Summary of Contents for HotSpring Vista
- Page 2 Watkins Manufacturing Corporation congratulates you on your decision to enjoy the ® finest spa available... Welcome to the growing family of Hot Spring spa owners. Owner’s Manual This Owner’s Manual will acquaint you with the operation and general maintenance of your new spa. We suggest that you take some time to carefully review all ten sections.
-
Page 3: Table Of Contents
115 Volt GFCI ................35 Important Safety Instructions ............1 JeT MeNUS Important Spa Instructions ............3 SPA SPeCIfICATIONS VISTA (Model SS) ..............36 ..........4 GRANDEE (Model GG) ............. 37 INSTAllATION INSTRUCTIONS ENVOY (Model KK) ..............38 Site Preparation ..............5 ARIA (Model AR) ................ -
Page 4: Safety Information
safety infOrMatiOn IMPORTANT SAfeTy INSTRUCTIONS (Read and follow all InStRuctIonS) AvOIdINg THe RISk TO CHIldReN dANgeR: • RISk Of CHIld dROWNINg. Extreme caution must be exercised to prevent unauthorized access by children. To avoid accidents, ensure that children cannot use a spa unless they are supervised at all times. WARNINg: • To reduce the risk of injury, do not permit children to use this spa unless they are closely supervised at all times. - Page 5 (pressure wire connector) is provided on the outside of the control box for bonding to local ground points. To reduce the risk of electric shock, this connector should be bonded with a No. 8 AWG (8.4 mm ² ) solid copper wire to any metal ladders, water pipes, or other metal within 5 feet (1.5 m) of the spa to comply with local requirements.
-
Page 6: Important Spa Instructions
unclean wateR • Keep the water clean and sanitized with correct chemical care. The recommended levels for your Hot Spring ® spa are: - Free Available Chlorine (FAC): 3.0-5.0 ppm - Total Alkalinity: 40-120 ppm - Water pH: 7.2-7.6 - Calcium Hardness: 100-150 ppm (Refer to Water Quality and Maintenance section for complete instructions.) IMPORTANT: Turn on the jet pump for a least ten minutes after adding ANY spa water chemicals into the filter compartment. • Clean the filter cartridges monthly to remove debris and mineral buildup which may affect the performance of the hydromassage jets, limit the flow, or trip the high limit thermostat, which will turn off the entire spa. -
Page 7: Spa Specifications
® 1,008 6,228 7'7" x 8'4" 120 lbs. Vista 230 volt, 50 amp 38" 325** gallons lbs. lbs. per sq. (Model SS) 2.31m square 4,000 Single phase GFCI foot Seats 6 1,893 2,825 feet 97 cm protected circuit Adults 2.54m... -
Page 8: Installation Instructions
installatiOn instructiOns SITe PRePARATION WARNING WARNING You probably have a spot picked out for your new spa, whether it’s indoors or outdoors, on a patio or on a deck. Just make sure you check the following: • Always put your spa on a structurally sound, level surface. A filled spa can weigh a great deal. Make certain that the location you choose can support the weight of your filled spa. • Don’t forget to level your spa before filling it. (See Spa Leveling Instructions) • Locate your equipment compartment, which houses all of the electrical components, in a place where Lowering the top of... -
Page 9: Spa Leveling Instructions
• Exterior rated lumber ® ® NOTe: due to the large size of the vista and grandee spas Watkins Manufacturing Corporation requires the spas be installed on a level 4" thick concrete pad or structurally engineered deck and NOT shimmed in any manner. - Page 10 16" (40.6 cm) 22 1/2" (57.1 cm) ® eNvOy (MOdel kk) 37 1/2" (95.3 cm) leveling Points 43 1/2" (110.5 cm) 67 1/2" (171.5 cm) NOTe: All dimensions are approximate; measure your spa before 71" (180.3 cm) making critical design or pathway decisions. 93"...
