Mid-wheel Powerchair

USER MANUAL

ATTENTION
Please read your
owner's manual
before driving your
Powerchair.
888WNLLHD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 888WNLLHD and is the answer not in the manual?

Questions and answers

Related Manuals for Shoprider 888WNLLHD

Summary of Contents for Shoprider 888WNLLHD

  • Page 1: User Manual

    Mid-wheel Powerchair USER MANUAL ATTENTION Please read your owner’s manual before driving your Powerchair. 888WNLLHD...

  • Page 2: Table Of Contents

    Table of Contents INTRODUCTION ......................3 EMI WARNING .........................4 SAFETY INSTRUCTIONS ....................6 FEATURE GUIDE ......................8 GETTING TO KNOW YOUR POWERCHAIR………………………………………..9 THE JOYSTICK CONTROLLER (SHARK) ..............10 GETTING READY TO DRIVE……………………............12 LOCKING / UNLOCKING THE JOY STICK CONTROLLER…………………… ..13 ENGAGED/DISENGAGED MODE ................14 DRIVING YOUR POWERCHAIR................15 CARING FOR YOUR POWERCHAIR ................16 BATTERIES AND BATTERY CHARGING..............17 TROUBLESHOOTING....................19...

  • Page 3: Introduction

    The innovative design of the 888WNLLHD includes articulating double frames that move in any direction. This intelligent feature keeps all 6 wheels on the ground at all times, even when driving on uneven terrain, hence the name 888WNLLHD. Combine this with the programmable joystick controller, adjustable arm assemblies, flat-free tires, deluxe reclining captain seat, easy access to batteries and quick-change color shrouds for a complete Powerchair package.

  • Page 4: Emi Warning

    EMI WARNING Electromagnetic Interference (EMI) from Radio Wave Sources Powered electric chairs may be susceptible to electromagnetic interference, which is a kind of interfering electromagnetic energy (EM) emitted from sources such as radio stations, TV stations, amateur radio (HAM) transmitters, two-way radios and cellular phones.
  • Page 5 Powered Chair Electromagnetic Interference (EMI) Because EM energy rapidly becomes more intense the closer one moves to the transmitting antenna (source), the EM fields from hand-held radio sources (transceivers) are of special concern. It is possible to unintentionally bring high levels of EM energy very close to the Powerchair’s control system while using these devices.

  • Page 6: Safety Instructions

    Safety Instructions Please use your Powerchair often and let it expand your horizons. The more mobility your Powerchair brings, the happier you will be! But, with all things, observing a few rules will ensure safe maneuvering. So please… (1) Do not drive the Powerchair without reading this instruction manual. (2) D o n o t u s e t h e j o y s t i c k i n a n e r r a t i c m a n n e r w h e n g o i n g u p o r d o w n a n incline.
  • Page 7 Important Notes The Shoprider Powerchair is designed to assist in your individual mobility needs. Any usage outside of the guidelines in this manual may result in damage to the chair or injury to the user or third party.

  • Page 8: Feature Guide

    Feature Guide (888WNLLHD) Fig. 1 (1) Armrests (2) Joystick Controller (3) Charging Port (4) Deluxe Reclining Captain Seat (5) LED Headlight (6) Indicator Light (7) Footplate (8) Front Castor (9) Drive Wheel (10) Rear Castor (11) Taillight...

  • Page 9: Getting To Know Your Powerchair

    Getting to Know Your Shoprider Powerchair The Seat and Arm Assemblies ANGLE Pull up on the end of the armrests and they will flip back up allowing easy transfer in and out of the seat. Under the armrest, there is a bolt and lock nut (1) that can be adjusted up or down to change the angle of the armrest.

  • Page 10: The Joystick Controller (Shark)

    The Joystick Controller (Shark) On / Off Button (1) This button turns the joystick controller (hereinafter referred to as Shark joystick) on and off. Do not use this button to stop the Powerchair, except in an emergency. Speed Decrease Button (2) This button decreases the maximum speed.
  • Page 11 Powerchair. Charging Port (10) for Off-Board Charger Only plug a Shoprider certified charger into this port. This port should not be used as a power supply for any other electrical devices. Disregarding this will void the warranty of the Powerchair.

  • Page 12: Getting Ready To Drive

    Getting Ready to Drive STEP 1 Press the On / Off Button, then the joystick will turn on after the Battery Gauge blinks for about a second. STEP 2 Press the Speed Increase / Decrease Button to set up a suitable level that you can maneuver the Powerchair easily.

  • Page 13: Locking / Unlocking The Joy Stick Controller

    Locking/Unlocking the Shark Joystick LOCK MODE: The Shark joystick can be locked to prevent unauthorized use. The locking method is achieved through a sequence of key presses and joystick movements, as detailed below. To lock Powerchair controller:  While the power is ON, press and hold the Power button for 4 seconds. ...

  • Page 14: Engaged/Disengaged Mode

    Engaged/Disengaged Mode The free wheel release lever (yellow handle) is located inside the right / left rear wheel. To disengage the motor, lift up the lever (the Powerchair can now be pushed). To re- engage the motor push down on the lever. WARNING! Always re-engage the free wheeling device after use.

  • Page 15: Driving Your Powerchair

    Driving Your Powerchair Ramps, Slopes and Cambers The indoor/outdoor Powerchair has the ability to negotiate ramps, slopes and cambers of a low to medium gradient. It is of the utmost importance that the following points are observed: 1. Never attempt to go up or down an incline which has a rough, wet or slippery surface (loose gravel, tree roots, wet grass, polished floor, etc.) 2.

  • Page 16: Caring For Your Powerchair

     Check the 888WNLLHD’s batteries on a regular basis. For extended battery life, it is highly recommended that the batteries be fully charged after each use. If the...

  • Page 17: Batteries And Battery Charging

    Batteries & Battery Charging The Powerchair is supplied with 12 Volt 50Ah x 2 sealed lead acid, maintenance free batteries. These are located under the seat in the center of the Powerchair. For easy handling, Velcro or plastic carrying straps may be provided to assist in installation or removal of the batteries.
  • Page 18 Batteries & Battery Charging How to Charge Your Unit 1. Make sure that the main switch on the charger is in the off position. 2. Connect the charger to the charging port at the front of the Shark (item 10 in Fig.2) 3.

  • Page 19: Troubleshooting

    Troubleshooting The Self-Help Guide (Table 1) is intended to assist in the location of a fault that may occur in a certain part of the Powerchair. Flash codes indicate the nature of an abnormal condition directly from the Shark joystick Information Gauge.

  • Page 20: Specifications

    Range per charge Km(mile) 26~28(16~18) (Battery Capacity) As a part of our ongoing product improvement initiative, Shoprider reserves the right to change specifications and design without prior notice. All specifications and dimensions are approximate. Includes the anti-tip wheel. The actual driving range varies with the factors shown below: 1.

  • Page 21: Notes

    Notes...

  • Page 22: Disclaimer

    This Powerchair is not intended to be used by individuals with physical limitations that ® could prevent the user from operating the Powerchair safely. SHOPRIDER disclaims all responsibility for any personal injury or property damage, which may occur as a result of improper or unsafe use of its products.
