  • Page 1 T585 Safety.qxd 3/23/2006 4:11 PM T585 ® Digital Disc Player Owner’s Manual Manuel d’Installation Bedienungsanleitung Gebruikershandleiding Page 1...

  • Page 2: Introduction

    Main Power Disconnect; When the power switch is in the Off position, the T585 is not completely disconnected from the main power. The primary method of isolating the T585 from the mains supply is to disconnect the mains plug. Ensure that the mains plug remains accessible at all times. When installing the product, ensure that the plug is easily accessible.
  • Page 3 THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE IS INTENDED TO ALERT THE USER TO THE PRESENCE OF IMPORTANT OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE APPLIANCE CAUTION Changes or modifications to this equipment not expressly approved by NAD Electronics for compliance could void the user’s authority to operate this equipment. CAUTION REGARDING PLACEMENT To maintain proper ventilation, be sure to leave a space around the unit (from the largest outer dimensions including projections) equal to, or greater than, shown below.

  • Page 4: Table Of Contents

    Remote Control ............10 Operation Of The T585 With The Remote Control ......11 OPERATION Operation of the T585 .
  • Page 5 T585 Safety.qxd 3/23/2006 4:11 PM SETUP Connecting to Surround Sound System ....... . .19-25 SACD/DVD-A.

  • Page 6: Identification Of Controls

    T585 Safety.qxd 3/23/2006 4:11 PM Identification of Controls FRONT PANEL 1-2Power button and On/Standby indicator 3 Display window 4 Select/Enter/Navigation buttons 5 STOP button 6 OPEN/CLOSE button 7 DVD/CD tray 8 PLAY button 9 PAUSE button DISPLAY WINDOW 1 DVD-Audio and Dolby Digital multi-channel output indicator...

  • Page 7: Rear Panels

    The +12V-IN TRIGGER allows you to have an external 12V signal to turn ON the NAD T585 from standby. This 12V signal must be a continuous 12V signal in order to keep the T585 in the ON state. Once you remove the 12V signal the T585 will return to standby.

  • Page 8: Rear Panels

    The +12V-IN TRIGGER allows you to have an external 12V signal to turn ON the NAD T585 from standby. This 12V signal must be a continuous 12V signal in order to keep the T585 in the ON state. Once you remove the 12V signal the T585 will return to standby.

  • Page 9: Preparing The Remote Control

    NOTES ON THE REMOTE CONTROL • Do not expose the remote sensor of the T585 to a strong light source such as direct sunlight or illumination. If you do so, you may not be able to operate the T585 with the remote control.

  • Page 10: Remote Control

    T585 Safety.qxd 3/23/2006 4:12 PM Identification of Controls REMOTE CONTROL 1 POWER ON, POWER OFF 2 SETUP 3 Transport control keys OPEN/CLOSE, STOP, PAUSE, STEP, PLAY, SKIP, SCAN, SLOW 4 ENTER and navigation buttons 5 RETURN 6 TITLE, MENU 7 DISPLAY...

  • Page 11: Operation Of The T585 With The Remote Control

    10 The REPEAT A-B button is used to repeat a specific start to stop section of an audio CD or DVD/VCD. During play mode of the media, press the button once to store the start point of the T585 in memory.

  • Page 12: Operation

    Press PLAY. The disc tray is automatically closed and playback begins. • If the disc is placed in upside down (and it is a single sided disc), NO DISC will appear on the T585’s display and ‘NO DISC’ appears on the TV screen.

  • Page 13: Special Playback

    Resume function may not be available on some DVD/VCD discs. STILL PICTURE (PAUSE) Press PAUSE during playback. For a DVD, the T585 will be placed in the still picture mode. For a CD the player will be placed in the pause mode.

  • Page 14: Scanning At High Speed

    CD and VCD). The speed will be retained even after the button is released. To return to normal playback, press PLAY NOTES • The DVD player does not play back sound during the high-speed reverse and forward playback of DVD VCD video discs as well as CD video discs. • Not all media support maximum speeds for scanning.