- Page 11 ® ARIA (MOdel AR) 21" (53.3 cm) leveling Points 25" (63.5 cm) NOTe: All dimensions are approximate; measure your spa before 30 3/4" (78.1 cm) making critical design or pathway decisions. 36.75" (93.3 cm) 62.0 " (157.5 cm) 65 3/4" (167.0 cm) 12"...
- Page 12 ® vANgUARd (MOdel vv) 21" (53.3 cm) leveling Points 25" (63.5 cm) 30 3/4" (78.1 cm) NOTe: All dimensions are approximate; measure your spa before 36.75" (93.3 cm) making critical design or pathway decisions. 62.0 " (157.5 cm) 65 3/4" (167.0 cm) 12"...
- Page 13 ® SOveReIgN (MOdel II) 17 1/2" (45.1 cm) 31 1/2" (80 cm) leveling Points 34.5" (67.6 cm) NOTe: All dimensions are approximate; measure your spa before 58 1/2" (148.6 cm) making critical design or pathway decisions. 59 1/2" (151.1 cm) 38"...
- Page 14 13" (33 cm) ® PROdIgy (MOdel H) 14 1/2" (36.8 cm) leveling Points 33 1/4" (84.5 cm) NOTe: All dimensions are approximate; measure your spa before 43 1/2" (110.5 cm) making critical design or pathway decisions. 57" (144.8 cm) 74" (188.0 cm) 15"...
- Page 15 ® JeTSeTTeR (MOdel JJ) leveling Points 22" (55.9 cm) 28" (71.1 cm) NOTe: All dimensions are approximate; measure your spa before 47" (119.4 cm) making critical design or pathway decisions. 58" (147.3 cm) 64" (162.5 cm) 84" (213.4 cm) 80" (203.2 cm) 20 3/4"...
-
Page 16: Controls And Equipment
® vISTA (MOdel SS) OveRHeAd vIeW ® A. SmartJet system lever ® B. Moto-Massage jet Comfort ® Control system lever ® C. Precision jets Comfort Control system lever D. Water feature lever E. Hydromassage jet with directional nozzle F. -
Page 17: Grandee (Model Gg)
® gRANdee (MOdel gg) OveRHeAd vIeW ® A. SmartJet system lever ® B. Moto-Massage jet Comfort ® Control system lever ® C. Precision jets Comfort Control system lever ® D. JetStream jet Comfort Control system lever E. Pillow F. Hydromassage jet with directional nozzle G. -
Page 18: Envoy ® (Model Kk)
Envoy ® (ModEl KK) OveRHeAd vIeW ® A. SmartJet system lever ® B. Moto-Massage jet Comfort ® Control system lever ® C. Precision jets Comfort Control system lever D. Pillow E. Hydromassage jet with directional nozzle F. Hydromassage jet with rotary nozzle G. -
Page 19: Aria ® (Model Ar)
aRIa ® (ModEl aR) OveRHeAd vIeW ® A. SmartJet system lever ® ® B. Precision jets Comfort Control system lever ® C. Moto-Massage jet Comfort Control system lever D. Pillow E. Hydromassage jet with directional nozzle F. Hydromassage jet with rotary nozzle G. -
Page 20: Vanguard ® (Model Vv)
vanguaRd ® (ModEl vv) OveRHeAd vIeW ® A. SmartJet system lever ® B. Moto-Massage jet Comfort ® Control system lever ® C. Precision jets Comfort Control system lever D. Pillow E. Hydromassage jet with directional nozzle F. Hydromassage jet with rotary nozzle G. -
Page 21: Sovereign ® (Model Ii)
SovEREIgn ® (ModEl II) OveRHeAd vIeW ® A. SmartJet system lever ® B. Moto-Massage jet Comfort Control system lever ® C. Precision jets Comfort ® Control system lever D. Pillow E. Hydromassage jet with directional nozzle F. Hydromassage jet with rotary nozzle G. -
Page 22: Prodigy ® (Model H)
PRodIgy ® (ModEl H) OveRHeAd vIeW ® A. SmartJet system lever ® B. JetStream jet Comfort ® Control system lever ® C. Precision jets Comfort Control system lever D. Hydromassage jet with directional nozzle E. Hydromassage jet with rotary nozzle F. -
Page 23: Jetsetter ® (Model Jj)
JEtSEttER ® (ModEl JJ) OveRHeAd vIeW ® A. SmartJet system lever ® B. JetStream jet Comfort ® Control system lever ® C. Moto-Massage DX jet Comfort Control system lever ® D. Precision jets Comfort Control system lever E. Pillow F. Hydromassage jet with directional nozzle G. -
Page 24: Electrical Requirements And
