SERVICE
DIGITAL LASER MFP
DIGITAL LASER MFP
SCX-6322DN/XEU
Basic Model : SCX-6322DN/XAA
Manual
The keynote of Product
[Key Features]
1. General Spec
- CPU : 240 MHz Chorus-M
- Memory : 64MB SDRAM
- USB2.0, IEEE1284, Ethernet 10/100 base TX
- Toner: 8K (Std.) / Drum : 20K
- 50sh DADF (SCX-6322DN), 40sh ADF (SCX-6122FN)
- 550sh x 1 Tray (Max.550sh x 2 Tray), 100sh MP Tray
- Machine Life : 300K pages
2. Copying
- 20cpm/Ltr. (SCX-6322DN),
17cpm/Ltr. (SCX-6122FN)
- 600 x 600dpi, 25-400% Zoom Copy
3. Printing
- 23ppm /Ltr., 1200dpi Effective output Quality
- PCL6, PS3, Duplex Standard
4. Scan
- Scan to Email/SMB/FTP, 20 Sec.(Gray) Scan speed
- JPEG, TIFF, PDF
5. FAX
- 33.6Kbps, PC-FAX
- Send from Local/Remote PC
- Fax forward to Folder
6. Options
- 2nd Tray (550sh)