  • Page 15: Osd Operation

    T585 Safety.qxd 3/23/2006 4:12 PM DISPLAY/TITLES/MENUS/SUBTITLES Examples of GUI (Graphical User Interface) MENU Icons (The screens may differ depending on the disc contents.) OPERATION USING MENU ICONS Press DISPLAY during playback [TV screen] DVD GUI To show the current title number, press the DISPLAY button, and navigate to the desired title number or type in the numeric number directly and press ENTER.

  • Page 16: Viewing From Another Angle

    T585 Safety.qxd 3/23/2006 4:12 PM Operation VIEWING FROM ANOTHER ANGLE REPEAT PLAY Page 16 Some DVDs may contain scenes, which have been shot simultaneously from a number of different angles. For these discs, the same scene can be viewed from each of these different angles using the ANGLE button.

  • Page 17: Storing Markers In Memory

    3/23/2006 4:12 PM Storing a MARKER in the T585’s memory is similar to marking your page in a book. It allows you to quickly return to any point on the disc. 1 Press MARKER during play at the starting point to be viewed (listened to) again Indicates 1/9 is stored in the memory.

  • Page 18: Random Play

    RANDOM PLAY (CD) PROGRAM PLAY (CD) Page 18 1 Press RANDOM during normal playback or stop mode. The T585 automatically starts random playback and the PROG indicator will appear in the T585’s display. 2 To resume normal playback, press RANDOM.

  • Page 19: Playback Audio With Cd, Vcd, And Dvd

    Connect the audio outputs to your integrated amplifier as shown below. Then set up the speaker bass response and configuration as per the 5.1 SPEAKER SETUP. Rear of T585 digital disc player DVD-A, SACD, Dolby Digital 5.1 Outputs Rear of M15 A/V Surround Sound Preamplifier 7.1 Inputs...

  • Page 20: Setup

    Refer to the owner’s manual of your audio equipment as well. Depending on your Dolby Digital surround sound decoder, the decode rate may be 96 or 48K. When you connect the T585 to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet before making any connections.

  • Page 21: Dolby Pro Logic Surround Sound

    Refer to the owner’s manual of your audio equipment as well. Depending on your Dolby Digital surround sound decoder, the decode rate may be 96 or 48K. When you connect the T585 to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet before making any connections.

  • Page 22: 2-Channel Digital Stereo Sound

    • Refer to the owner’s manual of your receiver as well. • Before you connect the T585 to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet before making any connections.

  • Page 23: Dts Sound

    DTS SOUND In order to enjoy DTS sound your A/V Receiver or processor must be equipped with a DTS Decoder. The digital output of the T585 must be set to‘Stream/PCM' and the disc must have a DTS soundtrack. There is no analogue output of the T585 for DTS soundtrack.

  • Page 24: Connecting To An Analogue Stereo System

    • Refer to the owner’s manual of your receiver as well. • Before you connect the T585 to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet before making any connections.

  • Page 25: Connecting To A Tv Directly

    • Refer to the owner’s manual of your receiver as well. • Before you connect the T585 to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet before making any connections.

  • Page 26: Initial Setup Settings

    1 From the T585 remote control, press SETUP to select the Settings menu. A drop-down menu for ‘OSD’, ‘Audio’, ‘Subtitle’, ‘Menu’, and ‘Text’ will display. 2 Use the navigation keys to select the desired Language and then press the ENTER button on the T585 remote to store the selection.

  • Page 27: Selecting Video Aspect And Picture Mode

    T585 Safety.qxd 3/23/2006 4:13 PM SELECTING VIDEO TV ASPECT AND PICTURE MODE To select the appropriate display mode according to your TV set, one selects the SETUP menu form the remote. Choose ‘Video’, ‘Display Mode’, then the three choices that best fit your TV set.

  • Page 28: Selecting Signal Mode

    3 Using the navigation arrows, select either ‘0’ or ‘+7.5’ IRE and press ENTER NOTES • The black level defaults are different for each type of T585; NTSC T585 is +7.5 IRE, PAL T585 is 0 IRE. • Setting the black level incorrectly may result in poor contrast when displaying dark scenes.

  • Page 29: Selecting Brightness Level

    Depending on the settings of your monitor, you may wish to adjust the brightness of the viewed media from your T585 instead of the monitor. The brightness can be fine tuned to your video monitor. 1 From the drop-down menu of the OSD screen, use the navigation keys to select the video icon, and press the ENTER on the remote 2 Using the navigation arrows, select “Brightness”...

