Philips HR 7754/01 Service Manual

Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION:
The Foodprocessor is equipped with mechanical and
thermal safety switches.

TECHNICAL DATA:

Motor : universal, radio / TV interference
suppressed
Power consumption : 800 Watt max.
Voltage & frequency : 230 V, 50 Hz
Cordset : 100 cm, double insulated with
moulded on plug
Speed setting : Smart Process Control
Bowl capacity : 2.5 L dry ingredients, 1.7 L liquids
Blender capacity : total jar capacity 2.0 L,
Speeds unloaded : blender drive shaft 19500 rpm (max)
accessories drive shaft from 660 rpm
to 2150 rpm, depends on application
Weight in fancy box : 6.200 g
Dimensions : 406 mm x 281 mm x 521 mm
fancy box (l x w x h)
This product meets the requirements regard-
ing interference suppression on radio and TV.
Published by Philips Domestic Appliances and Personal Care
4322 277 00895
04/01
Essence
SAFETY:
Automatically resettable : protects motor against overheating
thermal cut out
Built – in safety lock
Motor brake system
COLOURS:
White with Vapor Dusk accents, clear transparant bowl & jar
MATERIALS USED:
- Bowl, bowl lid, blender jar & safety cover, : SAN
JE lid
1.5 L effective
- Housing, screw cap, blender lid, pusher, : PP
inlay bowl handle
- juice extractor (sieve, pusher),
citrus press (sieve & cone)
- Panel foil
- Kneading accessory
- Balloon beater
- Insert holder, handgrip blender jar
- Adjustable slicing disc
After the product has been repaired, it should
function properly and has to meet the safety
requirements as offi cially laid down at this
moment.
Printed in the Netherlands
Foodprocessor
HR 7754/01
: detects wheter lid & bowl are
assembled
: stops the appliance within
1.5 seconds
: PP
: Santoprene
: PP / 30% chalk
: POM
: ABS
: POM, ABS,
© Copyright reserved Subject to modification
stainless steel