The power indicator will stop blinking once the problem has been corrected. The Power and Ready indicator lights on the control panel also provide the same diagnostic function. 230 vOlT PeRMANeNTly CONNeCTed MOdelS • Vista • Grandee • Envoy ®... - Page 25 NOTe: Long wiring runs may require larger-gauge wire than stated. We recommend using a maximum 3% voltage drop when calculating wire gauge requirements. ® ® ® ® vISTA (SS), gRANdee (gg), eNvOy (kk) & ARIA (AR) WIRINg CONNeCTIONS Identify the TB-1 terminal block, located inside the control box at the lower left-hand corner.
-
Page 26: Volt Permanently Connected Model
WARNINg: fIll THe SPA WITH WATeR befORe TURNINg ON THe POWeR! (See STARTUP ANd RefIll PROCedUReS). Once your spa has been filled with water, turn it on and test all of the circuit breakers. ® ® ® ® Vista (SS),Grandee (GG), Envoy (KK),& Aria (AR) 230 volt permanently connected model... -
Page 27: Volt Operation
NeveR CONNeCT THe SPA TO AN eXTeNSION CORd! A pressure wire connector is provided on the exterior surface of the control box, inside the spa. This is to permit the connection of a ground bonding wire between this point and any metal equipment, enclosures, reinforced concrete pad, pipe, or conduit within 5 feet of the spa (if needed to comply with local building code requirements). - Page 28 INSTAllATION INSTRUCTIONS 1. To connect the electrical service, first open the equipment compartment door. Carefully pull the door panel away and remove it from the spa. 2. Locate the IQ 2020 spa control box. Loosen the screws on the front of the control box. Remove the screws and the control box cover. 3.
-
Page 29: Operating Instructions
30 amp / 230 volt GFCI circuit breaker. The Vanguard and Sovereign models use the 20 amp breaker for the jet pump and control circuit while the 30 amp breaker is used for the heating system. The Vista, Grandee, Envoy and Aria models use the 20 amp breaker for the heating system while using the 30 amp breaker for the jet pumps and control circuit. -
Page 30: Start-Up And Refill Procedures
Open the door of the electrical subpanel, if your spa is a Vanguard or Sovereign model reset the 20 amp GFCI breaker first and verify the system is primed (see step 3), then reset the 30 amp breaker. If your spa is a Vista, Grandee, Envoy or Aria model reset the 30 amp GFCI breaker first, verify the system is primed, then reset the 20 amp breaker. -
Page 31: Smartjet System
Operational Note: Make sure you adjust your Total Alkalinity first, as an out-of-balance condition will affect your ability to adjust the pH correctly, and will prevent the sanitizer from operating effectively. The spa is ready for use when the spa water has circulated through each SmartJet lever operating position and the chlorine level remains between 3 ppm and 5 ppm. -
Page 32: Hydromassage Jets
® HydROSTReAM ® ® ® (vISTA , eNvOy & ARIA SPAS ONly) The Hydrostream jet is a mid-size hydromassage jet that delivers a great massage to the feet, back and shoulder areas. This jet can be adjusted at the face plate for greater or lesser intensity. -
Page 33: Indicator Lights
The four labeled outer buttons are referred to as "Hard buttons". These buttons are fixed and their functions do not change. The four inside buttons are referred to as "Soft buttons". Pressing the soft button will activate the function on the screen closest to the button. -
Page 34: Home Screen
® HOT SPRINg ON/ReAdy INdICATOR lIgHT Green indicator - water is ready, within 2°F of set temperature The Hot Spring logo on the front of the spa illuminates a blue and green color. These colors indicate the power and ready status of the spa without having to open the cover and look at the control panel. -
