Installing The Filter - Teka CM 45 Instruction Manual

English
USING THE APPLIANCE FOR
THE FIRST TIME
• Coffee has been used to factory test the appli-
ance and it is therefore completely normal for
there to be traces of coffee in the mill. The ma-
chine is, however, guaranteed to be new.
• You should customise water hardness as soon
as possible following the instructions in the
"Setting water hardness" chapter.
1. Connect the appliance to the mains electricity
supply and press the main switch (A23).
You must select the required language:
2. To set English, wait for the appliance to display
"PRESS OK TO INSTALL ENGLISH".
While the message is displayed, press the OK
button (B9) (fig. 1) for at least 3 seconds until
"ENGLISH INSTALLED" is displayed.
The appliance then displays the setting con-
firmed message in English.
If you set the wrong language by mistake, follow
the instructions in the chapter "Changing the
language" to choose the right language.
Follow the instructions indicated by the appli-
ance:
3. After 5 seconds, the appliance displays "FILL
TANK". To fill the water tank, remove (fig. 2),
rinse and fill with fresh water without exceeding
the MAX line.
Replace the tank and push as far as it will go.
4. Place a cup under the cappuccino maker (fig. 3).
The appliance now displays: "HOT WATER
PRESS OK".
Press the OK button (B9) (fig. 1) and after a few
seconds a little water comes out of the cappuc-
cino maker. (Delivery stops automatically).
5 The machine now displays "TURNING OFF...
PLEASE WAIT" and goes off.
6. Extract the appliance by pulling it out using
the handles (fig. 4). Open the lid and fill the
container with coffee beans, then close the lid
and push the appliance in.
Important! To prevent malfunction, never
introduce pre-ground coffee, freeze dried coffee,
caramelised beans or anything else which could
damage the appliance.
The coffee maker is now ready for normal use.
N.B.! When using the appliance for the first
time, you need to make 4/5 cups of coffee and 4/5
cappuccinos before the appliance starts to give
satisfactory results.
N.B.! Each time the coffee maker is turned
on by using the main switch (A23), the appliance
performs a "SELF-DIAGNOSIS" cycle and then goes
off. To turn it on again, turn the knob
(to the right or left) (fig. 5).

Installing the filter

Some models are fitted with a water softener filter
to improve the quality of the water used and extend
the working life of the appliance. To install, proceed
as follows:
1. Remove the filter from the packaging (A25).
2. Slide the pointer of the date indicator (see fig.
28) until the months of use are displayed.
N.B. The filter lasts about 2 months if the ap-
pliance is used normally. If the coffee maker is
left unused with the filter installed, it will last a
maximum of 3 weeks.
3. Insert the filter in the water tank (A12) and press
it until it touches the bottom of the tank (see fig.
28).
4. Fill the tank and place in the coffee maker.
5. Turn the cappuccino maker (A10) outwards
and place a container underneath (min.
capacity 100 ml).
N.B. When you install the filter, you must
notify the appliance of its presence.
6. Press the MENU button (B6) to enter the menu;
7. Press the NEXT button (B7) until "INSTALL
FILTER" is displayed.
8. Press the OK button (B9).
102
(A7)
