Summary of Contents for Lamona LAM3400
- Page 1 LAM3400 Built in Electric LAM3402 LAM3403 Fan Oven User & Installation Guide...
- Page 2 LAMONA Appliances Dear Customer, Congratulations on your choice of oven which has been designed to give you excellent service. The user manual will help you use your product quickly and safely. Please read this user manual before installing and using the oven.
-
Page 3: Table Of Contents
User manual LAM3400 / LAM3402 / LAM3403 Index 01 - Before using the oven 07 - Cooking and baking advice Important safety information General 08 - Cooking tables Safety for children Safety when working with electricity 09 - Care and maintenance... -
Page 4: Index_ 04
User manual LAM3400 / LAM3402 / LAM3403 Important instructions and warnings for safety and environment This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. - Page 5 User manual LAM3400/3402/3403 Important instructions and warnings for safety and envi ronment Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering of the glass.
-
Page 6: Before Using The Oven
LAMONA Appliances Before using the Oven Make sure that you have removed all packaging, wrappings, stickers and from the oven’s surface. It is recommended that you clean and wash the oven’s surface before using for the time. Never use the product when your judgment or coordination is impaired by the use of alcohol and/or drugs. -
Page 7: Safety For Children
User manual LAM3400 / LAM3402 / LAM3403 and components inside the oven which maybe Product must be installed by a person hot. Always allow time for the oven in accordance with the regulations in force. to cool. Otherwise, the guarantee may become void. -
Page 8: General Information
LAMONA Appliances 02 - General Information Oven layout Control panel Oven light Handle Oven shelf runners Oven door Fan motor (behind steel plate) Control panel layout Main oven thermostat knob Digital timer Main oven function knob Oven / grill temperature indicator... -
Page 9: Preparation
User manual LAM3400 / LAM3402 / LAM3403 03 - Preparation Initial heating Initial use It is recommended to heat up the product for about 30 minutes and then switch it off. Thus any production residues or layers will be burnt off and removed. -
Page 10: Operating Modes
LAMONA Appliances 04 - Operating modes Operating modes All functions for the ovens and grill are listed in this section. The order of operating modes shown here might deviate from the arrangement on your appliance. Oven Light Fan-Grill This operates the oven internal light only,... -
Page 11: How To Operate The Oven And Grill
User manual LAM3400 / LAM3402 / LAM3403 05 - How to operate the oven and grill Select temperature The grill heats up to the adjusted temperature & Operating mode and maintains it. During heating, the temperature indicator light will remain on until the desired temperature is reached. -
Page 12: How To Operate The Timer
LAMONA Appliances 06 - How to operate the Timer How to operate the oven timer Keep button ‘ ’ pressed. Set the desired length of the cooking time with button ‘ ’ or ‘ ’. The clock will increase or decrease in one minute increments. If you press and hold button ‘... -
Page 13: Interrupting The Cooking Process
User manual LAM3400 / LAM3402 / LAM3403 Deactivate the program lock The oven is heated up to the set temperature and keeps this temperature until the end of the cooking time that has been selected. During the cooking Keep buttons‘... -
Page 14: Cooking And Baking Advice
LAMONA Appliances 07 - Cooking and baking advice Tips for baking cake If the cake is too dry, increase the temperature by 10°C and decrease the cooking time. If the cake is wet, use less liquid or lower the temperature by 10°C. -
Page 15: Cooking Tables
User manual LAM3400 / LAM3402 / LAM3403 08 - Cooking Table The values indicated in the tables below are Baking and roasting indicative. They may vary according to the type of Level 1 is the bottom level in the oven. -
Page 16: Care And Maintenance
LAMONA Appliances 09 - Care and maintenance Do not remove the control knobs General information for control panel cleaning. Cleaning oven door Service life of the product will extend and the possibility of problems will decrease if the product is Don’t use any harsh abrasive cleaners or sharp... -
Page 17: Removing The Inner Door Glass
User manual LAM3400 / LAM3402 / LAM3403 Removing the inner door glass The inner glass panel of the oven door can be The inner glass can then be lifted from its removed for cleaning. retaining slots. When cleaning, avoid the use any harsh... -
Page 18: Replacing The Oven Lamp
LAMONA Appliances Replacing the oven lamp Hot surfaces may cause burns! Make sure that the appliance is switched off and cooled down in order to avoid the risk of an electrical shock or burns. The oven lamp is a special electric lamp that can resist up to 300°C. -
Page 19: Installation
User manual LAM3400 / LAM3402 / LAM3403 10 - Installation Before installation The appliance is intended for installation in Howdens kitchen cabinets. The product should only be installed by suitably Surfaces, synthetic laminates and adhesives persons. used must be heat resistant. -
Page 20: Installation And Connection
LAMONA Appliances Installation and connection Risk of electric shock . Before starting any Material damage! work on the electrical installation, please The door and/or handle must not be used for lifting disconnect the mains supply. or moving the appliance. This appliance must only be installed by a We recommend 2 people handling of the electrician, e.g. -
Page 21: Cooling Fan
User manual LAM3400 / LAM3402 / LAM3403 Cooling fan Installation Slide the oven through the cabinet aperture, align and secure. Fix your oven with the 2 screws and washers as indicated in the illustration. Final check Control panel Connect the appliance to the mains supply, Door switch on the mains supply and check the oven’s... - Page 22 LAMONA Appliances TECHNICAL INFORMATION General Voltage /Frequency 220-240 V ~ 50 Hz Total power consumption 2.3kW Fuse min. 13 A Cable length max. 2 m Cable type / section H05VV-FG 2.5mm², 3 core or equivalent Oven/Grill External dimensions (height / width / depth)
-
Page 23: Troubleshooting
User manual LAM3400 / LAM3402 / LAM3403 12 - Troubleshooting TROUBLESHOOTING GUIDE Symptoms Possible Cause Solutions Oven emits steam when it Food is being cooked with a high It is normal that steam escapes from food during cooking. is in use. -
Page 24: Your Guarantee
LAMONA Appliances 13 - Your guarantee Product Guarantee Details (UK only) breakdown repairs. (Details of which are shown on your Proof of Purchase Document). Any claim during the period of the guarantee (MUST BE ACCOMPANIED BY THE PROOF OF PURCHASE) The product must be correctly installed and operated in accordance with the manufacturer’s... - Page 25 User manual LAM3400 / LAM3402 / LAM3403 Notes _ 25...
- Page 27 ISSUE V5 04-02-15 If supplied, please stick your self adhesive product rating plate here, or make a note of the product serial number below in the box below for future reference. Serial Number : ...................
Need help?
Do you have a question about the LAM3400 and is the answer not in the manual?
Questions and answers
How to i put the oven door back
To reinstall the oven door on a Lamona LAM3400, follow these steps:
1. Ensure the hinge housing clips are open.
2. Align the door hinges with the hinge slots on the oven.
3. Insert the hinges into the slots and ensure they are properly seated.
4. Close the clips at the hinge housing to secure the door.
Make sure the door is properly fitted before use.