Page 35: Jets Control
& ® ® ® ® Sovereign models) or Jet 2 Low position (Vista , Grandee , Envoy and Aria models), the blue ™ Jet Pump icon will also light up. Press any of the soft keys to change the jet functions between high, low (when available) speed, and off. -
Page 36: Summer Timer
Press the LIGHTS hard button to activate the Underwater Lighting and display the screen below. The intensity of the spa’s underwater lights are controlled using the Dimmer soft button. There are five (5) brightness levels plus off. NOTe: Pressing the LIGHT hard button will also change the intensity of the spa's underwater lights when in the Underwater Lighting menu. -
Page 37: Auxiliary Control Panel
® ® ® ® vISTA, gRANdee , eNvOy & ARIA 1st Press = Jet pump 2 on Low 2nd Press = Jet pump 2 on High... -
Page 38: Volt Gfci
115 vOlT gfCI The Ground Fault Circuit Interrupter is a safety device that is designed to detect as little as 5 milliamps (±1mA) of electrical current leakage to ground. Watkins Manufacturing Corporation recommends that the GFCI be tested prior to each use to ensure it is functioning correctly. With the spa connected to the power supply, push the TEST button. The spa should stop operating and the GFCI power indicator will go out. -
Page 39: Jet Menus
® vISTA (MOdel SS) JeT SySTeM MeNU JeT PUMP 1–JeT SySTeM 1 JeT PUMP 2–JeT SySTeM 1 ® left SmartJet lever in the 3 o’clock position Right SmartJet lever in the 3 o’clock position • 3 Jet-Cluster • 6 HydroStream ™... -
Page 40: Grandee (Model Gg)
vANgUARd (MOdel v) JeT SySTeM MeNU ® ™ gRANdee (MOdel gg) JeT SySTeM MeNU JeT PUMP 1–JeT SySTeM 1 JeT PUMP 2–JeT SySTeM 1 ® left SmartJet lever in the 3 o’clock position Right SmartJet lever in the 3 o’clock position •... -
Page 41: Envoy (Model Kk)
vANgUARd (MOdel v) JeT SySTeM MeNU ® ™ eNvOy (MOdel kk) JeT SySTeM MeNU JeT PUMP 2–JeT SySTeM 1 JeT PUMP 1–JeT SySTeM 1 Right SmartJet lever in the 3 o’clock position left SmartJet lever in the 3 o’clock position •... -
Page 42: Aria (Model Ar)
® ARIA (MOdel AR) JeT SySTeM MeNU JeT PUMP 1 • 4 Precision ® jets on left back wall • 4 HydroStream ® jets on left back wall • 1-Directional hydromassage on back wall • 1 Moto-Massage ® DX jet on right back wall •... -
Page 43: Vanguard (Model Vv)
vANgUARd (MOdel v) JeT SySTeM MeNU ® ™ vANgUARd (MOdel vv) JeT SySTeM MeNU JeT PUMP 1-JeT SySTeM 1 • 1 Moto-Massage ® jet on left rear • 4 directional Precision ® jets above left Moto-Massage jet • 2 directional Precision jets on left rear seat (calf area) •... -
Page 44: Sovereign (Model Ii)
® SOveReIgN (MOdel II) JeT SySTeM MeNU JeT SySTeM 1 ® SmartJet lever in the 3 o’clock position • 1 Moto-Massage ® DX jet on left rear • 4 directional Precision ® jets above Moto-Massage jet • 10 directional Precision jets on right rear •... -
Page 45: Prodigy (Model H)
vANgUARd (MOdel v) JeT SySTeM MeNU ® ™ PROdIgy (MOdel H) JeT SySTeM MeNU JeT SySTeM 1 SmartJet lever in the 3 o’clock position ® • 10 directional Precision ® jets on right rear • 2 dual port rotary jets on left rear •... -
Page 46: Jetsetter (Model Jj)
vANgUARd (MOdel v) JeT SySTeM MeNU ® ™ JeTSeTTeR (MOdel JJ) JeT SySTeM MeNU JeT SySTeM 1 SmartJet lever in the 3 o’clock position ® • 1 Moto-Massage ® DX jet on left rear • 4 directional Precision ® jets above Moto-Massage DX jet •... -
Page 47: Spa Care And Maintenance
spa care and Maintenance geNeRAl INfORMATION ® Your Hot Spring spa is manufactured from the highest quality, most durable materials available. Even so, the spa care and maintenance program you develop will ultimately determine how long your spa, and its individual components, will last. Regular maintenance and following the advice in this section will help you to protect your investment. -
