/Cyan/Black

Replace Yellow/Magenta/Cyan/Black

Yellow/Magenta/Cyan/Black Low

Phaser 6130 Color Laser Printer Service Manual
The printer does not detect the Toner Cartridge.
The Toner Cartridge CRUM ID error indicates that a non-Xerox Toner
Cartridge is installed.
The Toner Cartridge (Yellow/Magenta,/Cyan/Black) has reached its end of life.
The Toner Cartridge (Yellow/Magenta,/Cyan/Black) is near its end of life.
Initial Actions
Check the Toner Cartridge life using CentreWare IS.
Cycle printer power.
If problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts
Toner Cartridge (Y/M/C/K),
PL5.1.21-24
MCU Board, PL8.2.13
Troubleshooting Procedure Table
Step Actions and Questions
1 Check the Toner Cartridge for correct
installation. Is the Toner Cartridge
correctly installed?
2 Reseat the Toner Cartridge. Make sure
the lock key is in the lock position.
Does the error still occur?
Error Messages and Codes
Wiring and Plug/Jack Map References
"Map 1 - Transfer Unit, Control Panel,
Imaging Unit, Dispenser, Fuser" on
page 10-8
"Map 4 - Toner Dispenser Motors, HVPS,
MCU" on page 10-11
"Developer" on page 10-27
Yes
Go to step 3.
Go to step 3.
No
Go to step 2.
Complete.
3-27