  • Page 30: Selecting Video Adjustment Options

    Black Level Brightness Contrast Saturation Sharpness Gamma HDMI 480/576 720p 1080i 480/576 720p 1080i Component YPbPr 480p/576p 720p Component YCbCr 480i/576I 1080i CVBS 480i/576I S-Video 480i/576I SCART/RGB 480i/576I 480p/576p 720p 1080i Note: For European version T585, see page 37 for available video output options.

  • Page 31: Selecting Digital And Audio Output And Other Settings

    • Do not use any type of solvents such as thinner, benzene, commercially available cleaners or anti- static spray for vinyl LPs. They may damage the disc. • The T585’s OSD may display “ERROR: DISC MINOR - CLEAN ME”. If it does, clean the disc as mentioned above.

  • Page 32: Playable Discs

    In addition this unit can play back a CD-R or CD-RW that contains audio titles or MP3 files You cannot playback discs other than those listed above such as; CD-ROM, CD-Extra, CD-G, and CD-i discs. To do so may render the T585 permanently inoperable.

  • Page 33: Table Of Languages And Their Abbreviations

    T585 Safety.qxd 3/23/2006 4:13 PM Enter the appropriate code number in the Settings’ drop-down-menu, ‘Other’ for “Audio”, “Subtitle”, “Menu” and/or “Text”. Be aware that this is a media specific feature that may not be available for all DVDs and VCDs.

  • Page 34: Troubleshooting

    • Plug the power cord into the wall outlet securely. • Insert a disc (Check that the DVD or VCD indicator in the T585’s display is lit). • Select the appropriate video input mode on the TV so that the picture from the DVD player appears on the TV screen.

  • Page 35: Specifications

    Unit Dimensions (W x H x D)* *Gross dimensions include feet, disc tray, and rear connections Specifications are subject to change without notice. For updated documentation and features please log onto www.nadelectronics.com for the latest information about your T585. Page 35 3 x 12-Bit 256MHz DAC...

  • Page 36: Copyright Information/Macrovision Product Notice

    CONSUMERS SHOULD NOTE THAT NOT ALL HIGH DEFINITION TELEVISION SETS ARE FULLY COMPATIBLE WITH THIS PRODUCT AND MAY CAUSE ARTIFACTS TO BE DISPLAYED IN THE PICTURE. IN CASE OF T585 PROGRESSIVE SCAN PICTURE PROBLEMS, IT IS RECOMMENDED THAT THE USER SWITCH THE CONNECTION TO THE STANDARD DEFINITION INTERLACE OUTPUT.

  • Page 37: Notes

    T585 Safety.qxd 3/23/2006 4:13 PM VIDEO OUTPUT SCAN TYPES (EUROPEAN) 480I/576I HDMI SCART/RGB Component YPbPr Component YCbCr CVBS S-Video VIDEO OUTPUT SCAN TYPES (NORTH AMERICAN) 480I/576I HDMI Component YPbPr Component YCbCr CVBS S-Video Page 37 480P/576P 720P 1080I 480P/576P 720P...
  • Page 38 T585 Safety.qxd 3/23/2006 4:13 PM Reference ADDENDUM DOLBY / PCM Digital Audio DIGITAL Output Stream / PCM 5.1 Speaker Setup Master Volume Sample Freq. Downmix 48 KHz 96 KHz 192 Khz HDMI Dual Mono Test Tone Page 38 HIGH RESOLUTION DVD-AUDIO STEREO 192KHZ 24-BIT DISCS When playing 192KHz 24-bit High resolution DVD-audio stereo discs through the MIXED AUDIO OUT, it is necessary to select the option 192 kHz HDMI in the Digital Audio Output OSD menu.
  • Page 39 T585 Safety.qxd 3/23/2006 4:13 PM Page 39...
  • Page 40 Page 38 www.NADelectronics.com ©2006 NAD ELECTRONICS INTERNATIONAL A DIVISION OF LENBROOK INDUSTRIES LIMITED All rights reserved. No part of this publication may be reproduced, stored or transmitted in any form without the written permission of NAD Electronics International 585 Manual 02/06...