Page 48: Filter System
a) Remove the filter standpipes by turning them counterclockwise. (The standpipes may have a silicone sealant temporarily holding them in place and it may take firm pressure to get them to initially break free.) b) Place the end of the vacuum hose in one of the filter openings and cover the closest filter opening with a clean rag. c) Turn on the blower function and allow it to blow out any water remaining in the plumbing lines (approximately 3 to 5 minutes). -
Page 49: Filter Cartridges Removal And Cleaning
® ® ® ® pleats. The Tri-X filter (standard on Vista , Grandee , Envoy & Aria models only) can be cleaned in the dishwasher using no soap and no dry cycle. Please contact your Hot Spring dealer for details. -
Page 50: Care Of The Spa Cover
beauty of real wood. Everwood won’t crack, peel, blister or delaminate even after prolonged exposure to the elements. Cleaning of Everwood consists of simply spraying the cabinet with a mild soap and water solution to remove any stains and residue. Do not rub the Everwood with an abrasive material or use abrasive cleaners as this may damage its texture. -
Page 51: Vacation Care Instructions
How to Open the Cover 1. With the cover lock straps unfastened, place one hand under the cover skirting, between the spa and cover, to break the cover’s vacuum seal. Then, fold the front half of the cover over onto the back half. 2. -
Page 52: Water Quality And Maintenance
2. Adjust the pH as required. Sanitize the water by following the shock procedures. Upon your return: 3. Sanitize the water by following the shock procedures. Return the set temperature to its original setting. The spa water will be safe for you to use once the Free Available Chlorine residual level has dropped below 5.0 ppm. -
Page 53: Hot Spring Spa Water Maintenance Program
HOW TO Add CHeMICAlS TO THe WATeR IMPORTANT: All spa water chemicals, including granulated dichlor, MPS, granulated pH increaser or decreaser, granulated total alkalinity increaser, liquid stain and scale inhibitor, and liquid defoamer must always be added directly into the filter compartment while the jet pump is running in its high speed mode, and it must run for a minimum of ten minutes. -
Page 54: Total Alkalinity
bAlANCINg THe pH ALKALINE ADD pH A. The ideal pH level for your spa water is 7.4-7.6. DECREASER WATER B. The pH level is the measure of acidity and alkalinity. Values above 7 are alkaline; those below TO LOWER 7 are acidic. Maintaining the proper pH level is extremely important for: (SCALING ZONE) • Optimizing the effectiveness of the sanitizer. • Maintaining water that is comfortable for the user. COMFORT IDEAL ZONE... -
Page 55: Watkins Water Treatment Guide
(MPS)* per 250 each use gallons (Test before adding any ® 2 tablespoons Vista (Model SS) 1 teaspoon Vista (Model SS) chemicals; do not add ® 2 tablespoons Grandee (Model VV) 1 teaspoon Grandee (Model VV) any chemicals if proper or ®... -
Page 56: Freshwater Ag+® Silver Ion Purifier Replacement ...................... 53
® freshWater III high output ozone system uses Corona Discharge technology to produce a high concentration of ozone which is injected into the spa water. Monopersulfate (MPS) is an oxidizing chemical used to prevent the buildup of contaminants, maximize sanitizer efficiency, minimize combined chlorine, and improve water clarity. -
Page 57: Chlorine (Sodium Dichlor)
