Summary of Contents for Lamona LAM8301
- Page 1 LAM8301...
- Page 2 Welcome Dear Customer Congratulations on your choice of a quality dishwasher which has been designed to give you excellent service. Please read these instructions before installing the dishwasher and using it for the first time. The information contained herein is provided to avoid accidental risks and/or damage to your appliance Make sure you understand the controls prior to using your appliance.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1 Know your dishwasher 7 Operating the dishwasher Unpacking Specification 8 How to clean your machine 22 Upper spray arm Lower spray arm 2 Programme Chart 9 Before calling service 3 Warning and safety / Trouble shooting information Electrical Safety 10 Guarantee... -
Page 4: Know Your Dishwasher
Know your dishwasher / specification (P19) (P21) (P20) (P23) (P14) (P23) (P19) (P22) (P20) Please Clean Regularly Failure to clean will result in poor performance (P20) Unpacking Remove all Packing From the unit and dispose of this according to local regulations. -
Page 5: Specification
Specification Load Capacity : 10 Place settings Height : 820 mm Width : 448 mm Depth : 570 mm Net weight : 32 kg Supply voltage : 220-240 V ~ 50 Hz Fuse currrent : 13 A Total power : 2200 W Heater power : 1900 W Pump powers... -
Page 6: Programme Chart
Programme Chart 5 GB... -
Page 7: Warning And Safety Information
Warning and safety information Electrical Safety After unpacking your machine, keep The dishwasher should only be the packing material out of children’s operated on the voltage specified. For reach. electrical safety, only earthed plugs and sockets should be used. Always Warning ! use the fused plug provided with the Long cutlery, such as ladles and... -
Page 8: Recycling
problem it is advised that you cut the dangerous for the environment and mains cable off and break the door human health due to the presence of latch so it does not lock. hazardous substances. Energy and water saving The door of your machine is designed to support the weight of a full basket Scrape excess food from the dishes when the lower basket is pulled all the... -
Page 9: Before First Use
Do not wash forks, knives and spoons Any repairs and maintenance work with wooden or bone handles, items on this dishwasher should be carried stuck together with adhesives, out by authorised service staff only. Unauthorised repairs are not only plastic items not resistant to high temperatures. -
Page 10: Electrical Requirements
The supply cord or the mains lead must be replaced by a Lamona Connect the blue (neutral) wire to Authorized Service Agent or a similarly the terminal in the plug marked ‘N’... -
Page 11: Water Inlet Hose Connection
Water inlet hose connection Drain Hose Connection Make sure your plumbing is suitable to Fit the drainage hose of your machine install your new dishwasher. If in doubt to the drainage pipe without bending. contact a qualified plumber. Secure your hose firmly to the waste The appliance must be connected pipe to avoid it coming off during the to the water mains using the new... -
Page 12: Installation Of Dishwasher
4 4 8 ( + 1 0 0 ) ( + 1 0 0 ) Installation of dishwasher Note: Position the machine next to a water An additional sheet containing tap and a drain. assembly and installation instructions is provided with your appliance. Please When inserting the machine, ensure follow the instructions and precautions that the water inlet and drain hoses are... -
Page 13: How To Use
Make sure your dishwasher is perfectly level using the adjustable feet. When the appliance is correctly levelled, the door will not catch on the inner liner on either side of the cabinet. If the door does not close correctly, loosen or tighten the adjustable feet, until the machine is perfectly level. -
Page 14: Water Hardness & Regeneration Settings
Water Hardness Level Hardness Clarke German French Level degrees degrees degrees° Hardness Level Displayed °dE °dH Level 1 1 st programme indicator lights 2 nd programme indicator lights Level 2 7-14 6-11 10-20 3 rd programme indicator lights Level 3 15-21 12-17 21-30... -
Page 15: Visual Indicator
Adding Dishwasher Salt Only use special pelletized dishwasher salt in your machine to soften the hard water. Never use other types of salts including table salt, animal feeding salt, sea salt, culinary salt. These types of salt do not dissolve in water easily and will damage your appliance beyond repair. -
Page 16: Detergent Use
Detergent use Warning! Two-in-one and three-in-one Any brand of powder, gel and tablet detergents detergents that have been designed for You will obtain the best results from household dishwashers, may be used. your dishwasher if you use separate detergent, rinse aid and water- Keep detergents in a cool and dry softening salt. - Page 17 Using two-in-one detergent and dishwasher. Always place the rinse aid tablets in the detergent dispenser • These detergents will not give you of the detergent holder. the same drying performance that you can obtain by using separate Using three-in-one detergent, detergent, salt and rinse aid.
-
Page 18: Filling Detergent Dispenser
Detergent residues hardness shown in the manual. Regular use of low temperature • Put the rinse aid setting at the washes and/or short duration correct level. programmes can lead to undissolved detergent residue build up. We Filling recommend to carry out a service wash detergent at the highest temperature possible dispenser... -
Page 19: Loading The Dishwasher
Loading the dishwasher Position 6: maximum dose.) Gradually increase the dose if there are drops of Loading the dishwasher correctly will water or lime spots on the dishes after increase the washing, drying and washing. Reduce it if there are sticky energy performance of your machine. -
Page 20: Loading The Upper Basket
When loading your dishwasher please ensure tall glasses (and/or wine glasses) rest against the sides of the upper basket. Do not allow tall glasses to rest against each other since they may be damaged during washing if not properly supported. Loading the Upper Basket 1. -
Page 21: Upper Basket Height Adjustment (Unloaded)
Place larger items such as saucepans in the lower basket. You can remove the cutlery basket to make room for other items .Place spoons and forks in the cutlery basket with handles down and knives with handles up to prevent accidental injury. Warning ! Long cutlery, such as ladles and long knives, etc must be placed... -
Page 22: Operating The Dishwasher
Operating the dishwasher • • Unload the baskets - we Turn the water tap on. Open the recommend to turn off the water tap door of the machine. • when not in use Check that the upper and lower arms can rotate freely. •... -
Page 23: How To Clean Your Machine
How to clean your machine Cleaning your machine at regular intervals ensures longer product life and reduces the risk of recurring problems. Clean spray arms and in particular filters at least once a week ! Always unplug the appliance and turn Main filter off the water supply before cleaning. -
Page 24: Upper Spray Arm
Pull the main filter off. Clean all three filters under running tap water with a brush. Reinsert the main filter in its place. Place the coarse filter into the micro filter. Ensure the marks align properly. Turn the coarse filter clockwise until you hear a clicking sound. -
Page 25: Before Calling Service / Trouble Shooting
Before calling service / Trouble shooting Before calling service check the following & Trouble shooting guide supplied on the following page. Is the dishwasher door closed firmly? Is the machine plugged in? Are the filters clogged? Does the fuse need replacing ? Is the detergent dosage and/or Is the water mains supply fully rinse aid sufficient? Is there... - Page 26 Remove spots with silver polish. Rewash. Wash soon Prolonged contact with salty Pitting of after use, or pre-wash items if they will not be washed or highly acidic foods or stainless steel right away. Do not overload cutlery basket. Avoid with undissolved or highly items spilling or pouring detergent directly on flatware.
- Page 27 Notes...
-
Page 28: Guarantee
What to do if you need to report a problem- Please ensure you have ready: - The product’s model & serial numbers - Howdens Proof of Purchase document - Your full contact details. Call the Lamona Service Line on 0845 00 60 006... - Page 29 Printed in Turkey Part no: 17 9474 01 00 Revision: AA-05/12...