® question: Can I use the FreshWater III ozone system in addition to the silver ion system? Answer: Yes. In fact, it is preferred! The use of the FreshWater III ozone system will enhance the performance of the silver ions and may substantially reduce the need for supplemental chemical treatments when the spa is not in use. -
Page 58: Ozone
• The Usage Time is simply the amount of time a user spends in the spa. • Sanitizer Needed is the amount of Free Available Chlorine needed to accommodate the number of users and their combined usage time. For example, two spa users who regularly use the spa once an evening for twenty minutes create a specific and somewhat consistent demand on the sanitizer. During the first month of ownership, these two users can determine exactly how much sanitizer to use in order to maintain the proper residual. -
Page 59: Common Water Chemistry Questions
nitric acid accumulates in the air lines of the ozonator and WaRnIng WaRnIng injector. nitric acid will cause severe chemical burns if direct skin contact is made, so always wear protective gloves, glasses and clothing when working on the ozonator or injector lines. to prevent inhalation or ingestion of the nitric acid, do not blow or inhale with your mouth to any of the adapters, fittings or tubing of the ozonator or injector air lines. -
Page 60: Water Terminology
question: When I open my spa, I smell chlorine. How do I get rid of this smell? Answer: There are two types of chlorine in your spa. The first is the Free Available Chlorine (FAC), which is the chlorine available to sanitize your spa. -
Page 61: Service Information
ppm: The abbreviation of “parts per million”, the standard measurement of chemical concentration in water. Identical to mg/l (milligrams per liter). Reagent: A chemical material in liquid, powder, or tablet form for use in chemical testing. Sanitizer: Sanitizers are added and maintained at recommended residuals to protect bathers against pathogenic organisms which can cause disease and infection in spa water. -
Page 62: Silent Flo 5000 Circulation Pump And Circulation Pump Thermal Cut-Off
® SIleNT flO 5000 CIRCUlATION PUMP ANd CIRCUlATION PUMP THeRMAl CUT-Off ® The Hot Spring Silent Flo 5000 circulation pump is a dedicated, water cooled, energy efficient, quiet pump that provides continuous filtration for the spa. Since the Silent Flo 5000 pump is water cooled, it is equipped with a thermal cut-off to prevent the pump from being damaged by running hot when water is not present. -
Page 63: Disclaimers
Acts of nature, and damage caused by animals, rodents, and insects are considered abuses and are not covered under this warranty. *Operation of the spa does not mean “use” of the spa! Watkins Manufacturing Corporation does not recommend using the spa if the water temperature is above or below the spa’s control panel temperature range. -
Page 64: Spa Care And Maintenance Record
SPA CARe ANd MAINTeNANCe ReCORd Date Page 61 Service Information... -
Page 65: Troubleshooting Guides
TROUbleSHOOTINg ® Should you experience any problem whatsoever, do not hesitate to contact your authorized Hot Spring dealer. Here are some tips to help you to diagnose and rectify some more common sources of trouble yourself, if you choose to do so. gEnERal oPERatIon tRouBlESHootIng guIdE Problem Probable causes... - Page 68 (MODEL JJ/JJC) 1/11 ©2011 Watkins Manufacturing Corporation. Hot Spring, Moto-Massage, Vista, Grandee, Envoy, Vanguard, Sovereign, Aria, Prodigy, Jetsetter, Jet-Cluster, SmartJet, Comfort Control, No-Fault, IQ 2020, Wavemaster, Silent Flo-5000, Soothing Seven, Soothing Stream, JetStream, Precision, Everwood, CoverCradle, UpRite, Lift ’n Glide, EverFresh, FreshWater, FreshWater...
